Soil Mechanics and Geotechnical Engineering

1
Soil Mechanics and Geotechnical Engineering

• CE 435
• Spring 2004
• School of Engineering
• University of Alaska Anchorage

Courtesy of Erik Malvick, UD Davis
2
Geotechnical Engineering

• Implies the application of civil engineering
  technology to the Earth
• Concerned with soil and rock
• New materials in terms of civil engineering
• Difference between soil and rock is arbitrary
• Study of soil and rock as an engineering material
  to be built with or built on

3
Soils

• Consist of
• Particles
• Water
• Air
• Organics
• Other Fluids and Gases

4
Soils

• Consist of
• Particles
• Water
• Air
• Organics
• Other Fluids and Gasses

Typical 3 Phases
5
Soils

• Natural Deposits
• Product of Weathered Rock
• Properties Depend on Geologic History
• e.g. are they residual (formed in place)?
• are they transported (e.g river sediments, wind
  blown)?
• Manmade Deposit
• Compacted Fills
• Earth and Rock-fill Embankment Dams
• Properties depend on Placement Methods

6
Natural Deposit

• Heterogeneous and anisotropic material
• Layered

7
The Typical Geotechnical Engineering Process

• Characterize the Site
• Review of geology
• On-site exploration
• Collection of samples

8
(No Transcript)
9
Geot. Engrg. Process Cont.

• Evaluate Soil Properties
• Laboratory Tests
• Field Tests
• Properties are often Approximate
• Small samples
• Disturbance
• Continually changing

10
(No Transcript)
11
Geot. Engrg. Process Cont.

• Analyses
• Determine important properties
• Account for uncertainties (Factor of Safety)
• Judgment (Experience)
• Do the numbers make sense?
• Safety
• Build It
• Monitor construction process
• After Construction Monitoring
• Watch for changes
• Have contingencies ready for unforseen
  circumstances

12
Typical Projects
Grading and Drainage
13
Foundations
14
Fills Dams
15
Retaining Walls
16
Groundwater Flow Soil / Water Chemistry Contaminat
ion containment and cleanup
17
Slope Stability
18
Earthquake Effects
19
Earthquake Effects
20
Ground Improvement
21
Ground Improvement
22
Conclusions

• Soil Mechanics leads to many possible projects
• This class provides the fundamentals to begin
  learning the concepts and projects shown before
• A basic understanding of soil mechanics is
  necessary for all civil engineers

23
Useful Resources

• Geotechnical Photo Album
• cee.engr.ucdavis.edu/faculty/boulanger/geo_photo_a
  lbum/index.html
• Course website
• http//www.engr.uaa.alaska.edu/soe/Courses/ce435/i
  ntro.htm
