Eclipse with CDT, Eclipse plug-in

• ???
• 2009/02/13

2
Outline

• Eclipse and CDT introduction
• Build our environment
• Eclipse plug-in
• Wizard

3
ECLIPSE AND CDT
4
Eclipse Introduction

• Eclipse is a software platform comprised of
  extensible application frameworks, tools and
  runtimes for software development and management
• Primarily written in Java
• Primary use is as an integrated development
  environment (IDE)
• In its default form it is meant for Java
  developers, consisting of the Java Development
  Tools (JDT)
• Users can extend its capabilities by installing
  plug-ins written for the Eclipse software
  framework

5
Eclipse Architecture

• Eclipse Rich Client Platform (RCP)
• Equinox OSGi
• a standard bundling framework
• Core platform
• boot Eclipse, run plug-ins
• Standard Widget Toolkit (SWT)
• a portable widget toolkit
• JFace
• viewer classes to bring model view controller
  programming to SWT, file buffers, text handling,
  text editors
• Eclipse Workbench
• views, editors, perspectives, wizards

6
Eclipse Structure
7
CDT Introduction

• CDT
• C/C Development Tools
• Provide a fully functional C and C IDE for the
  Eclipse platform
• Function
• C/C Editor
• basic functionality, syntax highlighting, code
  completion etc.
• C/C Debugger
• APIs Default implementation, using GDB
• C/C Launcher
• APIs Default implementation, launches and
  external application
• Parser
• Search Engine
• Content Assist Provider
• Makefile generator

8
CDT Architecture
9
BUILD OUR ENVIRONMENT
10
Build Our Environment

• Install JDK
• http//java.sun.com/javase/downloads/index.jsp
• Install Eclipse platform
• http//download.eclipse.org/eclipse/downloads/
• The Latest Release is 3.4.1 (Ganymede)

11
Build Our Environment (Cont)

• Install CDT
• Use eclipse software update to install
• Download through software update dialog
• Download from the CDT website
• http//www.eclipse.org/cdt/downloads.php
• Choose the version according to the using
  eclipses version

12
Build Our Environment (Cont)

• Download through software update dialog
• Help -gt Software Updates

13
Build Our Environment (Cont)

• Expend Ganymede Update Site
• Choose C and C Development

14
Build Our Environment (Cont)

• Download from website
• Download zip file according to Eclipse version
• Help -gt Software Updates
• Click Add Site to add zip file to source

15
Build Our Environment (Cont)

• Choose the zip file source and install

16
Build Our Environment (Cont)

• Install Win32 GNU Toolchain
• MinGW
• http//www.mingw.org/
• allow one to produce native Windows programs that
  do not rely on any 3rd-party C runtime DLLs
• MSYS
• A contraction of "Minimal SYStem
• POSIX-like command line interpreter system
• GDB
• http//sourceforge.net/project/showfiles.php?group
  _id2435package_id20507
• The MinGW setup program does not install the gdb

17
Demo

• Using CDT to compile
• No makefile (CDT automatically create)
• With makefile
• Using CDT to debug

18
ECLIPSE PLUG-IN
19
Eclipse Plug-in Architecture

• Workbench and Workspace
• Two indispensable plug-ins of the Eclipse
• Provide the extension points used by most of the
  plug-ins
• A plug-in requires an extension point to plug
  into in order to function

20
Eclipse Plug-in Architecture (Cont)
21
Eclipse Plug-in Architecture (Cont)

• The Workbench extension points
• Allow plug-ins to contribute behaviors to
  existing views and editors or to provide
  implementations for new views and editors
• The Workspace extension points
• Allow plug-ins to interact with resources,
  including projects and files

22
Eclipse Plug-in Model

• A plug-in is described in an XML manifest file,
  called plugin.xml, residing in the plug-in's
  folder
• The manifest file describes the content of the
  plug-in to the Eclipse runtime
• plug-in identifier, version, etc.

23
Eclipse Plug-in Model (Cont)

• The manifest file contains four main sections
• Dependencies
• listing all the plug-ins required by the plug-in
• Extensions
• declaring all the functionalities by extending
  other plug-ins' extension points
• Runtime
• shows all the packages that your plug-in makes
  visible to other plug-ins, libraries and folders
  that constitute the plug-in runtime classpath
• Extension Points
• declaring new function points defined by this
  plug-in which other plug-ins can extend

24
Dependency

• When a plug-in is dependent on other plug-ins for
  its functions, the dependency is specified via a
  requires element in the plug-in manifest file

25
Extensions

• A plug-in can contribute new functionality to the
  platform by adding an extension to extension
  points declared by other plug-ins
• The extension declaration must follow the schema
  defined by the extension point it contributes to

26
Extension Points

• Extension points define new function points for
  the platform that other plug-ins can plug into
• Defining a new extension point requires the
  writing of a schema, which all clients of the
  extension point must then follow in order to be
  processed correctly at runtime

27
Develop a Plug-in

• The easiest way to create a plug-in is to use the
  Plug-in Development Environment (PDE)
• PDE provides a set of tools that assist the
  developer in every stage of plug-in development
  from genesis to deployment

28
Configuring PDE

• In order for PDE to provide a development
  environment that is identical to the runtime
  environment in which the plug-in will be later
  deployed, one needs to specify the Target
  Platform
• Target platform refers to the set of plug-ins
  with which the plug-in being developed will be
  deployed

29
Configuring PDE (Cont)

• At runtime, most plug-ins require other plug-ins
  to be on their class path in order to run
  properly
• At development time, a plug-in similarly requires
  that all the libraries for its required plug-ins
  be on its build path in order for its code to
  compile without errors

30
Configuring PDE (Cont)
31
Demo

• Create a new plug-in project
• Using template
• No template

32
WIZARD
33
Wizard Components

• Wizard has two components
• Main wizard
• Initialize, finalize, and handle all pages
• Wizard page
• Page layout
• Event handle

34
Main Wizard

• void addPages()
• Adding pages to a wizard
• void init()
• Initializing widgets on wizard pages
• ?boolean canFinish()
• Pages can finish or not
• boolean performFinish()
• What to do when finishing

35
Wizard Page

• void createControl()
• Create widgets on page
• ?void handleEvent()
• Handle event
• ?IWizardPage getNextPage()
• Setting the next page
• ?boolean canFlipToNextPage()
• Can go to next page or not

36
Demo

• Create a wizard plug-in project
• A wizard example
