DISCRETE COMPUTATIONAL STRUCTURES

1
DISCRETE COMPUTATIONAL STRUCTURES

• CSE 2353
• Material for Second Test
• Spring 2006

2
CSE 2353 OUTLINE

1. Sets
2. Logic
3. Proof Techniques
4. Integers and Inductions
5. Relations and Posets
6. Functions
7. Counting Principles
8. Boolean Algebra

3
Proof Technique Learning Objectives

• Learn various proof techniques
• Direct
• Indirect
• Contradiction
• Induction
• Practice writing proofs
• CS Why study proof techniques?

4
Proof Techniques

• Theorem
• Statement that can be shown to be true (under
  certain conditions)
• Typically Stated in one of three ways
• As Facts
• As Implications
• As Biimplications

5
Proof Techniques

• Direct Proof or Proof by Direct Method
• Proof of those theorems that can be expressed in
  the form ?x (P(x) ? Q(x)), D is the domain of
  discourse
• Select a particular, but arbitrarily chosen,
  member a of the domain D
• Show that the statement P(a) ? Q(a) is true.
  (Assume that P(a) is true
• Show that Q(a) is true
• By the rule of Universal Generalization (UG),
• ?x (P(x) ? Q(x)) is true

6
Proof Techniques

• Indirect Proof
• The implication p ? q is equivalent to the
  implication (q ? p)
• Therefore, in order to show that p ? q is true,
  one can also show that the implication
  (q ? p) is true
• To show that (q ? p) is true, assume that the
  negation of q is true and prove that the negation
  of p is true

7
Proof Techniques

• Proof by Contradiction
• Assume that the conclusion is not true and then
  arrive at a contradiction
• Example Prove that there are infinitely many
  prime numbers
• Proof
• Assume there are not infinitely many prime
  numbers, therefore they are listable, i.e.
  p1,p2,,pn
• Consider the number q p1p2pn1. q is not
  divisible by any of the listed primes
• Therefore, q is a prime. However, it was not
  listed.
• Contradiction! Therefore, there are infinitely
  many primes

8
Proof Techniques

• Proof of Biimplications
• To prove a theorem of the form ?x (P(x) ? Q(x )),
  where D is the domain of the discourse, consider
  an arbitrary but fixed element a from D. For this
  a, prove that the biimplication P(a) ? Q(a) is
  true
• The biimplication p ? q is equivalent to
  (p ? q) ? (q ? p)
• Prove that the implications p ? q and q ? p are
  true
• Assume that p is true and show that q is true
• Assume that q is true and show that p is true

9
Proof Techniques

• Proof of Equivalent Statements
• Consider the theorem that says that statements
  p,q and r are equivalent
• Show that p ? q, q ? r and r ? p
• Assume p and prove q. Then assume q and prove r
  Finally, assume r and prove p
• Or, prove that p if and only if q, and then q if
  and only if r
• Other methods are possible

10
Other Proof Techniques

• Vacuous
• Trivial
• Contrapositive
• Counter Example
• Divide into Cases

11
Proof Basics

• You can not prove by example

12
Proofs in Computer Science

• Proof of program correctness
• Proofs are used to verify approaches

13
CSE 2353 OUTLINE

1. Sets
2. Logic
3. Proof Techniques
4. Integers and Induction
5. Relations and Posets
6. Functions
7. Counting Principles
8. Boolean Algebra

14
Learning Objectives

• Learn about the basic properties of integers
• Explore how addition and subtraction operations
  are performed on binary numbers
• Learn how the principle of mathematical induction
  is used to solve problems
• CS
• Become aware how integers are represented in
  computer memory
• Looping

15
Integers

• Properties of Integers

16
Integers

17
Integers

18
Integers
19
Integers

• The div and mod operators
• div
• a div b the quotient of a and b obtained by
  dividing a on b.
• Examples
• 8 div 5 1
• 13 div 3 4
• mod
• a mod b the remainder of a and b obtained by
  dividing a on b
• 8 mod 5 3
• 13 mod 3 1

