zoltan

1
Robert Heaphy
2
Zoltan Dynamic Load Balancing and Parallel Data
Services

• Erik Boman, Karen Devine, Robert Heaphy, Bruce
  Hendrickson, William Mitchell (NIST), Robert
  Preis (University of Paderborn), Courtenay
  Vaughan
• Sandia National Laboratories
• Albuquerque, NM 87185

3
The Zoltan Toolkit

• Parallel, dynamic, adaptive computations need
  many services to obtain peak performance.
• Processor work loads change during computation.
• Communication patterns are complicated.
• Memory usage is dynamic.
• Application developers wrote their own solutions.
• Little expertise in such parallel algorithms.
• No capability to compare approaches.
• No code reuse.

Zoltan Toolkit of data services for dynamic,
unstructured, adaptive computations
4
Support for Many Applications

• Different applications, requirements, data
  structures.

5
Applications Adaptive Mesh Refinement

• Dynamic load balancing.
• Redistribute elements after mesh refinement.
• Keep data movement costs low.
• Recursive Coordinate Bisection
• Parent and child elements assigned to same
  processor.
• Inexpensive.
• Incremental.

Using RCB with AMR in SIERRA (Edwards, Rath,
Lober, et al., Sandia)
6
Applications Crash Simulations

• Dynamic load balancing.
• Assigns physically close surfaces to the same
  processor.
• Recursive coordinate bisection Inexpensive
  fast incremental.

• Multiphase simulation
• Graph-based decomposition for finite element
  calculation.
• RCB decomposition for contact detection.
• Unstructured Communication package maps between
  decompositions.

Using RCB for Contact Detection in
Pronto (Attaway, Hendrickson, Plimpton, et al.,
Sandia)
7
Applications Parallel Circuit Simulation

• Load balance matrix fill phase.
• Load time for devices can vary by two orders of
  magnitude.
• Problem is a network, not a mesh.
• Load balance solve phase.
• Equal number of rows while minimizing
  communication.
• Trilinos solver library (Heroux, et al.)
  partitions matrix with Zoltan.
• Apply graph partitioning to each phase.

Parallel analog circuit simulation in XYCE
(Hutchinson, Hoekstra, et al., Sandia)
8
Applications Multiphysics Simulations

• Multiphysics simulations
• Difficult to estimate work in advance.
• Rebalance infrequently want high quality.
• Dynamic load balancing
• Multi-constraint graph partitioning.
• Two balance criteria matrix fill and linear
  solve.
• Using Zoltan in MPSalsa.
• Load-balancing query functions implemented in
  lt200 lines of code.
• All communication for migrating data done with
  Zoltans data migration tools.
• No additional communication routines written by
  application developer.

MPSalsa multiphysicssimulations (J. Shadid, A.
Salinger, et al., Sandia)
9
Dynamic Load Balancing

• Desirable characteristics for dynamic load
  balancing
• Distribute work evenly among processors.
• Minimize interprocessor communication.
• Keep data movement costs low.
• Incremental partitioning small changes in
  workloads produce only small changes in
  decomposition.
• Parallel, scalable implementation.

10
No One-Size-Fits-All Solutions

• No single partitioner works best for all
  applications.
• Trade-offs
• Quality vs. speed.
• Geometric locality vs. data dependencies.
• Low data-movement costs vs. tolerance for
  remapping.
• Application developers may not know which
  partitioner is best for application.
• Zoltan contains suite of partitioning methods.
• Application changes only one parameter to switch
  methods.
• Allows experimentation/comparisons to find most
  effective partitioner for application.
• Advantage of toolkit approach.

11
Zoltan Suite of Partitioning Algorithms
Recursive Coordinate Bisection (Berger,
Bokhari) Recursive Inertial Bisection (Taylor,
Nour-Omid)
ParMETIS (Karypis, Schloegel, Kumar) Jostle
(Walshaw)
Space Filling Curves (Peano, Hilbert) Refinement-t
ree Partitioning (Mitchell) Octree Partitioning
(Loy, Flaherty)
12
Recursive Coordinate Bisection (RCB)

• Developed by Berger Bokhari, 1987, for AMR.
• Idea
• Divide work into two equal parts using a cutting
  plane orthogonal to a coordinate axis.
• Recursively cut the resulting subdomains.

