Windows Internet Name Service

1
Chapter 5

• Windows Internet Name Service

2
Learning Objectives

• Provide an overview of NETBIOS naming and NetBIOS
  name resolution
• Describe the features of the Windows Internet
  Name Service (WINS)
• Explain in detail the new features in the Windows
  2000 implementation of WINS
• Install WINS

continued
3
Learning Objectives

• Configure replication between WINS servers
• Configure a client to use WINS
• Manage, monitor, and troubleshoot WINS

4
NetBIOS Naming

• NetBIOS
• Session-level API developed to provide high-level
  applications with easy access to lower-level
  networking protocols
• Uses a flat namespace
• Names can only be used once per machine on a
  network
• NetBIOS scope can overcome this limitation
• NetBT
• NetBIOS using TCP/IP as its lower-level
  networking protocol stack
• Common abbreviation for NetBIOS over TCP/IP

5
Unique and GroupNetBIOS Names

• Unique NetBIOS names
• 16 bytes long
• Identify both the computer name and certain
  services running on a computer
• Example win2kdc01
• Group NetBIOS names
• Identify multiple computers
• Example Domain controllers in a domain

6
Common Unique andGroup NetBIOS Name Types
7
NetBIOS Naming

• Issue the nbtstat n command after the command
  prompt to view a list of all the services and
  their corresponding NetBIOS names

8
NetBIOS Name Resolution
9
How Node Types Determine Name Resolution Methods
10
NetBIOS Name Resolution

• Easiest way to set the node type for a client is
  to assign it as a DHCP scope option
• Set the 044 option to the IP addresses of WINS
  servers you want clients to use
• Set the 046 or node type to 0x8, the value for
  h-node

11
NetBIOS Name Resolution

• Use h-node on your network to ensure that clients
  first attempt to use directed communi-cation with
  the WINS server and only use broadcast as a
  secondary methods for name resolution

12
NetBIOS Name Resolution

• By default, all Windows 2000 clients are
  configured to use the Lmhosts file if it is
  present and no other NetBIOS name resolution
  method can provide resolution

13
NetBIOS Name Resolution
14
Lmhosts Extensions
15
Lmhosts Files

• Main drawback administrative overhead
  associated with maintaining Lmhosts files
• As static databases, they require changes
  whenever new computers are added to the network
  or when IP addresses change
• To meet the need for a better method of
  alleviating some of this administration,
  Microsoft created the Windows Internet Name
  Service

16
Windows Internet Name Service

• Allows clients to register their NetBIOS name to
  IP address mappings in a dynamic database hosted
  on a WINS server
• Provides a dynamic method to register NetBIOS
  names to IP addresses
• Allows clients to use directed communica-tions to
  a WINS server instead of broadcasts

17
Tasks a Client Can Access WINS Servers to Perform

• NetBIOS name registration
• NetBIOS name renewal
• NetBIOS name release
• NetBIOS name query

18
NetBIOS Name Registration

• Sent by WINS clients to WINS servers to ask for
  registration of a particular NetBIOS name with an
  IP address

19
NetBIOS Name Renewal

• Sent by WINS clients to request that the WINS
  server extend the NetBIOS name to IP address
  mapping
• Normally occurs halfway through the TTL

20
NetBIOS Name Release

• Sent by WINS clients to direct the WINS server to
  terminate the dynamic mapping of a NetBIOS name
  to an IP address

21
NetBIOS Name Query

• Used by WINS clients to query WINS servers for
  information about a particular NetBIOS name
• Used to find NetBIOS name to IP address mappings

22
Name Query Response

• Response sent from a WINS server to the WINS
  client, either informing the client of the
  NetBIOS name to IP address resolution or of
  failure to achieve a resolution

23
Name Query and Name Query Response
24
WINS in Windows 2000

• Most new features are attempts to make management
  and use of the WINS server easier
• Other features decrease the time used for WINS
  replication (process of replicating WINS
  databases between multiple WINS servers)
• Major new features
• Automatic Replication Partners
• Persistent connections
• Manual tombstoning

