Keystone D5 DMTS Broadband Live

1
Keystone D5 DMTSBroadband Live

• May 8, 2006
• The roadmap contained herein to be reviewed is
  for discussion purposes only to demonstrate our
  thoughts behind the evolutionary development of
  this product offering. ARRIS is not obligated to
  develop the software or hardware with the
  features and functionality discussed in these
  materials. This roadmap is subject to change.

2
D5 DMTS Product Roadmap
2Q06
2Q05
3Q05
4Q05
1Q06
IS Sept.
RTS Jan.
IS In Service RTS Ready to Ship
Release 2.0.0

• EdgeQAM 48 Channels, 4 Channel Bonding

FTA Mar.
IS May
Release 2.0.2

• DVB Simulcrypt
• PSI / SI Table Injection
• SPTS MPTS Remux
• Digital Simulcast / Broadcast Support
• IGMPv2
• D5 Nodal Element Manager interface

3
D5 DMTS Product Roadmap
2Q07
2Q06
3Q06
4Q06
1Q07
IS Jun.
RTS Aug.
IS In Service RTS Ready to Ship
Release 2.1

• WAN (DTI RJ45 Support)
• QAM - DRFI compliant
• SPTS and MPTS Stream Replication
• SPTS/MPTS GbE in/out w/ Encryption

IS TBD
RTS TBD
Release 3.0

• CableLabs M-CMTS support
• DEPI
• OSSI
• ERMI
• DTI
• DRFI
• DOCSIS 3.0
• PacketCable Multimedia 2.0
• 1 GHz tuning option
• C4 M-CMTS Interoperability
• DPI Digital Program Insertion SCTE 30/35

4
D5 DMTS Release 2.0.0

• Whats New
• Edge QAM
• Up to 48 QAMs per 2U chassis
• Support for Annex A and B
• 4 Channel Bonding per F connector

RTS 1/20!
Market Segment Digital Video VoD Regions
Europe, North America
5
D5 DMTS Release 2.0.2

• Whats New
• Simulcrypt/CAS (Nagra, Conax)
• SPTS MPTS Replication
• PSI / SI Table Injection
• SPTS MPTS Remux
• Multicast Support
• CAS Broadcast Support
• IGMPv2
• Ortikon EIS Interface
• D5 Nodal Element Manager interface
• Annex C

Market Segment Digital Video VoD Regions
All
6
D5 DMTS Release 2.1

• Whats New
• SPTS Replication
• WAN Virtex 4 (DTI RJ45 Support)
• SPTS/MPTS in/out Encryption

Market Segments VoD, Broadcast, Converged IP
Regions All
7
D5 DMTS Release 3.0

• Whats New
• CableLabs M-CMTS support
• DEPI
• OSSI
• ERMI
• DTI
• DRFI
• DOCSIS 3.0
• PacketCable Multimedia 2.0
• 1 GHz tuning option
• C4 M-CMTS Interoperability
• DPI Digital Program Insertion SCTE 30/35

Market Segments VoD, Broadcast, Converged IP
Regions All
8
Keystone D5 Nodal Manager Release 2.0.2
Low cost standalone platform to provide basic
nodal provisioning and troubleshooting
functionalities for D5 DMTS

• Whats New
• Fault Management
• Alarms and events log
• Configuration Management
• Inventory auto-detection
• Device panel view
• Input/output configuration
• Performance Management
• Statistics and counters
• DVB-SI Configuration and Generation

Market Segment Converged IP Regions All
