Introduction to Computer Graphics CS 445 / 645

1
Introduction to Computer GraphicsCS 445 / 645

• Lecture 6
• Geometric primitives andthe rendering pipepline

M.C. Escher Smaller and Smaller (1956)
2
Rendering geometric primitives

• Describe objects with points, lines, and surfaces

• Compact mathematical notation
• Operators to apply to those representations
• Render the objects
• The rendering pipeline
• Appendix A1-A5

HB Figure 109
3
Rendering

• Generate an image from geometric primitives

Rendering
Geometric Primitives
Raster Image
4
3D Rendering Example
What issues must be addressed by a 3D rendering
system?
5
Overview

• 3D scene representation
• 3D viewer representation
• Visible surface determination
• Lighting simulation

6
Overview

• 3D scene representation
• 3D viewer representation
• Visible surface determination
• Lighting simulation

How is the 3D scene described in a computer?
7
3D Scene Representation

• Scene is usually approximated by 3D primitives
• Point
• Line segment
• Polygon
• Polyhedron
• Curved surface
• Solid object
• etc.

8
3D Point

• Specifies a location

9
3D Point

• Specifies a location
• Represented by three coordinates
• Infinitely small

(x,y,z)
10
3D Vector

• Specifies a direction and a magnitude

11
3D Vector

• Specifies a direction and a magnitude
• Represented by three coordinates
• Magnitude V sqrt(dx dx dy dy dz dz)
• Has no location

(dx,dy,dz)
12
Vector Addition/Subtraction

• operation u v, with
• Identity 0 v 0 v
• Inverse - v (-v) 0
• Addition uses the parallelogram rule

v
u
-v
v
u-v
-v
u
13
Vector Space

• Vectors define a vector space
• They support vector addition
• Commutative and associative
• Possess identity and inverse
• They support scalar multiplication
• Associative, distributive
• Possess identity

14
Affine Spaces

• Vector spaces lack position and distance
• They have magnitude and direction but no location
• Combine the point and vector primitives
• Permits describing vectors relative to a common
  location
• A point and three vectors define a 3-D coordinate
  system
• Point-point subtraction yields a vector

15
Coordinate Systems

• Grasp z-axis with hand
• Thumb points in direction of z-axis
• Roll fingers from positive x-axis towards
  positive y-axis

16
Points Vectors

• Points support these operations
• Point-point subtraction Q - P v
• Result is a vector pointing from P to Q
• Vector-point addition P v Q
• Result is a new point
• Note that the addition of two points is not
  defined

17
3D Line Segment

• Linear path between two points

18
3D Line Segment

• Use a linear combination of two points
• Parametric representation
• P P1 t (P2 - P1), (0 ? t ? 1)

P2
P1
19
3D Ray

• Line segment with one endpoint at infinity
• Parametric representation
• P P1 t V, (0 lt t lt ?)

V
P1
20
3D Line

• Line segment with both endpoints at infinity
• Parametric representation
• P P1 t V, (-? lt t lt ?)

V
P1
21
3D Line Slope Intercept

• Slope m
• rise / run
• Slope (y - y1) / (x - x1) (y2 - y1) / (x2
  - x1)
• Solve for y
• y (y2 - y1)/(x2 - x1)x -(y2-y1)/(x2 -
  x1)x1 y1
• or y mx b

22
Euclidean Spaces

• Q What is the distance function between points
  and vectors in affine space?
• A Dot product
• Euclidean affine space affine space plus dot
  product
• Permits the computation of distance and angles

23
Dot Product

• The dot product or, more generally, inner product
  of two vectors is a scalar
• v1 v2 x1x2 y1y2 z1z2 (in 3D)

24
Dot Product

• Useful for many purposes
• Computing the length (Euclidean Norm) of a
  vector
• length(v) v sqrt(v v)
• Normalizing a vector, making it unit-length v
  v / v
• Computing the angle between two vectors
• u v u v cos(?)
• Checking two vectors for orthogonality
• u v 0.0

25
Dot Product

• Projecting one vector onto another
• If v is a unit vector and we have another vector,
  w
• We can project w perpendicularly onto v
• And the result, u, has length w v

26
Dot Product

• Is commutative
• u v v u
• Is distributive with respect to addition
• u (v w) u v u w

27
Cross Product

• The cross product or vector product of two
  vectors is a vector
• The cross product of two vectors is orthogonal to
  both
• Right-hand rule dictates direction of cross
  product

28
Cross Product Right Hand Rule

• See http//www.phy.syr.edu/courses/video/RightHan
  dRule/index2.html
• Orient your right hand such that your palm is at
  the beginning of A and your fingers point in the
  direction of A
• Twist your hand about the A-axis such that B
  extends perpendicularly from your palm
• As you curl your fingers to make a fist, your
  thumb will point in the direction of the cross
  product

29
Cross Product Right Hand Rule

• See http//www.phy.syr.edu/courses/video/RightHan
  dRule/index2.html
• Orient your right hand such that your palm is at
  the beginning of A and your fingers point in the
  direction of A
• Twist your hand about the A-axis such that B
  extends perpendicularly from your palm
• As you curl your fingers to make a fist, your
  thumb will point in the direction of the cross
  product

30
Cross Product Right Hand Rule

• See http//www.phy.syr.edu/courses/video/RightHan
  dRule/index2.html
• Orient your right hand such that your palm is at
  the beginning of A and your fingers point in the
  direction of A
• Twist your hand about the A-axis such that B
  extends perpendicularly from your palm
• As you curl your fingers to make a fist, your
  thumb will point in the direction of the cross
  product

