PowerPointPrsentation

1
KF Coulometry
2
Volumetric / Coulometric Titration
Volumetric Karl FischerIodine is added by
burette during titration. Water as a major
component 100 ppm - 100
3
Titration Cell
4
Coulometry

• Based on the same reaction as volumetric Karl
  Fischer Titration

- Iodine reacts with water 11 - The solvent
methanol is involved in the reaction. - A
suitable base keeps the pH 5 - 7

• But iodine will be produced just in time from
  iodide

2 I-
I2 2 e-
Anodic Oxidation
5
Iodine Production
6
Coulometry Theory

• Definition
• One Coulomb C is the quantity of charge
  transported by an electric current of one Ampere
  (A) during one second (s).
• 1 C 1 A 1 s

To produce one mol of a chemical compound, using
one electron, 96484 C are required.
Charles Augustin de Coulomb
14.6.1736 - 23.8.1806
7
Coulometry Theory

• Definition
• One Coulomb C is the quantity of charge
  transported by an electric current of one Ampere
  (A) during one second (s).
• 1 C 1 A 1 s

Two iodide ions react to iodine,which in turn
reacts with water 2 I ? I2 with
H2O
Therefore 1 mol water (18 g) is equivalent to 2
x 96484 C or 10.72 C / mg water.
To produce one mol of a chemical compound, using
one electron, 96484 C are required.
Absolute method, no standardization!
8
Iodine Production Speed
The iodine production speed depends on

• surface of the electrode
• voltage at the generator electrode
• the conductivity of the electrolyte

Influence to conductivity Samples and additional
solvent as chloroform, etc.
Warning Low conductivity
Normal conductivity ? high current 400
mA ? 2100 µg H2O/min
Very low conductivity ? low current 200
mA ? 1050 µg H2O/min
9
Resolution and Detection Limit
Resolution 0.1 µg water
Detection limit 5 µg water for 5 g sample ? 1
ppm
Measuring range 10 µg - 100 mg water/sample 1
ppm - 5 water
10
Repeatability
coulometry
srel lt 0.5
srel 5 - 0.5
srel gt 5
11
Filling Titration Cell
CatholyteFill in 5 mL catholyte.
Anolyte Fill in 100 mL anolyte
Catholyte
Anolyte
12
Filling Titration Cell
Catholyte always contains water!
Catholyte
? High drift value
Anolyte
13
With or Without Diaphragm
What are the differences?
14
With Diaphragm
With or Without Diaphragm
Without Diaphragm
15
Without Diaphragm
It is possible that iodine can go to the cathode
and convert to iodide.

Prevention

• Small cathode surface ? less chance to contact
  iodine

• bigger sample ? error has no effect

Only a little less accurate for samples with
very low water content.
16
Without Diaphragm
The hydrogen produced at the cathode is a very
good reducing agent.


H
H
? wrong result (too high value)
Not recommended for easily reducible samples
e.g. nitrobenzene, unsaturated fatty acids, etc.
17
Without Diaphragm

• Titration cell easier to clean.
• Long-term drift value more stable.
• Only one reagent.
• Automation of emptying and refilling electrolyte.

• A little bit less accuracy for very small water
  content (lt 50 µg/sample)
• Not recommended
• for easily reducible samples nitro compounds,
  unsaturated fatty acids, etc.

18
Application
With and Without Diaphragm

• With out diaphragm
• a little bit less accuracy for very small water
  content (lt 50 µg/sample)

Examples Transformer oil
Mean n srel µg water /sample with or without
diaphragm 16.3 ppm 6 1.5 34 - 40 with
diaphragm 19.6 ppm 6 5.7 39 - 43 without
diaphragm
19
Without Diaphragm
Titration cell without diaphragm is ideal for

• Hydrocarbons
• Halogenated hydrocarbons
• Alcohols
• Esters
• Ethers
• Acetamides
• Mineral oils
• Edible oils
• Ethereal oils

For this applications the titration cell without
diaphragm is recommended.
20
Analyte
For a complete water determination the sample
must be completely dissolved in the anolyte.
Sample not dissolved, emulsion ? Too low result
Different anolyte for different applications
21
Analyte for samples easy to dissolve
alcohols, ethers, esters, hydrocarbons,
halogenated hydrocarbons, nitro components,
etc. For cell with diaphragm ? with methanol
(HYDRANAL Coulomat AG) (apura - combiCoulomat
frit) ? with ethanol (HYDARANAL Coulomat E)
For cell without diaphragm ? with methanol
(HYDRANAL Coulomat AD) (apura - combiCoulomat
fritless)
22
Analyte for samples not easy to dissolve
edible oils, ethereal oils, ointments,
etc. ? with methanol and octanol For cell with
diaphragm (HYDRANAL Coulomat AG-H) (with 20
hexanol) (apura - combiCoulomat fritless) add
up to 40 octanol or decanol
For cell without diaphragm (HYDRANAL Coulomat
AD) (apura - combiCoulomat fritless) add up to
20 octanol or decanol
23
Conductivity

• Conductivity influences
• Generation of iodine
• Indication of the endpoint
• Conductivity of electrolyte decreases during
  determination
• long chained alcohols (hexanol, octanol,
  decanol), xylene or chloroform can be added.

without diaphragm addition of max. 20
to CombiCoulomat fritless high current at
generator electrode limit 5 - 6 mS/cm before
current breaks down
with diaphragm addition of max. 40 to
CombiCoulomat frit higher robustness
24
Analyte for samples difficult to dissolve
mineral oils, transformer oil, silicon oils,
etc ? with methanol and chloroform For cell with
diaphragm (HYDRANAL Coulomat A) (with 20
chloroform) (HYDRANAL Coulomat AG) (without
chloroform) (apura - combiCoulomat frit)
(without chloroform) add chloroform (maximum
50 )
For cell without diaphragm (HYDRANAL Coulomat
AD) (apura - combiCoulomat fritless) add up to
30 chloroform
25
Analyte for Ketons and Aldehydes
ketones and aldehydes react with methanol ketal
and acetal formation 1 H2O
? special reagent for ketones
For cell with diaphragm (HYDRANAL Coulomat AK
and CG-K) with a long chain alcohol instead of
methanol
For cell without diaphragm (HYDRANAL Coulomat
AK)
Caution with aldehydes! Short chain aldehydes
(for example acetaldehyde) will be oxidized at
the anode. 1 H2O Long chain aldehydes (for
example benzaldehyde) are no problem!
