Salem Nationalease

1
Heavy Duty Performance in a Medium Package
2
Agenda - MaxxForce 10

• Why Choose the MaxxForce 10?
• MaxxForce 10 Construction
• 2007 Technology and Improvements

3
Why Choose the MaxxForce 10?

• MaxxForce 10 Defining Attributes
• Heavy Duty Performance
• Medium Duty Price
• Low Engine Weight

4
Why Choose the MaxxForce 10?

• Heavy Duty Performance
• Power and Torque for Class 8 Applications

1150 lbft 350 HP
5
Why Choose the MaxxForce 10?

• Heavy Duty Performance
• Engine Braking performance comparable to
  traditional heavy engine Jake Brakes without
  the noise!

Brake noise at 2000 RPM Typical heavy 80-85
dBA MaxxForce 10 64 dBA
6
Why Choose the MaxxForce 10?

• Light Weight Design
• Built on a our premium medium duty platform, the
  MaxxForce 10 has a big advantage in weight
  sensitive applications
• Dry Engine Weight (advertised)
• Cummins ISM 2181 lbs
• C-13 2270 lbs
• MaxxForce 10 1560 lbs
• 600-700 lbs advantage!

7
Why Choose the MaxxForce 10?

• Low Cost Alternative to a Heavy Engine
• A MaxxForce 10 powered International WorkStar
  will generally cost more than 8000 less than a
  similarly speced WorkStar with a heavy engine at
  the same rated power

8
Why Choose the MaxxForce 10?

• Low Cost and Driver Friendly
• Allison 3000 HS and 3000 RDS transmissions are
  now available with the MaxxForce 10 up to 350 HP,
  offering considerable savings over the 4000
  series transmission required for heavy engines
• Eaton automated manuals are also available for
  the MaxxForce 10, providing another cost
  effective driver friendly alternative

9
MaxxForce 10 - Construction
MaxxForce 10 Construction

• Built on common architecture with MaxxForce DT
  and MaxxForce 9
• Common Bore Diameter
• Displacement change by Stroke
• Product of International Melrose Park, Illinois
  Engine Plant
• Engineering design and test
• Major component manufacturing
• Final assembly

10
MaxxForce 10 Construction
Crankcase Premium Strength

• Thermal stress relieving
• Controlled heating process
• Relieves residual stress in the metal from
  casting process
• Improves case strength to allow higher peak
  cylinder pressures

11
MaxxForce 10 - Construction
Crankcase Premium Strength

• Bearing cap ladder provides added strength
• Ties main bearings to skirt of crankcase
• Provides added strength, maintaining perfect
  alignment of crankshaft under heavy loads

12
MaxxForce 10 - Construction

• Crankshaft Heavy Duty Durability
• Main bearings comparable in size to Heavy Engines
  and significantly larger than competitive 9
  liter engines

Main Bearing Diameters (inches) Cummins
ISM 4.49 CAT C-10 4.25 MaxxForce 10 4.25 Cummins
ISL 3.83
13
MaxxForce 10 - Construction

• Single Piece Steel Piston
• Heavy engine style piston
• Similar to MaxxForce 11/13 piston
• Gallery cooled
• Improved wear characteristics and lighter over
  all weight compared to prior two piece steel
  crown / aluminum skirted piston

14
MaxxForce 10 - Construction

• Titanium Compressor Wheel
• Severe Service Turbo-Charger

MaxxForce 10 engines use a titanium compressor
wheel for durable turbo service in the most
severe applications
Electronic Variable Response Turbocharger
15
2007 Technology and Improvements

• Design Philosophy for 2007
• Minimize changes
• Carry-over 2004 engine technology to maximize
  reliability growth
• Integrate proven technology and build from Green
  Diesel Technology experience to meet emissions

16
2007 Technology

• G2 Electro Hydraulic Fuel System

• Advantages
• Reliable proven design
• Full electronic control
• No high pressure fuel lines
• Enables DPF regeneration (in-cylinder-dosing)
  without down-stream injection equipment

