Title: Presented by M G Pia (CERN, INFN)


1
  • Presented by M G Pia (CERN, INFN)
  • Authors
  • P Truscott F Lei
  • (Defence Evaluation Research Agency, UK)
  • C Ferguson R Gurriaran (University of
    Southampton, UK)
  • P Nieminen E Daly
  • (ESA /ESTEC)
  • J Apostolakis, S Giani, M G Pia (CERN,
    Switzerland)
  • L Urban (KFKI Hungary)
  • M Maire (LAPP, France)

2
Principal Sources of Radiation in theNear-Earth
Environment
Extra-Solar System ?-rays, X-rays
Galactic Cosmic Rays (protons heavier
nuclei) 1MeV/nuc - 100s GeV/nuc
Solar Protons Heavier Ions (up to 100
MeV/nuc) X-rays, ?-rays
Trapped Particles protons (1 MeV - 100s
MeV) electrons (1 keV - several MeV)
3
  • The Environment
  • Spacecraft are required to operate in a severe,
    energetic radiation environment comprising
    cosmic-ray protons and heavier nuclei, trapped
    protons and electrons that form the Van Allen
    radiation belts, and solar particles emitted
    during flare events and coronal mass ejections.
    The interactions of these particles in spacecraft
    materials not only attenuates the radiation, but
    may also give rise to secondary particles (e.g.
    protons, neutrons, bremsstrahlung) that may have
    higher fluxes and/or greater effects than the
    primaries.
  • The Effects
  • The radiation environment can give rise to a
    range of deleterious effects in spacecraft
    microelectronics, solar arrays, sensors and
    specialised (mission-specific) instruments such
    as ?-ray detectors
  • Total ionising dose
  • Atomic displacement (bulk) damage
  • Single event effects (SEE), in which ionisation
    by single particles can temporarily upset or
    destroy integrated circuits
  • Induced radioactivity and enhanced background
    rates in sensors

4
  • Applications for Radiation Transport Models
  • Spacecraft instrument design/operation for
    mitigation of effects Radiation transport
    models may be used to predict the effects of the
    environment on the systems making up the
    spacecraft platform and payload, and to allow
    designers to develop and optimise hardening
    strategies. The planning of spacecraft
    operations must take into consideration
    variations in the environment during the mission
    (such as solar particle events) and radiation
    transport models help quantify the threat to
    instruments and the effectiveness of possible
    operational measures.
  • Trouble-shooting Such tools are also valuable
    for trouble-shooting in-flight anomalies
    experienced in spacecraft that have already been
    launched, and for assessing possible mitigation
    strategies.
  • Optimise detector/sensor designs Simulation of
    radiation transport is necessary for optimising
    the design of radiation detectors, such as those
    used for ?-ray or X-ray missions.
  • Data interpretation The interpretation of data
    from such instruments may also be critically
    dependent upon model results, e.g. predictions of
    induced X-ray yields from asteroids/moons are
    required to derive composition from detected
    X-ray fluxes.

5
Spacecraft Missions and Radiation Effects
6
  • Geant4 Overview and Features (see CHEP 2000 Paper
    140)
  • The result of a world-wide collaboration of 100
    scientists and computer engineers from 40
    institutes
  • Latest release is Geant4.1.0 issued 8th Dec 99
  • Monte Carlo simulation for nuclei, hadrons,
    leptons and bosons in 3D
  • Object Oriented design (implemented in C)
  • Geant4 Adaptive GUI available
  • Excellent facilities for visualisation (essential
    for geometry debugging)
  • Comprehensive range of physical processes already
    implemented as well as planned
  • Fast simulation mode - response of a volume may
    be parameterised based on empirical or simulation
    data
  • Facilities for event biasing
  • Geometry can be constructed from solid simple
    volumes or breps
  • Defined by user-written C
  • STEP interpreter for geometry input from CAD
    tools