20
Integers
21
Integers
22
Integers
23
Integers

• Relatively Prime Number

24
Integers

• Least Common Multiples

25
Representation of Integers in Computer

• Electrical signals are used inside the computer
  to process information
• Two types of signals
• Analog
• Continuous wave forms used to represent such
  things as sound
• Examples audio tapes, older television signals,
  etc.
• Digital
• Represent information with a sequence of 0s and
  1s
• Examples compact discs, newer digital HDTV
  signals

26
Representation of Integers in Computers

• Digital Signals
• 0s and 1s 0s represent low voltage, 1s high
  voltage
• Digital signals are more reliable carriers of
  information than analog signals
• Can be copied from one device to another with
  exact precision
• Machine language is a sequence of 0s and 1s
• The digit 0 or 1 is called a binary digit , or
  bit
• A sequence of 0s and 1s is sometimes referred to
  as binary code

27
Representation of Integers in Computers

• Decimal System or Base-10
• The digits that are used to represent numbers in
  base 10 are 0,1,2,3,4,5,6,7,8, and 9
• Binary System or Base-2
• Computer memory stores numbers in machine
  language, i.e., as a sequence of 0s and 1s
• Octal System or Base-8
• Digits that are used to represent numbers in base
  8 are 0,1,2,3,4,5,6, and 7
• Hexadecimal System or Base-16
• Digits and letters that are used to represent
  numbers in base 16 are 0,1,2,3,4,5,6,7,8,9,A ,B
  ,C ,D ,E , and F

28
Representation of Integers in Computers
29
Representation of Integers in Computers

• Twos Complements and Operations on Binary
  Numbers
• In computer memory, integers are represented as
  binary numbers in fixed-length bit strings, such
  as 8, 16, 32 and 64
• Assume that integers are represented as 8-bit
  fixed-length strings
• Sign bit is the MSB (Most Significant Bit)
• Leftmost bit (MSB) 0, number is positive
• Leftmost bit (MSB) 1, number is negative

30
Representation of Integers in Computers
31
Representation of Integers in Computers

• Ones Complements and Operations on Binary
  Numbers

32
Representation of Integers in Computers
33
Mathematical Deduction
34
Mathematical Deduction

• Proof of a mathematical statement by the
  principle of mathematical induction consists of
  three steps

35
Mathematical Deduction

• Assume that when a domino is knocked over, the
  next domino is knocked over by it
• Show that if the first domino is knocked over,
  then all the dominoes will be knocked over

36
Mathematical Deduction

• Let P(n) denote the statement that then nth
  domino is knocked over
• Show that P(1) is true
• Assume some P(k) is true, i.e. the kth domino is
  knocked over for some
• Prove that P(k1) is true, i.e.

37
Mathematical Deduction

• Assume that when a staircase is climbed, the next
  staircase is also climbed
• Show that if the first staircase is climbed then
  all staircases can be climbed
• Let P(n) denote the statement that then nth
  staircase is climbed
• It is given that the first staircase is climbed,
  so P(1) is true

38
Mathematical Deduction

• Suppose some P(k) is true, i.e. the kth staircase
  is climbed for some
• By the assumption, because the kth staircase was
  climbed, the k1st staircase was climbed
• Therefore, P(k) is true, so

39
Mathematical Deduction
40
Mathematical Deduction

• We can associate a predicate, P(n). The predicate
  P(n) is such that

41
Prime Numbers
42
Prime Numbers
43
Prime Numbers
Example Consider the integer 131. Observe that 2
does not divide 131. We now find all odd primes p
such that p2 ? 131. These primes are 3, 5, 7, and
11. Now none of 3, 5, 7, and 11 divides 131.
Hence, 131 is a prime.
44
Prime Numbers
45
Prime Numbers

• Factoring a Positive Integer
• The standard factorization of n

46
Prime Numbers

• Fermats Factoring Method

47
Prime Numbers

• Fermats Factoring Method

48
CSE 2353 OUTLINE

1. Sets
2. Logic
3. Proof Techniques
4. Integers and Induction
5. Relations and Posets
6. Functions
7. Counting Principles
8. Boolean Algebra

