Sleeve meets Aerosol
Klöckner Pentaplast GmbH Co. KG
www.kpfilms.com
Sandra TheilkeSales Marketing Manager Sleeve
Capsule Film
3
Overview

• klöckner pentaplast Facts and Figures

2. Shrink Sleeves A Story of Success
3. From Film to Sleeve The Value Creation Chain
4. Sleeve on Aerosols
5. Questions and Comments
4
Klöckner Pentaplast Facts and Figures

• Global producer of rigid films
• Headquarter in Montabaur, Germany
• Pharma, Food and technical applications
• 4,000 employees worldwide
• 24 production sites worldwide
• Turnover 1.2 bn
• Production capacity of 500,000 to/ year

5
2. Shrink sleeves A story of success

• Eye catching
• Innovative
• Decorative

6
Applications of Shrink Sleeves
Full body Sleeve
Security closures
Promotion packs
7
From Film to Sleeve
Printing
Tubeforming
Application
Shrinking
Film production
Finished Sleeve
8
Film Production

• Prefilm
• 100 250 µm, depending on stretching ratio and
  Sleeve thickness
• PVC - calandered
• PET/OPS - extruded
• 2. Off-line TDO Stretching
• 40 60 µm, depending on neededstiffness.
  Within kp up to 4.2 mprior to slitting
• 3. Slitting according to customer needs

9
Printing

• Common printing methods
• Gravure ( gt 300.000 pieces )
• Flexo ( 15.000 300.000 pieces)
• Offset ( 30.000 1 Mio. pieces )
• Digital ( smaller volumes )
• Reverse printing
• ? Sleeve transparent, printed side is protected
• No corona treatment necessary for PVC PET
  sleeve film
• (probable exception UV-Flexo printing)
• Special shrinkable inks needed
• Distortion of printing design, pre-press art work

10
Printing
11
Tubeforming

• Sleeve formed to an endless tube
• most common Solvent welding

12
What does shrinkage mean?
40 mm
60 Shrinkage
100 mm
13
How to apply Sleeves

• Manual and also automated applications are
  possible. The fully automatic applications work
  on an endless tubing method, while manual
  converting requires a single segment of tubing
  for each bottle .
• Cutting system depending on line speed, low speed
  (lt250 per min) by guillotine knife, high speed by
  blades on rotary axes

14
How to shrink Sleeves

• Shrinkage by either
• infra-red radiation, bad temp. profile, flat
  shrink curve necessary
• hot air tunnel, more homogenous
• steam tunnel, best shrink result

Heat
15
Marketing Advantages of Shrink Sleeves

• Full body decoration
• Shelf impact
• Scuff resistance
• Innovative forms and shapes
• Difficult pack combinations
• Product differentiation

16
Economical and Technical Possibilities

• Economical benefit
• Easy stocking (only one base container)
• Reduction of costs for printing waste (metal ?
  film)
• Reuse of unsold aerosols by re-labelling
• Small series become profitable
• Technical advantages
• No pre-treatment necessary (primer)
• Most sophisticated printing quality (9 colour
  printing)
• Shaped aerosol possible (up to 75)

17
Conclusion
Marketing point of view
Technical point of view
High technical flexibility
Excellent promotional possibilities

Economical point of view
Cost competitive alternative
18
Thank you for your attention!
Your are kindly invited to join us at booth B2 !