31
Cross Product Right Hand Rule

• See http//www.phy.syr.edu/courses/video/RightHan
  dRule/index2.html
• Orient your right hand such that your palm is at
  the beginning of A and your fingers point in the
  direction of A
• Twist your hand about the A-axis such that B
  extends perpendicularly from your palm
• As you curl your fingers to make a fist, your
  thumb will point in the direction of the cross
  product

32
Cross Product Right Hand Rule

• See http//www.phy.syr.edu/courses/video/RightHan
  dRule/index2.html
• Orient your right hand such that your palm is at
  the beginning of A and your fingers point in the
  direction of A
• Twist your hand about the A-axis such that B
  extends perpendicularly from your palm
• As you curl your fingers to make a fist, your
  thumb will point in the direction of the cross
  product

33
Other helpful formulas

• Length sqrt (x2 - x1)2 (y2 - y1)2
• Midpoint, p2, between p1 and p3
• p2 ((x1 x3) / 2, (y1 y3) / 2))
• Two lines are perpendicular if
• M1 -1/M2
• cosine of the angle between them is 0
• Dot product 0

34
3D Plane

• A linear combination of three points

P3
P2
P1
35
3D Plane

• A linear combination of three points
• Implicit representation
• ax by cz d 0, or
• PN d 0
• N is the plane normal
• Unit-length vector
• Perpendicular to plane

N (a,b,c)
P3
P2
P1
d
36
3D Sphere

• All points at distance r from point (cx, cy,
  cz)
• Implicit representation
• (x - cx)2 (y - cy)2 (z - cz)2 r 2
• Parametric representation
• x r cos(?) cos(?) cx
• y r cos(?) sin(?) cy
• z r sin(?) cz

37
3D Geometric Primitives

• More detail on 3D modeling later in course
• Point
• Line segment
• Polygon
• Polyhedron
• Curved surface
• Solid object
• etc.

HB Figure 10.46
38
Take a breath

• Were done with the primitives
• Now were moving on to study how graphics uses
  these primitives to make pretty pictures

39
Rendering 3D Scenes
40
Camera Models

• The most common model is pin-hole camera
• All captured light rays arrive along paths toward
  focal point without lens distortion (everything
  is in focus)
• Sensor response proportional to radiance

View plane
Other models consider ... Depth of field Motion
blur Lens distortion
Eye position (focal point)
41
Camera Parameters

• What are the parameters of a camera?

42
Camera Parameters

• Position
• Eye position (px, py, pz)
• Orientation
• View direction (dx, dy, dz)
• Up direction (ux, uy, uz)
• Aperture
• Field of view (xfov, yfov)
• Film plane
• Look at point
• View plane normal

View Plane
Up direction
Look at Point
back
View direction
Eye Position
right
43
Moving the camera
Up
Back
Towards
Right
View Frustum
44
The Rendering Pipeline
45
Rendering Transformations

• Weve learned about transformations
• But they are used in three ways
• Modeling transforms
• Viewing transforms (Move the camera)
• Projection transforms (Change the type of camera)

46
The Rendering Pipeline 3-D
Scene graphObject geometry

• Result
• All vertices of scene in shared 3-D world
  coordinate system
• Vertices shaded according to lighting model
• Scene vertices in 3-D view or camera
  coordinate system
• Exactly those vertices portions of polygons in
  view frustum
• 2-D screen coordinates of clipped vertices

ModelingTransforms
LightingCalculations
ViewingTransform
Clipping
ProjectionTransform
47
The Rendering Pipeline 3-D
48
Rendering Transformations

• Modeling transforms
• Size, place, scale, and rotate objects and parts
  of the model w.r.t. each other
• Object coordinates -gt world coordinates

Y
Z
X
49
The Rendering Pipeline 3-D
50
Lighting Simulation

• Lighting parameters
• Light source emission
• Surface reflectance
• Atmospheric attenuation
• Camera response

Light Source
Surface
Camera
51
Lighting Simulation

• Direct illumination
• Ray casting
• Polygon shading
• Global illumination
• Ray tracing
• Monte Carlo methods
• Radiosity methods

Light Source
Surface
N
More on these methods later!
Camera
52
The Rendering Pipeline 3-D
Scene graphObject geometry

• Result
• Scene vertices in 3-D view or camera
  coordinate system

ModelingTransforms
LightingCalculations
ViewingTransform
Clipping
ProjectionTransform
53
Rendering Transformations

• Viewing transform
• Rotate translate the world to lie directly in
  front of the camera
• Typically place camera at origin
• Typically looking down -Z axis
• World coordinates a view coordinates

54
The Rendering Pipeline 3-D
Scene graphObject geometry

• Result
• Remove geometry that is out of view

ModelingTransforms
LightingCalculations
ViewingTransform
Clipping
ProjectionTransform
55
Assignment 2

• Due two and a half weeks from today
• Project description available online
• Well discuss details in class on Monday

56
The Rendering Pipeline 3-D
Scene graphObject geometry

• Result
• 2-D screen coordinates of clipped vertices

ModelingTransforms
LightingCalculations
ViewingTransform
Clipping
ProjectionTransform
57
Rendering Transformations

• Projection transform
• Apply perspective foreshortening
• Distant small the pinhole camera model
• View coordinates a screen coordinates

58
Rendering Transformations

• Perspective Camera
• Orthographic Camera

59
Rendering 3D Scenes
60
Rasterize

• Convert screen coordinates to pixel colors

61
Summary

• Geometric primitives
• Points, vectors
• Operators on these primitives
• Dot product, cross product, norm
• The rendering pipeline
• Move models, illuminate, move camera, clip,
  project to display, rasterize
