Exterior Walls

1
Exterior Walls

• By Alex Yager

2
Exterior Wall
3
Structural Types

• Exterior walls can be classified into three
  different groups
• They are Load-Bearing Walls, Non Load-bearing
  Walls, and Curtain Walls
• Load-Bearing Walls are walls that support loads
  from floors, roof and equipment plus their own
  weight
• Non Load-Bearing Walls are walls that only
  support their own weight

4
Structural Types (Cont.)

• Curtain Walls are walls that have their own
  weight supported on structural members

5
Material Classifications

• Wood and Wood Products Wood Shingles,
  weatherboard siding, plywood, and prefabricated
  panels
• Concrete and Masonry Brick, concrete masonry
  units, reinforced concrete, precast concrete
  panels, structural clay tile, stone, exterior
  plaster

6
Material Classifications (Cont.)

• Metal Corrugated iron and steel, aluminum
  sheeting, precut sheet metal, enamel-coated,
  prefabricated steel panels, protected metals, and
  prefabricated panels
• Mineral and Chemical Products Asbestos
  shingles, asbestos-cement sheets, prefabricated
  panels, gloss black and vinyl

7
The Purpose of Siding

• Siding is used on exterior walls to protect the
  house from heat and cold and against penetration
  of rain and moisture
• There must be no unprotected openings in the wall
  in order for it to be watertight
• Joints at window and door frame openings must be
  sealed with a good caulking material, and damaged
  areas must be repaired immediately

8
Maintenance And Repair

• Where repair is made to existing types of
  construction and material, it is best to match
  the specifications between the two as closely as
  possible
• Improved construction techniques should be
  constantly examined to prevent or offset similar
  failure

9
Maintenance And Repair (Cont.)

• Consideration must be given to either matching
  existing material, replacement of the entire
  covering, or a completely new finish over the
  existing surface where weathering, normal wear,
  or other reasons dictate a requirement for repair
• Neglect of maintenance and repair measures only
  leads to greater and more costly problems

10
Types of Siding

• Sheet Sidings Made of Plywood
• Hardboard and oriented-strand board
• Vinyl
• Aluminum
• Steel
• Wood Shingles
• Masonry Veneers
• Stucco
• Fiber-Cement

11
Siding Pictures
Wood

• Masonry Veneer

Steel
Aluminum
Vinyl
Stucco
12
Wood Exteriors

• There are two main reasons for failure in wood
  exterior walls moisture and structural failure
• Some reasons for moisture failure are weathering,
  leaks, and cracks, which allow moisture to enter
  and collect behind exterior coverings
• Settlement of foundations, which can cause
  displacement and misalignment of framing members
  may crack, misalign, and damage facing material

13
Wood Siding Maintenance

• Make a careful check over the existing material
  to make sure that everything is looking good and
  functioning correctly
• Make sure that if there are any damaged sections
  on any part of the siding that you consider
  replacing sections of the wall rather than
  replacing the whole thing

14
Wood Siding

• To replace a damaged section, remove the material
  and tighten any nails in the existing material to
  be left in place
• Make sure you cut a sufficient amount of area
  around the damaged section to obtain good
  jointing and nailing, which is needed to have the
  new section seal well with the original wall
• Cover replacement wood with finishes or paint
  matching the original design so that it blends in

15
Wood Siding

• All types of siding are affected in some way by
  the sun, expansion and contraction from moisture,
  temperature changes, and wind
• It is a must to protect the wood from the
  elements by covering it with paint, stain, wood
  preservatives, or oils

16
Aluminum Siding

• Although is a common belief that this type of
  siding never needs to be maintained, it actually
  does require some
• Moisture can get trapped within a wall thickness,
  accelerating rot and decay
• Instead of replacing just the damaged section as
  when you replace wood siding, it is advised to
  replaced the whole section so the fix isnt quite
  as noticeable

