Title: ATGRADE SYSTEMS


1
AT-GRADE SYSTEMS
  • by
  • Albert R. Jarrett,
  • Professor of Biological Engineering

2
The Pennsylvania Protocol
  • In Chapter 73 (Conventional).
  • In-Ground Systems (Limiting Zone gt60 in).
  • Beds.
  • Trenches.
  • Subsurface Sand Filters.
  • Elevated Sand Mounds (Limiting Zone gt20 in).
  • Individual Residential Spray Irrigation System
  • Bedrock Limiting Zone gt 16 in.
  • Water Table Limiting Zone gt10 in.

3
The Pennsylvania Protocol
  • There are two additional categories
  • Alternate Systems.
  • Started as an Experimental System.
  • Was tested and approved for use.
  • Listed in the Alternate Systems Guidance.
  • Experimental Systems.
  • Proposed systems.
  • Being tested.

4
The Pennsylvania Protocol
  • You either have
  • A Conventional system its in Chapter 73.
  • An Alternate system its on the alternate
    guidance.
  • An Experimental system being tested.

5
The Alternate Systems
  • As of February, 2007 Alternate Systems
  • Alternate Systems may be substituted for
    Conventional Systems.
  • Alternate Systems are generally more costly than
    Conventional Systems.
  • Alternate Systems require more maintenance than
    Conventional Systems.

6
At-Grade Systems
  • At-Grade On-Lot Disposal Systems are Alternate
    Systems.
  • There are two types of At-Grade Systems.
  • At-Grade Absorption Area
  • Shallow Limiting Zone At-Grade Absorption Area.
  • The following series of slides will present the
    details required to understand and design these
    At-Grade Systems.

7
At-Grade Absorption Area
  • Minimum Depth to Limiting Zone 20 inches
  • Primary Characteristics
  • Aggregate placed on the soil surface.
  • Must be pressure dosed.

8
If Slope 12
  • Perc Rate must be 3 to 180 min/in.
  • Sized according to a Elevated Sand Mound
    requirements.
  • Seepage bed must have a minimum 41 length to
    width ratio.

9
If Slope gt 12 and 15
  • Perc Rate must be 3 to 90 min/in.
  • Sized according to a Elevated Sand Mound
    requirements.
  • Seepage bed must have a minimum 61 length to
    width ratio.

Slope
Width Length 6Width
10
(No Transcript)
11
Treatment Requirements
  • Treatment requirements as a function of the Depth
    to the Limiting Zone
  • Limiting Zone ? 48 inches
  • Primary Treatment Only (Septic Tank)
  • Limiting Zone ? 20 inches ? 48 inches.
  • Secondary Treatment
  • Aerobic Treatment Tank
  • OR Primary Treatment (Septic Tank)
  • Free Access Sand Filter _at_ 5 gal/d/ft2 (Max)
  • Buried Media Filter _at_ 0.8 gal/d/ft2 (Max)

12
Limiting Zone ? 48 inches.
SepticTank
At-Grade Absorption
Soil Water
House
13
Limiting Zone ? 20 inches but
? 48 inches
Secondary Treatment
Primary Treatment
SepticTank
Soil Water
At-Grade Absorption
Sand Filter
House
Aerobic Tank
At-Grade Absorption
Soil Water
House
14
Shallow Limiting Zone At-Grade Absorption Area
  • Minimum Depth to Limiting Zone
  • 10 inches to seasonal high watertable.
  • 16 inches to rock.
  • Primary Characteristics
  • May not be placed on concave topography.
  • Aggregate placed on the soil surface.
  • Must be pressure dosed.
  • Only trenches maybe used (no beds).

15
Slope must be 15
  • The absorption area is sized based on
  • Horizontal Linear Loading Rate, and
  • Hydraulic Linear Loading Rate
  • Requires a Soil Scientist do the evaluation.

