Title: Millikans Oil Drop Experiment


1
Millikans Oil Drop Experiment
  • Dr. Frank Walmsley
  • Department of Chemistry
  • Trinity University
  • San Antonio, TX 78212

2
Historical Setting
  • Early 1900s
  • Rutherford had reported his alpha scattering
    experiments. Structure of atom known but not
    accepted by everyone.
  • Charge on an alpha particle known.
  • Experiments with cathode rays known including
    fact that negatively charged.

3
Historical Setting
  • Needed to know charge on an electron.
  • Millikan modified experiments tried by others and
    did very careful work.
  • Used nonvolatile oil rather than volatile water.
  • Corrected equations for rate of fall of drop
    determined this experimentally

4
Historical Setting
  • Robert Millikan
  • Received Nobel Prize for this work
  • Work done at University of Chicago
  • Became first president of Californa Institute of
    Technology

5
Design of the Experiment
  • Sketch of apparatus used
  • Blue plates charged charge can be varied. Oil
    drops fall through hole in top plate. Xrays place
    electrons on drops. Microscope used for observing
    drops.

6
Design of the Experiment
  • Photo of actual apparatus used in the
    experiments.

7
Design of the Experiments
  • Time of fall of oil drop in the absence of field
    measured between two fixed points. Drop falls due
    to gravity.
  • Electric field needed to hold drop steady between
    the two plates measured.
  • When drop is suspended, force due to gravity
    equals force due to electrical attraction to
    plate.

8
Design of the Experiment
  • Information needed
  • Density of air
  • Viscosity of air
  • Density of oil
  • Equation for rate of fall
  • Strength of electric field
  • Temperature
  • Air Pressure

9
Data Treatment
  • From Millikans 1911 paper.

10
Data Treatment
  • Notice that dividing by the smallest of the three
    numbers does not give whole number results.
  • 1.996 1.000 2.813
  • Millikan had lots of measurements, not just 3
    which is needed in order to find that common
    multiplier.

11
Experimental Results
  • Showed that the charges were multiples of the
    minimum basic charge of one electron.
  • Determined the value of that charge.
  • This led to more accurate values for other
    constants such as Avogadros Number.

12
Was Millikan Dishonest?
  • Millikan did not use all his data points in his
    published articles.
  • Millikan said in his articles that he did use all
    points.
  • How can both be true?

13
Was Millikan Dishonest?
  • It is true that Millikan selectively chose points
    to report.
  • He discarded drops that were too small because
    they were too affected by bombardment from air
    molecules.
  • He discarded drops that were too large because
    they did not obey the equations for rate of fall.
  • He discarded drops that had only one measurement
    that is, did not have additional measurements
    with fewer or greater numbers of electrons.

14
Was Millikan Dishonest?
  • It appears that what he meant (and did not say
    clearly) was
  • He used all drops that met his criteria for being
    reliable.
  • If he had used all drops, the results would have
    been essentially the same.

15
