GNOME Diagnostic Mode

1
(No Transcript)
2
GNOME Diagnostic Mode

• Appropriate Mode for Spill Response
• Full Control of all files, settings and
  parameters
• Can change information during spill run
• Complete control of model means results are
  completely the responsibility of the user.

3
New Tool Bar
Main Dialog
Trash Can
Settings
Open File
Save
4
Physical Processes Modeled

• Horizontal Mixing
• Advection
• Steady Flow
• Tides
• Steady Flow Tides
• 3D circulation
• Windage

5
Physical Processes Modeled

• Horizontal Mixing - Random Walk
• Advection
• Steady Flow - Hydrodynamic Model Fields
• Tides - Time Series Hydrodynamic Fields
• Steady Flow Tides
• 3D circulation - 3D models
• Windage - wind(t) time series at point

6
New Left Hand List
Universal Movers
Active Checkbox
Maps
7
Movers
8
Universal Movers
9
Horizontal Mixing
Spill movement after 1 hour. (Horizontal mixing
only)
10,000 cm2/s
100,000 cm2/s
1,000,000 cm2/s
10
Horizontal Mixing Uncertainty
Spill movement after 1 hour. (Horizontal mixing
only)
2x uncertainty
10x uncertainty
11
Windage
Spill movement after 1 hour. (10 knot wind from
West)
1-4 windage
50-100 windage
12
Wind Uncertainty
Spill movement after 1 hour. (10 knot wind from
West, windage 1-4)
13
Maps and Movers
14
Currents
We use separation Of variables U(x,y,t)cu(x,y)
T(t)
The desired velocity and Reference point
together Determine c. C U(x_ref,y_ref,t_ref)
u(x_ref,y_res)T(t_ref)
15
ComponentMover
16
Advection Advection Uncertainty
1 timestep (0.05 hr)
13 timesteps (40 minutes )
17
Spills
18
Lets See What Happens...

• 1. Horizontal Mixing only
• 2. Tides only
• 3. Wind only

• 4. Tides, Winds and Horizontal Mixing
• 5. 4 with gasoline

19
Horizontal Mixing Only
20
Currents and Tides Only
21
Wind Only
W 10 kt
22
Everything!
W 10 kt
23
Everything (product now gasoline)
W 10 kt
24
What next?

• Open up Location Files and see how they work
• Make our own save files by loading and creating
  maps and movers
• Use the save files in a spill scenario