13
RCB Advantages

• Conceptually simple fast and inexpensive.
• Regular subdomains.
• Can be used for structured or unstructured
  applications.
• All processors can inexpensively know entire
  decomposition.
• Effective when connectivity info is not
  available.
• Implicitly incremental.

14
RCB Disadvantages

• No explicit control of communication costs.
• Can generate disconnected subdomains.
• Mediocre partition quality.

15
Variations on RCB in Zoltan

• Recursive Inertial Bisection
• Simon, Taylor, et al., 1991
• Cutting planes orthogonal to principle axes of
  geometry.
• Not incremental.
• Point-Assign and Box-Assign.
• Given a decomposition, determine to which
  processor(s) a new item should be added (based on
  its geometric location).
• Useful in contact detection and multiphase
  simulations.
• Structured-mesh support.
• Set parameter to generate regular block
  subdomains.

16
Space-Filling Curve Partitioning (SFC)

• Developed by Peano, 1890.
• Space-Filling Curve
• Mapping from R3 to R1 that completely fills a
  domain.
• Applied recursively to obtain desired
  granularity.
• Used for partitioning by
• Warren and Salmon, 1993, gravitational
  simulations.
• Pilkington and Baden, 1994, smoothed particle
  hydrodynamics.
• Patra and Oden, 1995, adaptive mesh refinement.

17
SFC Algorithm

• Run space-filling curve through domain.
• Order objects according to position on curve.
• Perform 1-D partition of curve.

18
SFC Advantages

• Simple, fast, inexpensive.
• Maintains geometric locality of objects in
  processors.
• Linear ordering of objects may improve cache
  performance.
• Implicitly incremental.

19
SFC Disadvantages

• No explicit control of communication costs.
• Can generate disconnected subdomains.
• Slightly lower quality partitions than RCB.

20
Implementations of SFC in Zoltan

• Binned Hilbert SFC
• Heaphy, Edwards, 2001
• Replace linear sort of objects by adaptive
  binning strategy.
• Improved speed over traditional implementations.
• Box-Assign and Point-Assign supported.
• Refinement-Tree Partitioning
• Mitchell, 1998
• Topology-based rather than geometry-based.
• Uses parent-child relationships in AMR to build
  tree.
• Octree Partitioning
• Loy, Flaherty, 1998
• Explicitly builds octree data structure.
• Partial tree traversals give (binned) linear
  ordering.

21
Applications using SFC

• Adaptive hp-refinement finite element methods.
• Assigns physically close elements to same
  processor.
• Inexpensive incremental fast.
• Linear ordering can be used to order elements
  for efficient memory access.

hp-refinement mesh 8 processors. Patra, et al.
(SUNY-Buffalo)
22
Graph Partitioning

• Represent problem as a weighted graph.
• Nodes objects to be partitioned.
• Edges communication between objects.
• Weights work load or amount of communication.

• Partition graph so that
• Partitions have equal nodal weight.
• Weight of edges cut by subdomain boundaries is
  small.

23
Multi-Level Graph Partitioning

• Bui Jones (1993) Hendrickson Leland (1993)
  Karypis and Kumar (1995)
• Construct smaller approximations to graph.
• Perform graph partitioning on coarse graph.
• Propagate partition back, refining as needed.

24
Multi-level Graph Partitioning

• Advantages
• High quality partitions for many applications.
• Explicit control of communication costs.
• Widely used for static partitioning (Chaco,
  METIS, Party, Scotch)
• Disadvantages
• More expensive than geometric approaches.
• Not incremental.

25
Diffusive Graph Partitioning

• Cybenko (1989) Hu Blake (1995)
• Work is moved from heavily loaded processors to
  more lightly loaded neighbors.

26
Diffusive Graph Partitioning

• Advantages
• Local and parallel.
• Inexpensive.
• Incremental.
• Disadvantages
• Several iterations needed for global balance.
• Partition quality can degrade.
• Hybrid approach may work best.

