WaveMaker Visual AJAX Studio 4'0 Training

1
WaveMaker Visual AJAX Studio 4.0 Training

• Custom Queries

2
Creating Custom Queries

• When you need to do more complex searches then
  supported by views
• When you need to do more then insert, update and
  delete in a LiveForm
• When you want to use more advanced SQL parameters
• Example Get distinct values from a column

3
How to Create a Custom Query

• From the Go To Menu select Queries or click the
  Queries Icon
• Query is created using HQL
• Very similar to SQL
• Good online tutorials for reference
• http//www.roseindia.net/hibernate/index.shtml

4
Creating a Query

• Name and Comment your Query
• Write your Query
• Identify any input parameters
• A sample Query is provide

5
Testing Queries

• Ability to test queries at design time
• Enter input values in as Test Parameters Values

6
Query Example1

• Comparing against 1 or more values
• Example Give me the countries for the following
  2 customers
• select customerName, country from Customers _a
  where customerName in (s1, s2)
• select customerName, country from Customers _a
  where customerNames1 or customerName s2
• Create 2 input parameters of type string
• To pass multiple values into the test parameters
• Pass comma separated values, no quotes
• Example Atelier graphique, Mini Wheels Co.

7
Query Example 2

• Comparing against 1 list of values
• Example Give me all countries for the following
  customers (1 more in a list)
• select customerName, country from Customers _a
  where customerName in (customerList)
• Create 1 input parameters of type string
• Select the list checkbox
• To pass a list of variables of unknown length
  into the TestBind parameters
• Use Brackets and seperate values with a comma, no
  quotes
• Example Atelier graphique, Mini Wheels Co.

8
Query Example 3

• Getting Distinct Values
• Example Give me all distinct countries from the
  customer table
• select distinct country, count(country) from
  Customers group by country
• Must return more then 1 column even though it is
  not needed

9
Custom Query Tips

• Table names and column names are case sensitive
• Check the LiveTable datamodel for correct syntax
• If using aliases use all lower case
• from customers _cust not from customer _Cust
• Notice the returns a single result checkbox
  under query definition
• Multiple results will return when testing but at
  runtime errors may be thrown
• You must return more then 1 column.

10

• Questions?

11
Exercise 16

• Create a custom query to return distinct values
• Test the query
