Automatic semantic role labeling using FrameNet: a literature survey

1
Automatic semantic role labeling using FrameNet
a literature survey

• Justin Betteridge
• 11-731 Machine Translation
• April 18, 2005

2
Outline

• Introduction
• Automatic Labeling of Semantic Roles -- Gildea
  Jurafsky, 2002
• SENSEVAL 3 ASR task
• Applications in MT
• Conclusions / Work in progress

3
1. Introduction

• Example
• She blames the Government for failing to do
  enough to help.
• Judge She blames Evaluee the Government
  Reason for failing to do enough to help .

4
1.2 Semantic Roles

• linking theory
• mapping from syntax to semantics
• spectrum of approaches
• specific ? general
• (CS) (linguists)

5
1.3 FrameNet (Johnson et al., 2003)
6
2. Automatic Labeling of Semantic Roles (Gildea
Jurafsky, 2002)

• Statistical techniques
• training 36,995 sentences
• development 8,167 sentences
• test 7,900 sentences
• FrameNet 1.0 (67 frames, 12 domains)
• theory of frame semantics by Fillmore (1976)
• Applications
• generalizing IR, QA, semantic dialogue systems
• help in WSD
• intermediate representation in SMT, text
  summarization, text data mining
• incorporation into probabilistic language models
  accurate parsers, better LM for ASR

7
2.1 Previous work

• Data-driven techniques
• Miller et al. (1996) ATIS air travel domain
• Riloff (1993) data-driven IR, dictionary of
  patterns for filling slots in a specific domain
• Riloff and Schmelzenbach (1998) automatically
  derive entire "case frames" for words in the
  domain
• Blaheta and Charniak (2000) domain independent
  system trained on function tags in PTB doesn't
  include all arguments of most predicates
• this work identify all semantic roles for wide
  variety of predicates in unrestricted text

8
2.2 Features Used

• Governing Category
• either S (for subjects) or VP (objects)
• only applies to NPs
• Parse Tree Path
• Example
• constituent's syntactic relation to target word
  (unlike gov)
• dependent on parse tree formalism 2,978 different
  values from training data, not counting unmatched
  frame elements, 4,086 otherwise
• subsumes gov when S or VP in path (4 of 35,138
  NPs do not)

9
2.2 Features Used

• Position
• whether constituent occurs before or after target
  word
• gov, position, path all represent syntactic
  relation between target word and constituent
• individual experiments showed all performed
  pretty much the same
• Voice
• often active verb direct objects lt--gt passive
  verb subjects
• passives identified using patterns (passive
  auxiliary and past participle)
• about 5 of examples were classified as passive
• Head Word
• expected lexical information to be important
  (like other areas in NLP)
• integral part in Collins parser --gt read directly
  from parse tree
• prepositions, complementizers are heads

10
2.3 Probability Estimation
11
2.3 Probability Estimation

• Linear interpolation of distributions
• used equal weights and also EM training
• only included distributions with data
• interpolation weights have "relatively little
  impact"
• (interested in ranking, not exact probabilities)
• "backoff" model lattice of distributions
• organized by specificity
• minimal lattice gives 9/10 of the performance of
  whole system

12
2.3 Probability Estimation
13
2.4 Identification of Frame Element Boundaries

• Finding boundaries handled separately
• probabilities using similar features
• path, target word, constituent head word
• fe whether a constituent is a frame element
• Distributions
• data sparseness/fragmentation problems for some
  feature combinations
• only about 30 sentences available for each target
  word

14
2.5 Generalizing Lexical Statistics

• Lexical features most informative
• 87.4 accuracy for P(rh,pt,t)
• also lowest coverage data sparseness problem
• 3 ways to generalize NPs (4,086 instances)
• automatic clustering (85)
• WordNet-based semantic hierarchy (84.3)
• Bootstrapping (83.2)

15
2.7 Verb Argument Structure

• how to handle different argument signatures for
  the same word?
• He opened the door vs. The door opened
• 2 strategies
• sentence-level feature for frame element groups
• subcategorization feature
• 81.6 performance

16
2.8 Integrating Syntactic and Semantic Parsing

• Collins (1999) form of chart parsing with PCFG
• frame element probabilities applied to full
  parses
• average of 14.9 parses per sentence
• 18 of sentences assigned different parse
• still, performance effect quite small
• not enough available parses per sentence?
  inefficient n-best parsing algorithm

17
2.9 Generalizing to Unseen Data

• Used 18 abstract thematic roles
• Performance using abstract roles 82.1
• Unseen Predicates
• results encouraging linearly interpolated model
  79.4 test set performance
• agrees with linking theory
• FN frames are fine-grained enough
• Unseen Frames
• only 67 frames in FrameNet 1.0
• using a minimal lattice, performance was 51
• Unseen Domains 39.8 (40.9 baseline)
• FN domains for way of organizing the project

18
3. SENSEVAL-3 Task (Litkowski 2004)

• FrameNet 1.1
• 487 frames
• 696 different frame element names (may have
  different meanings in different frames)
• 132,968 annotated sentences (mostly from BNC)
• test set for this task
• 8,002 sentences selected randomly from 40 frames
  (also randomly selected from those with at least
  370 annotations)
• training set
• 24,558 sentence IDs --gt look up in FN
• 2 cases
• Unrestricted case Frame element labeling
• Restricted case Frame element identification
  labeling

19
3. SENSEVAL-3 Task

• scoring measures
• Precision
• correct / attempted
• Recall
• correct / total FE
• Overlap (avg. overlap of all correct)
• overlapping chars / chars in FN answer
• Attempted
• ( FE generated / FE in test set ) 100

