Title: Chapter 9


1
Chapter 9 Network Theorems
  • Introductory Circuit Analysis
  • Robert L. Boylestad

2
9.1 - Introduction
  • This chapter introduces important fundamental
    theorems of network analysis. They are
    superposition, Thévenins, Nortons, maximum
    power transfer, substitution, Millmans, and
    reciprocity theorems

3
9.2 - Superposition Theorem
  • Used to find the solution to networks with two
    or more sources that are not in series or
    parallel
  • The current through, or voltage across, an
    element in a linear bilateral network is equal to
    the algebraic sum of the currents or voltages
    produced independently by each source
  • For a two-source network, if the current
    produced by one source is in one direction, while
    that produced by the other is in the opposite
    direction through the same resistor, the
    resulting current is the difference of the two
    and has the direction of the larger
  • If the individual currents are in the same
    direction, the resulting current is the sum of
    two in the direction of either current

4
Superposition Theorem
  • The total power delivered to a resistive element
    must be determined using the total current
    through or the total voltage across the element
    and cannot be determined by a simple sum of the
    power levels established by each source

5
9.3 - Thévenins Theorem
  • Any two-terminal, linear bilateral dc network can
    be replaced by an equivalent circuit consisting
    of a voltage source and a series resistor

6
Thévenins Theorem
  • The Thévenin equivalent circuit provides an
    equivalence at the terminals only the internal
    construction and characteristics of the original
    network and the Thévenin equivalent are usually
    quite different
  • This theorem achieves two important objectives
  • Provides a way to find any particular voltage or
    current in a linear network with one, two, or any
    other number of sources
  • We can concentration on a specific portion of a
    network by replacing the remaining network with
    an equivalent circuit

7
Thévenins Theorem
  • Sequence to proper value of RTh and ETh
  • Preliminary
  • 1. Remove that portion of the network across
    which the Thévenin equation circuit is to be
    found. In the figure below, this requires that
    the load resistor RL be temporarily removed from
    the network.

8
Thévenins Theorem
  • 2. Mark the terminals of the remaining
    two-terminal network. (The importance of this
    step will become obvious as we progress through
    some complex networks)
  • RTh
  • 3. Calculate RTh by first setting all sources
    to zero (voltage sources are replaced by short
    circuits, and current sources by open circuits)
    and then finding the resultant resistance between
    the two marked terminals. (If the internal
    resistance of the voltage and/or current sources
    is included in the original network, it must
    remain when the sources are set to zero)

9
Thévenins Theorem
  • ETh
  • 4. Calculate ETh by first returning all sources
    to their original position and finding the
    open-circuit voltage between the marked
    terminals. (This step is invariably the one that
    will lead to the most confusion and errors. In
    all cases, keep in mind that it is the
    open-circuit potential between the two terminals
    marked in step 2)

10
Thévenins Theorem
  • Conclusion
  • 5. Draw the Thévenin equivalent circuit with
    the portion of the circuit previously removed
    replaced between the terminals of the equivalent
    circuit. This step is indicated by the placement
    of the resistor RL between the terminals of the
    Thévenin equivalent circuit

Insert Figure 9.26(b)
11
Thévenins Theorem
  • Experimental Procedures
  • Two popular experimental procedures for
    determining the parameters of the Thévenin
    equivalent network
  • Direct Measurement of ETh and RTh
  • For any physical network, the value of ETh can
    be determined experimentally by measuring the
    open-circuit voltage across the load terminals
  • The value of RTh can then be determined by
    completing the network with a variable resistance
    RL

12
Thévenins Theorem
  • Measuring VOC and ISC
  • The Thévenin voltage is again determined by
    measuring the open-circuit voltage across the
    terminals of interest that is, ETh VOC. To
    determine RTh, a short-circuit condition is
    established across the terminals of interest and
    the current through the short circuit Isc is
    measured with an ammeter
  • Using Ohms law
  • RTh Voc / Isc

13
9.4 - Nortons Theorem
  • Nortons theorem states the following
  • Any two linear bilateral dc network can be
    replaced by an equivalent circuit consisting of a
    current and a parallel resistor.
  • The steps leading to the proper values of IN and
    RN
  • Preliminary
  • 1. Remove that portion of the network across
    which the Norton equivalent circuit is found
  • 2. Mark the terminals of the remaining
    two-terminal network

14
Nortons Theorem
  • RN
  • 3. Calculate RN by first setting all sources to
    zero (voltage sources are replaced with short
    circuits, and current sources with open circuits)
    and then finding the resultant resistance between
    the two marked terminals. (If the internal
    resistance of the voltage and/or current sources
    is included in the original network, it must
    remain when the sources are set to zero.) Since
    RN RTh the procedure and value obtained using
    the approach described for Thévenins theorem
    will determine the proper value of RN

15
Nortons Theorem
  • IN
  • 4. Calculate IN by first returning all the
    sources to their original position and then
    finding the short-circuit current between the
    marked terminals. It is the same current that
    would be measured by an ammeter placed between
    the marked terminals.
  • Conclusion
  • 5. Draw the Norton equivalent circuit with the
    portion of the circuit previously removed
    replaced between the terminals of the equivalent
    circuit

16
9.5 - Maximum Power Transfer Theorem
  • The maximum power transfer theorem states the
    following
  • A load will receive maximum power from a linear
    bilateral dc network when its total resistive
    value is exactly equal to the Thévenin resistance
    of the network as seen by the load
  • RL RTh

17
Maximum Power Transfer Theorem
  • For loads connected directly to a dc voltage
    supply, maximum power will be delivered to the
    load when the load resistance is equal to the
    internal resistance of the source that is, when
  • RL Rint

18
9.6 - Millmans Theorem
  • Any number of parallel voltage sources can be
    reduced to one
  • This permits finding the current through or
    voltage across RL without having to apply a
    method such as mesh analysis, nodal analysis,
    superposition and so on.
  • 1. Convert all voltage sources to current sources
  • 2. Combine parallel current sources
  • 3. Convert the resulting current source to a
    voltage source, and the desired single-source
    network is obtained

19
9.7 - Substitution Theorem
  • The substitution theorem states
  • If the voltage across and the current through
    any branch of a dc bilateral network is known,
    this branch can be replaced by any combination of
    elements that will maintain the same voltage
    across and current through the chosen branch
  • Simply, for a branch equivalence, the terminal
    voltage and current must be the same

20
9.8 - Reciprocity Theorem
  • The reciprocity theorem is applicable only to
    single-source networks and states the following
  • The current I in any branch of a network, due to
    a single voltage source E anywhere in the
    network, will equal the current through the
    branch in which the source was originally located
    if the source is placed in the branch in which
    the current I was originally measured
  • The location of the voltage source and the
    resulting current may be interchanged without a
    change in current

21
9.9 - Application
  • Speaker system

Insert Fig 9.111