25
Automatic Replication Partners
26
Installing WINS

• Pre-installation requirements
• Configure server with a static IP address, subnet
  mask, and default gateway
• Configure WINS settings in the Internet Protocol
  Properties (TCP/IP) to point to servers own IP
  address
• Determine how many WINS servers the network needs
• Two minimum one as primary and another as
  backup
• Primary and back-up servers should be able to
  support a network of 10,000 clients

27
Installing WINS

• Open the Network and Dial-up Connections dialog
  box

28
Installing WINS
29
Installing WINS

• Open the Windows Optional Networking Components
  Wizard and Networking Services dialog boxes

30
Installing WINS
31
Installing WINS

• Click WINS and click OK to install the WINS
  server and make it available under Administrative
  Tools

32
Installing WINS
33
Installing WINSActive Registrations
34
Installing WINSActive Registrations
35
Configuring WINS Server

• Use default configuration clients automatically
  register NetBIOS names and IP addresses with the
  WINS server
• To provide a WINS entry for a non-WINS client
  such as a UNIX box, add a static entry to the
  WINS database

36
Configuring WINS Replication

• Required in a network with more than one WINS
  server, otherwise clients on the network may not
  be able to resolve certain NetBIOS names
• All WINS servers should be configured to perform
  replication with one another

37
WINS Replication
38
Configuring WINS Replication

• Replication partners can be set up automatically
  via multicast
• In most cases, you need to configure replication
  manually to ensure that it meets the needs of the
  network
• Types of WINS replication
• Pull
• Push

39
Pull and Push Replication

• Pull replication
• Occurs at a preset time interval
• Used with slow WAN links
• Push replication
• Occurs after a predetermined number of changes to
  the database occur
• Used with fast connections between replication
  partners
• Most WINS servers are configured as both push and
  pull replication partners to ensure that the
  databases for each server remain constant

40
Configuring WINS Replication

• Open the WINS console and right-click the
  Replication Partners folder

41
Configuring WINS Replication

• Type the IP address of the WINS server that you
  wish to configure as a replication partner and
  click OK to continue
• Repeat on both servers that you wish to set up as
  replication partners

42
Configuring WINS Replication
43
Configuring Advanced Properties for WINS
Replication

• Set replication parameters
• Interval for pull replication
• Number of updates before push replication is
  triggered
• Set persistent connection settings

44
Configuring Clients for WINS

• Easiest way
• Set the DHCP 044 and 046 scope options mentioned
  earlier in NetBIOS Name Resolution
• Guarantees that all DHCP-enabled clients receive
  the IP address of WINS servers on your network
  and the correct node type for NetBIOS name
  resolution

45
Configuring Clients for WINS

• On clients with static IP addresses, configure
  WINS setting in the Advanced properties, WINS tab
  of the Advanced (TCP/IP) settings dialog box
• Configure primary and secondary WINS server
• Enable/disable use of Lmhosts file
• Enable/disable NetBIOS over TCP/IP

46
Configuring Clients for WINS

• For all static clients, you must access the WINS
  tab and manually type WINS server information

47
Managing, Monitoring, and Troubleshooting WINS

• Most troubleshooting stems from incorrectly set
  WINS entries on the client or incorrect DHCP
  scope options on the DHCP servers
• Use Event Viewer to discover WINS errors
• Use WINS console most important WINS
  management, configuration, and troubleshooting
  tool for further information about WINS server
  service (eg, Back Up Database)
• May need to compact the WINS database

48
WINS Server Statistics Window
49
Server Properties Dialog Box
50
Chapter Summary

• NetBIOS naming
• Windows Internet name service
• WINS in Windows 2000
• Installing WINS
• Configuring WINS replication
• Configuring clients for WINS
• Managing, monitoring, and troubleshooting WINS