49
Learning Objectives

• Learn about relations and their basic properties
• Explore equivalence relations
• Become aware of closures
• Learn about posets
• Explore how relations are used in the design of
  relational databases

50
Relations

• Relations are a natural way to associate objects
  of various sets

51
Relations

• R can be described in
• Roster form
• Set-builder form

52
Relations

• Arrow Diagram
• Write the elements of A in one column
• Write the elements B in another column
• Draw an arrow from an element, a, of A to an
  element, b, of B, if (a ,b) ? R
• Here, A 2,3,5 and B 7,10,12,30 and R
  from A into B is defined as follows For all a ?
  A and b ? B, a R b if and only if a divides b
• The symbol ? (called an arrow) represents the
  relation R

53
Relations
54
Relations

• Directed Graph
• Let R be a relation on a finite set A
• Describe R pictorially as follows
• For each element of A , draw a small or big dot
  and label the dot by the corresponding element of
  A
• Draw an arrow from a dot labeled a , to another
  dot labeled, b , if a R b .
• Resulting pictorial representation of R is called
  the directed graph representation of the relation
  R

55
Relations
56
Relations

• Directed graph (Digraph) representation of R
• Each dot is called a vertex
• If a vertex is labeled, a, then it is also called
  vertex a
• An arc from a vertex labeled a, to another
  vertex, b is called a directed edge, or directed
  arc from a to b
• The ordered pair (A , R) a directed graph, or
  digraph, of the relation R, where each element of
  A is a called a vertex of the digraph

57
Relations

• Directed graph (Digraph) representation of R
  (Continued)
• For vertices a and b , if a R b, a is adjacent to
  b and b is adjacent from a
• Because (a, a) ? R, an arc from a to a is drawn
  because (a, b) ? R, an arc is drawn from a to b.
  Similarly, arcs are drawn from b to b, b to c , b
  to a, b to d, and c to d
• For an element a ? A such that (a, a) ? R, a
  directed edge is drawn from a to a. Such a
  directed edge is called a loop at vertex a

58
Relations

• Directed graph (Digraph) representation of R
  (Continued)
• Position of each vertex is not important
• In the digraph of a relation R, there is a
  directed edge or arc from a vertex a to a vertex
  b if and only if a R b
• Let A a ,b ,c ,d and let R be the relation
  defined by the following set
• R (a ,a ), (a ,b ), (b ,b ), (b ,c ), (b
  ,a ), (b ,d ), (c ,d )

59
Relations

• Domain and Range of the Relation
• Let R be a relation from a set A into a set B.
  Then R ? A x B. The elements of the relation R
  tell which element of A is R-related to which
  element of B

60
Relations
61
Relations
62
Relations
63
Relations

• Let A 1, 2, 3, 4 and B p, q, r. Let R
  (1, q), (2, r ), (3, q), (4, p). Then R-1
  (q, 1), (r , 2), (q, 3), (p, 4)
• To find R-1, just reverse the directions of the
  arrows
• D(R) 1, 2, 3, 4 Im(R-1), Im(R) p, q, r
  D(R-1)

64
Relations
65
Relations

• Constructing New Relations from Existing
  Relations

66
Relations

• Example
• Consider the relations R and S as given in Figure
  3.7.
• The composition S ? R is given by Figure 3.8.

67
Relations
68
Relations
69
Relations
70
Relations
71
Relations
72
Relations
73
Relations
74
Relations
75
Relations
76
Relations
77
Relations
78
Relations
79
Relations
80
Partially Ordered Sets
81
Partially Ordered Sets
82
Partially Ordered Sets
83
Partially Ordered Sets
84
Partially Ordered Sets

• Hasse Diagram
• Let S 1, 2, 3. Then P(S) ?, 1, 2, 3,
  1, 2, 2, 3, 1, 3, S
• Now (P(S),) is a poset, where denotes the set
  inclusion relation. The poset diagram of (P(S),)
  is shown in Figure 3.22