20
3.1 Results

• 8 teams, 20 runs
• CLResearch, USaarland, UAmsterdam 1 restricted
  case
• ISI, UTDMoldovan, UTDMorarescu 1 restricted, 1
  unrestricted
• HKPolyU 8 unrestricted cases
• UUtah 2 restricted, 2 unrestricted
• Unrestricted case (classification task)
• avg. precision 0.870
• avg. recall 0.828
• overlap almost identical to precision (slight
  positional errors)
• Restricted case
• avg. precision 0.677
• avg. recall 0.547
• avg. overlap 0.622

21
3.2 University of Amsterdam

• dependency based syntactic analysis important
• added PTB functional tags, non-local dependencies
  w/ TiMBL
• Memory Based Learning based on syntactic paths
  from target word
• features used include
• frame name
• words along the path
• semantic classes of words along the path
• nouns using WordNet
• adverbs, prepositions one of 6 clusters obtained
  from FN using k-means
• POS tags of words along the path
• subcategorization of target word
• others (22 total)
• P86.9, O84.7, R75.2, A86.4

22
3.3 Saarland University

• focused on generalizing using various similarity
  measures for frame elements of different frames
• syntactic nodes are instances for frame-level
  learning
• 2 learning methods
• log-linear Maximum Entropy model
• Memory Based Learning
• generalization techniques
• Frame hierarchy
• peripheral frame elements
• EM-based semantic clustering
• novel features
• preposition (if any)
• whether this path had been seen for a frame
  element in training data
• MaxEnt learner w/ all features and 3 most helpful
  generalization techniques (EM head lemma, EM
  path, Peripherals)
• P65.4, O60.2, R47.1, A72.0
• MBL learner w/ all features, no extra training
  data from generalization
• P73.6, O67.5, R59.4, A80.7

23
3.4 CL Research

• only exploratory participation
• integrate frame semantics into their Knowledge
  Management System
• P58.3, O48.0, R11.1, A19.0

24
3.5 Information Sciences Institute (ISI)

• Maximum Entropy models
• FE identification classify as FE, Target, or
  None
• features for FE identification
• partial path
• logical function external argument, object
  argument, other
• previous class class information of the
  nth-previous constituent (Target, FE or None)
• Semantic role classification
• order relative position of a FE in the sentence
  (0 at left)
• syntactic pattern phrase type and logical
  function of each FE
• Unrestricted P86.7, O86.6, R85.8, A99.0
• Restricted P80.2, O78.4, R65.4, A81.5

25
3.6 University of Texas, Dallas Morarescu

• SVM classifier for each frame using combinations
  of 4 feature sets!
• from Gildea Jurafsky study
• from (Surdeanu 2003)
• content word (for PPs, SBARs, and VPs)
• head word POS
• content word POS
• named entity class of content word
• boolean named entity flags (whether an
  organization, location, person, etc. was
  recognized in the phrase)
• new features
• from (Pradhan 2004)

26
3.6 University of Texas, Dallas Morarescu

• New Features
• human personal pronoun or a hyponym of PERSON
  sense 1 in WN
• support verbs head of the VP that contains the
  target word (nouns, adjectives)
• target type lexical class of the target word
  (verb, noun or adjective)
• list constituent (FEs) phrase types of the other
  FEs
• grammatical function external argument, object,
  complement, modifier, head noun modified by
  attributive adjective, genitive determiner,
  appositive
• list grammatical function grammatical functions
  of the other FEs
• number FEs in sentence
• frame name
• coverage whether there is subparse that exactly
  covers the FE
• coreness core, peripheral, or extrathematic
• subcorpus name of subcorpus (12,456 possible)
  indicates relations between target word and some
  of its FEs

27
3.6 University of Texas, Dallas Morarescu

• Generalization to obtain extended data
• Unrestricted P94.6, O94.6, R90.7, A95.8
• Restricted P89.9, O88.2, R77.2, A85.9

28
3.7 University of Texas, Dallas Moldovan

• SVM classifiers
• divided up training data by target word type
  verb, noun, adjective
• 16 features, 3 sets
• baseline same as GJ
• modified slight modifications
• new
• argument structure phrase structure of the nodes
  along the path between the root node of the
  argument and its head word in a level-order
  fashion.
• distance between argument and target
• PropBank semantic argument captures semantic
  type of argument
• diathesis alternation flat representation of the
  predicate argument structure (as in PropBank)
• Unrestricted P89.8, O89.7, R83.9, A93.4
• Restricted P80.7, O77.7, R78.0, A96.7

29
3.8 Hong Kong Polytechnic University

• frame-level classifiers
• 5 different ML techniques
• Boosting
• most successful
• SVM
• Maximum Entropy
• SNOW (Sparse Network Of Winnows)
• Decision Lists
• various ensembles of these techniques (submitted
  8 runs)
• SVM, Boosting, MaxEnt (binary) got highest scores
• Unrestricted P87.4, O87.3, R86.7, A99.2

30
3.9 University of Utah

• used generative models (Jordan 1999)
• joint probability distribution over targets,
  frames, roles, constituents (basically just a
  1st-order HMM)
• novel features
• depth, height of constituent in parse tree
• constituent word count
• Unrestricted P85.8, O85.7, R84.9, A98.9
• Restricted P35.5, O25.5, R45.3, A127.9

31
4. Applications in MT

• intermediate representation in SMT
• Replacement for expensive hand-crafted domain
  models in KBMT

32
4. Applications in MT

• KANT Domain Model
• used for disambiguating PP attachment
• Use SRL to learn
• Lift Theme the engine Source from the chassis
  Instrument with a hoist .

33
5. Conclusions

• FrameNet useful resource for shallow semantic
  parsing via supervised learning
• Still need word sense / frame disambiguation

34
5. Work in progress

• Work outside FrameNet/SENSEVAL-3
• Comparison with PropBank/CoNLL
• Details of application in KBMT

35
Questions?