7
Applications of Geant4 Physical Processes
Hadron-nucleon or hadron-nuclear
Parameterised
Parton-string (gt5GeV)
Cosmic ray nuclei and secondaries
Kinetic (10MeV - 10GeV)
Trapped protons and secondaries
QMD models
Pre-compound (2-100 MeV)
Secondary neutrons, including atmospheric/planetar
y albedo neutrons
Low-energy neutron (thermal - 20 MeV)
Induced radioactive background calculations
Isotope production
Nuclearde-excitation
Evaporation (Agt16)
Treatment for seondaries from cosmic ray nuclei
and trapped protons, esp. important in
calculation of single event effects
(microdosimetry)
Fermi break-up (A?16)
Fission (A?65)
Multi-fragmentation
Photo-evaporation (ENSDF)
Induced and natural radioactive backgrounds
Radioactive decay (ENSDF)
8
Applications of Geant4 Physical Processes
Electromagnetic
Ionisation
Important for treatment of SEE (microdosimetry
from nuclear recoil and evaporation prods)
Multiple scattering
?-ray production
Trapped electron effects
Bremsstrahlung
annihilation
Photo-electric effect
Compton scattering
Rayleigh scattering
Pair-production
Atomic relaxation
Induced and natural radioactive backgrounds
9
Space Specific GEANT4 Modules
  • Clearly Geant4 offers a very comprehensive
    environment to specify a geometry, perform
    particle tracking, and model a wide range of
    physical interaction processes. Furthermore the
    object-oriented design allows relatively
    straightforward extension of the toolkit through
    class inheritance.
  • The particular requirements of spacecraft
    radiation effects studies have led the European
    Space Agency to sponsor the development of a
    number of space-specific components. These are
    now discussed.

10
  • MGA for Geant4 STEP Interface
  • The CAD STEP (Standard for Exchange of Product
    Data - ISO 10303) interface provides an efficient
    method of defining spacecraft system geometries
    for Geant4, especially since the use of CAD tools
    is widespread in the aerospace industry. In
    addition, a number of commercial CAD tools
    already have STEP interfaces.
  • However, the protocol (AP203) of STEP does not
    allow the association of materials information
    with each volume. The Materials and Geometry
    Association (MGA) tool is a Java-based utility to
    attribute material information and visualisation
    properties with volumes in a STEP file. This can
    be achieved manually by the user through the
    Graphical User Interface, or automatically if the
    CAD engineer uses pre-defind meta-data
    information in the PRODUCT records for each
    volume in the STEP file. The user can draw upon
    a database of standard spacecraft materials, or
    create her own materials by defining elemental
    and nuclide composition. Once this association
    is complete, both the STEP and MGA files are read
    by Geant4 to obtain a complete description of the
    geometry.

11
Evaluation of CAD Tools
  • CAD Product Suitability for G4 based
  • ProEngineer (Parametric) yes
  • Euclid (Matra Datavision) yes (with translator)
  • Catia (IBM Dassault) yes
  • MicroStation (Bentley) translator released ?
  • AutoCAD (AutoDesk) yes (R14.01 )
  • I-deas (SDRC) yes

12
MGA Data Entry Windows
Volume, material and Vis attribute association
Materials specification window
Creation of internal databases (materials and
colours)
13
  • Low-Energy Electromagnetic Interactions
  • Previously, the minimum energies for accurate
    ?-ray and electron transport in Geant3 and in EGS
    and ITS was 10 keV and 1 keV respectively. A key
    requirement identified by ESA for a general space
    radiation tool was that it treat X-ray
    fluorescence from the surfaces of asteroids and
    moons. This necessitates cut-offs of 250 eV. To
    achieve this, new processes (for low-energy
    Compton, Rayleigh, photo-electric effect,
    Bremsstrahlung, ionisation and fluorescence) have
    been introduced which utilise data
    parameterisations to evaluated data from Lawrence
    Livermore National Laboratory (EPDL97, EEDL and
    EADL).
  • It is planned to also extend the low-energy EM
    physics for positrons to below 1 keV, as well as
    treat Auger electron production.
  • The physics for ionisation caused by low-energy
    hadrons, ions has been extended using
    parameterisations to particle range and stopping
    power data from Ziegler and ICRU, permitting
    accurate tracking down to 1 keV. Accurate
    treatment of these physical processes is
    essential for simulating single event effects in
    microelectronics as a result of proton- or
    neutron-nuclear interactions. A similar extension
    is in progress for antiprotons.