• Low pressure common rail delivers fuel to
  injectors
• High pressure common oil rail - provides
  injection force
• G2 Injectors
• Spool valve controls oil flow and injection
  events
• Delivers fuel at 71 intensification of oil rail
  pressure

17
2007 Technology

• G2 In-Cylinder-Dosing for DPF Regeneration
• Added exhaust heat occasionally required to
  oxidize particulate matter trapped in the Diesel
  Particulate Filter
• G2 injectors deliver a second dose of fuel after
  combustion is complete
• This unburned fuel is pushed out of the cylinder
  with the exhaust
• Fuel then oxidizes in a flow through catalyst,
  releasing heat
• Heat reduces soot deposits in the DPF to CO2 and
  Water
• No additional fuel lines or injection equipment
  is required

Vehicle Exhaust System
Oxidation Catalyst
Diesel Particulate Filter
18
2007 Technology

• DPF Regeneration
• Intake throttling and turbine vane control

• Throttle wide open during normal operation
• Engine throttling along with turbine vane control
  raises exhaust temps for active regeneration
  prior to in-cylinder-dosing
• Throttle can close to protect DPF from high
  temperature damage

Intake Throttle
19
2007 Technology

• Electrical System

• New 32 bit single box ECM
• Faster computer with more capability
• Needed for aftertreatment inputs and control
• Single box has fewer connection points than old
  2-box system reliability
• Inputs for remote engine speed control body
  builders no longer need to order RESCM module

20
2007 Technology

• Electrical System

• Molded Foam Wiring Harnesses
• Molded to fit and tough as nails no more
  conduit and black tape
• Major improvement to
• First time quality Fits right every time, no
  connectors pulled out
• Long term reliability Robust to chaffing, no
  stress on wires
• Serviceability Easy to remove and reinstall
  harnesses
• Injector Harness has half as many connectors to
  valve cover gasket

21
2007 Technology

• EVRT Turbocharger
• Electronic Variable Response Turbine
• Vane type variable nozzle turbine with DC motor
  actuation

• Improves torque curve and response for better
  vehicle performance
• Provides exhaust back pressure to control EGR
  flow
• Design Improvements
• Corrosion resistant internal components
• Multiple improvements to DC actuators
• Stainless steel ball joints on actuator linkage

22
2007 Technology

• Upgraded 2007 EGR System

• NOx emissions reduced without fuel economy
  penalty via
• More EGR cooling
• Improved EGR mixing
• Higher flow rates
• Reduced pressure drop
• Valve robustness improved by
• Powered close capability
• Between the coolers location
• Water cooling

Power-to-close valve actuation
Water cooled valve
Stage 2 cooler
Stage 1 cooler
EGR static mixer
23
2007 Technology

• Closed Crankcase Ventilation System

• Maintenance Free centrifugal oil mist separator
• No filters to change
• Lube oil pressure spins a centrifuge to remove
  solids from crankcase fumes

Vent tube from valve cover
Cleaned air to compressor inlet
Centrifugal separator / drain to case
24
2007 Features

• Fuel Filtration System
• Combination filter and fuel/water separator
• Top loading strainer and cartridge style filter
  for ease of service
• Integrated Water-in-Fuel Sensor standard
• Driver notified by WIF light on dash
• No need to check sight glass
• Easy access water drain
• Integrated Filter Restriction Indicator standard
• Dirty filter indicated by dash light
• No need to change filter based on interval
• Optional 60 Watt Fuel Heater available

25
MaxxForce 10 - Ratings
MaxxForce 10 Ratings
26
MaxxForce 10

• Why Choose the MaxxForce 10?
• Heavy Duty Power and Performance
• Medium Duty Price
• Medium Duty Weight
• MaxxForce 10 Construction
• Stress-relieved / Ladder reinforced case
• Heavy duty bearings
• Single piece steel pistons
• Severe service turbo-charger
• 2007 Technology and Improvements
• Minimum change philosophy w/ reliability
  enhancements
• Emissions solutions based upon Green Diesel
  Technology

27
THANK YOU!!
