Rossby Wave Radiation from Nontranslating and Moving Vortices

1
Rossby Wave Radiation from Non-translating and
Moving Vortices

• Kyle Krouse
• Adam Sobel, Lorenzo Polvani

Department of Applied Mathematics and Applied
Physics Columbia University
2
Motivation Multiple Cyclone Events

• Dispersion from a Tropical Cyclone relevant to
  cyclogenesis
• (e.g. Frank, 1982 Davidson Hendon, 1989)
• TC movement emits Rossby wave radiation in its
  wake forming a wavetrain
• (e.g. Carr Elsberry, 1995)
• Simple mathematical explanation for this
  wavetrain? Particularly its wavelength?

3
An Observed Multiple Cyclone Event
TC Jelawat exciting TC Ewiniar in WNP, Aug.,
2000. From Li et al, 2003
4
Stationary Solutions

• Wavetrain is a stationary solution.
• Suspect that the wavetrain is due to Short
  Wavelength Rossby wave dispersion
• However, a non-translating vortex does not give
  you a strong signal (e.g. Carr Elsberry, 1995)

5
Our Idea

• If the steering flows for the cyclone and the
  Rossby waves are the same ? expect no additional
  stationary states from dispersion relation
• BUT different steering flows ? a Doppler effect
  might admit new stationary states

6
Numerical Model STSWMNonlinear SWEs on the
sphere

• (1)
• (2)
• (3)

7
Numerical Model STSWMNonlinear forced SWEs on
the sphere

• (1)
• (2)
• (3)

8
Numerical Model STSWMNonlinear forced SWEs on
the sphere

• (1)
• (2)
• (3)

9
Numerical Model STSWMNonlinear forced SWEs on
the sphere

• (1)
• (2)
• (3)

Average depth of system set to get correct
gravity wave speed H 250 m
10
Numerical Experiment

• Localized forcing
• Nonlinear response near vortex
• Linear response in far-field

11
Linear Analysis

• In far-field, dispersion relation instructive
• Rossby wave mechanism
• Near the tropics
• ? analyzing linear SWEs with equatorial
  beta-plane approximation seems reasonable

12
Dispersion Relation Non-translating Vortex
k zonal wavenumber n meridional wavenumber
13

• No meaningful stationary points (? 0)

14
(No Transcript)
15
(No Transcript)
16
Dispersion Relation Translating Vortex
Relative motion between the flow relevant to
the vortex and the flow relevant to the Rossby
waves
k zonal wavenumber n meridional wavenumber
17
What is Ubar?

• Relative motion between different flows
• TC steering flow versus the flow that the waves
  live on
• The flows may be different
• TC-induced beta-gyres
• monsoon shears
• ubar 5 m/s reasonable
• imposed westward vortex motion ? the environment
  is moving eastward from the vortex frame

18
(No Transcript)
19
(No Transcript)
20
(No Transcript)
21
(No Transcript)
22
(No Transcript)
23
Properties of the Solution

• Short-wavelength Rossby waves
• westward (absolute) phase propagation
• eastward energy propagation
• cyclonic anomaly is much stronger than in
  non-translating case grows in time
• catching phase that translates at ubar

24
(No Transcript)
25
Conclusions

• A difference between the flows relevant to a
  vortex and to the SW Rossby waves that it
  radiates can result in a new stationary solution
  to the SWEs.
• These stationary SW Rossby wave solutions are of
  the observed length scale in a Multiple Cyclone
  event.
• These waves excite a strong cyclonic anomaly to
  the SE of the vortex, potentially important in
  the spinup of a second vortex in a Multiple
  Cyclone event.

My email address is kdk8_at_columbia.edu