17
Fiber-cement Siding

• Fiber-cement siding is a lightweight, solid
  material that is a durable and visually
  compatible with wood siding rather than aluminum
  or vinyl
• It is resistant to rot, termites, fire, and
  delamination, and is dimensionally stable,
  allowing the paint to last longer
• Although fiber-cement costs more than aluminum
  and vinyl, it still costs a lot less than wood,
  and has a 50 year warranty

18
Vinyl Siding

• Vinyl siding is composed of extruded pieces of
  plastic and metal, usually used to simulate wood
• This type of siding is usually thinner than wood
  siding, and visually lighter than wood
• In the event of a fire, the fumes from vinyl can
  be very dangerous

19
Clapboard

• Clapboard is a type of siding used for the
  exterior finish of a wood-framed building and
  attached horizontally to wooden studs
• Each clapboard overlaps the one below it, leaving
  a few inches exposed to weather
• White pine is considered to be the best wood for
  clapboard, but cedar, cypress, and spruce are
  also used

20
Clapboard

• Beveled siding is overlapped to prevent water
  from entering between the lap
• The nails that are used to fasten the bottom of
  the clapboard also penetrate the top of the one
  below it to keep it fastened
• Only galvanized nails should be used to fasten
  clapboard

21
German Siding

• German siding is a flat faced board with a
  concave top and notched bottom
• It is installed by nailing the notched bottom of
  the upper board over the concave top of the lower
  board in a staggered joint pattern

22
Repairing Clapboard

• First, you must remove any paint or resin from
  the split
• Ply the section below the split away from the
  wall
• Prepare to coat the split edge with a waterproof
  adhesive
• To hold the piece while the adhesive sets, clamp
  the split edge together by driving some nails
  into the siding below the split edge

23
Repairing Clapboard

• When the adhesive sets, remove the temporary
  nails and nail the bevel siding to the sheathing
  or stud
• Caulk the holes made in the siding by the
  temporary nails

24
Questions

• 1. Clapboard is a type _______ siding.
• 2. A ________ closes a horizontal split in
  beveled siding while the adhesive sets
• 3. Drill ______ ______ before renailing hardwood
  siding
• 4. With overlapping board, shingles, or shakes,
  remove a broken piece by A First removing the
  shingle above it B Removing hidden nails with an
  end cutting pliers C Cutting hidden nails with a
  hacksaw blade D Cutting the old piece with a
  power circular saw

25
Questions

• 5. A new piece of ________ siding must be trimmed
  before it can be inserted
• 6. A joint in a board and batten siding is
  covered A By an interlocking structure B With
  a metal strip C By the next higher board D By a
  batten strip
• 7. It ______ (is, is not) necessary to replace an
  entire sheet of plywood siding if the damaged
  area is small

26
Questions

• 8. To repair mortar if the brick or stone is
  still solid, clean out the old mortar to a depth
  of _____ in
• 9. To _______ a mortar joint means to compact the
  mortar with the trowel point.
• 10. To seal masonry siding to window and door
  moldings, use A Mortar B Caulking C Glue D
  Resin

27
Questions

• 11. How many different types of exterior
  structural walls are there?
• 12. Name 2 kinds of siding
• 13. Wood is the cheapest siding you can buy T/F
• 14. What is vinyl composed of?
• 15. What is caulk used for?
• 16. You can repair small sections of wood siding
  without taking the section off. T/F

28
Questions

• 17. There are 4 main types of material that a
  type of siding can be classified under. T/F
• 18. Asbestos is a hazardous product that can
  cause bodily damage if contact is made with it
  T/F
• 19. Why is it so important so to have the siding
  on your house properly sealed?
• 20. Name a type of wood product that is used as
  siding

29
Answers

• 1. Exterior 9. Point
• 2. Caulked joint 10. B
• 3. Pilot Holes 11. 4
• 4. A 12. wood, metal, artificial..etc.
• 5. Board and Batton 13. F
• 6. A 14. Extruded pieces of plastic/metal
• 7. Is Not 15. To seal joints
• 8. 1 inch 16. T
• 17. T
• 18. T
• 19. So you keep all the moisture out 20. wood
  shingles