16
Treatment Requirements
  • With the Shallow Limiting Zone
  • Water Limiting Zone ? 10 inches
  • Rock Limiting Zone ? 16 inches.
  • Primary Treatment (Septic Tank) Plus
  • Advanced Treatment Unit
  • Recirculating Sand Filter _at_ 1.3 gal/d/ft2 (Max)
  • Free Access Media Filter _at_ 1.25 gal/d/ft2 (Max)
  • Buried Media Filter _at_ 0.67 gal/d/ft2 (Max)
  • Peat Filter
  • UV Disinfection

17
Shallow Limiting Zone
Advanced Treatment
Trenches
Recirculating Sand Filter Sand Filter Peat Filter
Septic Tank
At-Grade Absorption
Soil Water
House
UV
18
At-Grade System Components
  • Primary Treatment (Septic Tank)
  • Secondary Treatment (Filtration)
  • Advanced Filtration
  • At-Grade Soil Absorption Area.

19
Primary TreatmentTwo-Chamber Septic Tank
20
Secondary Treatment LZ 20 in
  • A Secondary treatment unit (usually filtration
    and biological treatment).
  • These are filtration systems.
  • Placed after the treatment tank.
  • Placed before the At-Grade Absorption area.

21
Secondary Treatment LZ 20 in.
  • Secondary Treatment Systems
  • Free Access Gravity Sand Filter.
  • Buried Media Filter.

22
Free Access Gravity Sand Filter
3 Min 12 Max Depth
23
Advanced Treatment LZ 20 in
  • Advanced treatment unit (slow filtration and
    biological treatment).
  • These are slower filtration systems.
  • Placed after the treatment tank.
  • Placed before the At-Grade Absorption area.

24
Advanced Treatment LZ 20 in.
  • Advanced Treatment Units
  • Recirculating Sand Filter
  • Free Access Media Filter
  • Buried Media Filter
  • Peat Filter

25
Free Access Recirculating Subsurface Sand Filter
26
Free Access Gravity Sand Filter(Lower Loading
Rate)
3 Min 12 Max Depth
27
Peat Filter
28
Peat Filter
29
Absorption Area LZ 20 in.
  • Option A
  • Aggregate is placed at an 10-inch uniform depth
    over chisel-plowed soil surface.
  • Aggregate footprint must have at least a
    4(L)1(W) ratio across the slope.
  • 3-foot wide subsoil berm must be placed on both
    ends and bottom of aggregate.
  • Cover aggregate with separation layer.
  • 8 to 10-inch depth of topsoil is placed over the
    aggregate and berm and planted with suitable
    plants.

30
At-Grade Bed System
10 in aggregate 6 in below pipes, 2 in above
pipes.
8 min. topsoil cover
1
6
6
3
Subsoil Berm
21
31
Option A
31
At-Grade Bed System
41 LW Ratio
2 to 5
Option A
3 wide subsoil berm
32
Absorption Area LZ 20 in.
  • Option B
  • Aggregate is placed at a minimum 10-inch depth
    over chisel-plowed soil surface. Top of aggregate
    must be level.
  • Aggregate footprint must have at least a
    4(L)1(W) ratio across the slope.
  • Cover aggregate with separation layer.
  • 8 to 10-inch depth of topsoil is placed over the
    aggregate and planted with suitable plants.

33
At-Grade Bed System
10 in min aggregate 6 in min below pipes, 2 in
min above pipes.
8 min. topsoil cover
2 to 5
6
31
21
Option B
34
At-Grade Bed System
41 LW Ratio
2 to 5
Option B
35
Shallow LZ 20 in.
  • But when the depth to the Limiting Zone is 20
    inches or less, the system is assumed to dispose
    of the effluent differently.

36
Shallow LZ 20 in.
Must use a trench (one pipe)
10 in aggregate Min
10 inch backfill
  • 10 inches Water
  • 16 inches Rock

Plan for at least 25 feet down slope.
37
QUESTIONS???