14
Low-Energy Electromagnetic Interactions
15
  • Radioactive Decay Module
  • Long-term (gt1?s) radioactive decay induced by
    spallation interactions can represent an
    important contributor to background levels in
    spaceborne ?-ray and X-ray instruments, as the
    ionisation events that result often occur outside
    the time-scales of any veto pulse. The
    Radioactive Decay Module (RDM) treats the nuclear
    de-excitation following prompt photo-evaporation
    by simulating the production of ?, ?-, ?, ? and
    anti-?, as well as the de-excitation ?-rays. The
    model can follow all the descendants of the decay
    chain, applying, if required, variance reduction
    schemes to bias the decays to occur at
    user-specified times of observation. The
    branching ratio and decay scheme data are based
    on the Evaluated Nuclear Structure Data File
    (ENSDF), and the existing Geant4
    photo-evaporation model is used to treat prompt
    nuclear de-excitation following decay to an
    excited level in the daughter nucleus. (Atomic
    de-excitation following nuclear decay is treated
    by the Geant4 EM physics processes.)
  • The RDM has applications in the study of induced
    radioactive background in space-borne detectors
    and the determination of solar system body
    composition from radioactive ?- ray emission.

16
  • Sector Shielding Analysis Tool
  • It is often possible to obtain a first-order
    estimate of the radiation dose received within a
    spacecraft as a function of location using shield
    distribution data for that location in
    conjunction with dose-versus-depth information.
    The Sector Shielding Analysis Tool can provide
    shield distribution data using particle tracking
    facilities in Geant4. The so-called geantino
    particle is used to determine the path-lengths
    between material boundaries for rays emanating
    from a user-defined point. The

user is able to define the limits of the solid
angle analysed (the direction window) based on an
arbitrary co-ordinate system, and then sub-divide
divisions in this solid angle. Geantino rays can
be sampled randomly within each sub-division so
that the shielding can be assessed as a function
of ? and ?. Analysis output can be provided as a
function of material in units of g/cm2, cm or
radiation lengths, or for overall thickness
irrespective of material type.
17
  • General Source Particle Module
  • The space radiation environment is often quite
    complex in energy and angular distribution, and
    requires sophisticated sampling algorithms. The
    General Source Particle Module (GSPM) allows the
    user to define his source particle distribution
    (without the need for coding) in terms of the
    following
  • Spectrum linear, exponential, power-law,
    black-body, or piece-wise linear (or logarithmic)
    fit to data
  • Angular unidirectional, isotropic, cosine-law,
    or arbitrary (user-defined)
  • Spatial sampling from simple 2D or 3D surfaces,
    such as discs, spheres, boxes, cylinders
  • The GSPM also provides the option of biasing the
    sampling distribution. This is advantageous, for
    example, for sampling the area of a spacecraft
    where greater sensitivity to radiation effects is
    expected (e.g. where radiation detectors are
    located) or increasing the number of high-energy
    particles simulated, since these may produce
    greater numbers of secondaries.

18
Summary
  • Geant4 is a new-generation toolkit for Monte
    Carlo particle simulation
  • Unlike other codes Geant4 has been developed to
    provide comprehensive particle simulation in a
    single tool, but due to its OO design, it permits
    easy extension of physics modelled . if required
  • The Geant4 Toolkit has wide applications
    including not only HEP, but also space and
    medicine
  • Geant4 fulfils the functions required for space
    radiation effects studies and will be the basis
    of ESAs next generation of spacecraft radiation
    shielding tools

19
Visit Our Web Sites
  • ESA/DERA/UoS Spacecraft Radiation Shielding and
    Effects
  • http//www.estec.esa.nl/wmwww/WMA/research/Shieldi
    ng_tools.html http//www.space.dera.gov.uk/space_e
    nv/geant_mn.html
  • Geant4 collaboration at CERN
  • http//wwwinfo.cern.ch/asd/geant4/geant4.html
Write a Comment
User Comments (0)
About PowerShow.com