85
Partially Ordered Sets
86
Partially Ordered Sets

• Hasse Diagram
• Let S 1, 2, 3. Then P(S) ?, 1, 2, 3,
  1, 2, 2, 3, 1, 3, S
• (P(S),) is a poset, where denotes the set
  inclusion relation
• Draw the digraph of this inclusion relation (see
  Figure 3.23). Place the vertex A above vertex B
  if B ? A. Now follow steps (2), (3), and (4)

87
Partially Ordered Sets
88
Partially Ordered Sets

• Hasse Diagram
• Consider the poset (S,), where S 2, 4, 5, 10,
  15, 20 and the partial order is the
  divisibility relation
• In this poset, there is no element b ? S such
  that b ? 5 and b divides 5. (That is, 5 is not
  divisible by any other element of S except 5).
  Hence, 5 is a minimal element. Similarly, 2 is a
  minimal element

89
Partially Ordered Sets

• Hasse Diagram
• 10 is not a minimal element because 2 ? S and 2
  divides 10. That is, there exists an element b ?
  S such that b lt 10. Similarly, 4, 15, and 20 are
  not minimal elements
• 2 and 5 are the only minimal elements of this
  poset. Notice that 2 does not divide 5.
  Therefore, it is not true that 2 b, for all b ?
  S, and so 2 is not a least element in (S,).
  Similarly, 5 is not a least element. This poset
  has no least element

90
Partially Ordered Sets
Figure 3.24

• Hasse Diagram
• There is no element b ? S such that b ?15, b gt
  15, and 15 divides b. That is, there is no
  element b ? S such that 15 lt b. Thus, 15 is a
  maximal element. Similarly, 20 is a maximal
  element.
• 10 is not a maximal element because 20 ? S and 10
  divides 20. That is, there exists an element b ?
  S such that 10 lt b. Similarly, 4 is not a maximal
  element.

91
Partially Ordered Sets
Figure 3.24

• Hasse Diagram
• 20 and 15 are the only maximal elements of this
  poset
• 10 does not divide 15, hence it is not true that
  b 15, for all b ? S, and so 15 is not a
  greatest element in (S,)
• This poset has no greatest element

92
Partially Ordered Sets
93
Partially Ordered Sets
94
Partially Ordered Sets
95
Partially Ordered Sets
96
Partially Ordered Sets
97
Partially Ordered Sets
98
Partially Ordered Sets
99
Partially Ordered Sets
100
Application Relational Database

• A database is a shared and integrated computer
  structure that stores
• End-user data i.e., raw facts that are of
  interest to the end user
• Metadata, i.e., data about data through which
  data are integrated
• A database can be thought of as a well-organized
  electronic file cabinet whose contents are
  managed by software known as a database
  management system that is, a collection of
  programs to manage the data and control the
  accessibility of the data

101
Application Relational Database

• In a relational database system, tables are
  considered as relations
• A table is an n-ary relation, where n is the
  number of columns in the tables
• The headings of the columns of a table are called
  attributes, or fields, and each row is called a
  record
• The domain of a field is the set of all
  (possible) elements in that column

102
Application Relational Database

• Each entry in the ID column uniquely identifies
  the row containing that ID
• Such a field is called a primary key
• Sometimes, a primary key may consist of more than
  one field

103
Application Relational Database

• Structured Query Language (SQL)
• Information from a database is retrieved via a
  query, which is a request to the database for
  some information
• A relational database management system provides
  a standard language, called structured query
  language (SQL)
• A relational database management system provides
  a standard language, called structured query
  language (SQL)

104
Application Relational Database

• Structured Query Language (SQL)
• An SQL contains commands to create tables, insert
  data into tables, update tables, delete tables,
  etc.
• Once the tables are created, commands can be used
  to manipulate data into those tables.
• The most commonly used command for this purpose
  is the select command. The select command allows
  the user to do the following
• Specify what information is to be retrieved and
  from which tables.
• Specify conditions to retrieve the data in a
  specific form.
• Specify how the retrieved data are to be
  displayed.