27
Graph Partitioning in Zoltan

• Zoltan provides interfaces to popular parallel
  graph partitioning packages.
• ParMETIS (U. Minnesota)
• PJostle (U. Greenwich)
• Both ParMETIS and PJostle include
• Multilevel graph partitioning
• Diffusive partitioning
• Hybrids of the two strategies
• Multi-constraint partitioning
• Zoltan interface simple callbacks for neighbor
  lists.
• Zoltan builds complicated graph data structures
  needed by graph-partitioning packages.

28
Zoltan Data Services
29
Zoltan Data Migration Tools

• Data must be moved for new decomposition.
• Depends strongly on application data structures.
• Complicated communication patterns.
• Zoltan can help!
• Application supplies query functions to
  pack/unpack data.
• Zoltan does all communication to new processors.

30
Zoltan Matrix Ordering Interface

• Produce fill-reducing ordering for sparse matrix
  factorization.
• Generic matrix-ordering interface in Zoltan.
• Easy to add new ordering algorithms.
• Specific interface to ordering methods in
  ParMETIS.

31
Zoltan Unstructured Communication Package

• Simple primitives for efficient irregular
  communication.
• Zoltan_Comm_Create Generates communication plan.
• Processors and amount of data to send and
  receive.
• Zoltan_Comm_Do Send data using plan.
• Can reuse plan. (Same plan, different data.)
• Zoltan_Comm_Do_Reverse Inverse communication.
• Used for most communication in Zoltan.

32
Zoltan Dynamic Memory Package

• Support for debugging dynamic memory usage.
• Tracking of mallocs and frees.
• Memory-leak warnings.
• Source code file and line numbers of operations.
• Simple allocation of multi-dimensional arrays.
• Simple to use.
• Replace calls to malloc, free with ZOLTAN_MALLOC,
  ZOLTAN_FREE.
• Link with memory package library.

33
Zoltan Distributed Data Directory

• Helps applications locate off-processor data.
• Rendezvous algorithm (Pinar, 2001).
• Directory distributed in known way (hashing)
  across processors.
• Requests for object location sent to processor
  storing theobjects directory entry.
• Easy to use.
• Functions to create, update, search, destroy.
• Customizable data storage, user distribution.
• Scalable performance.
• Constant communication cost for look-ups.
• Linear total memory usage.
• Avoids communication bottlenecks.

34
Zoltan Toolkit Summary

• Data-structure neutral design.
• Application need not use/build prescribed data
  structures.
• High-quality implementations of many
  partitioners.
• No single algorithm is appropriate for all
  applications.
• Suite of algorithms allows experimentation and
  comparison.
• Data management tools for dynamic applications.
• Data migration, unstructured communication,
  memory management.
• Uses of Zoltan
• Effective toolkit for many different
  applications.
• Research test-bed for new algorithm development.
• Interface for new graph-, tree-, or
  geometry-based tools.

35
Zoltan Interface

• Simple, easy-to-use interface.
• Small number of callable Zoltan functions.
• Callable from C, C, Fortran.
• Data-structure neutral design.
• Supports wide range of applications and data
  structures.
• Imposes no restrictions on applications data
  structures.
• Application does not have to build Zoltans data
  structures.
• Only requirement unique global IDs for objects.
• Application interface
• Zoltan queries the application for needed info.
• IDs of objects, coordinates, relationships to
  other objects.
• Application provides simple functions to answer
  queries.
• Small extra costs in memory and function-call
  overhead.

36
Zoltan Query Functions

• Query mechanism supports
• Geometric algorithms
• Queries for dimensions, coordinates, etc.
• Graph-based algorithms
• Queries for edge lists, edge weights, etc.
• Tree-based algorithms
• Queries for parent/child relationships, etc.
• Once query functions are implemented, application
  can access all Zoltan functionality.
• Can switch between algorithms by setting
  parameters.

37
Example Zoltan Application Interface
APPLICATION
Initialize Zoltan (Zoltan_Initialize,
Zoltan_Create)
COMPUTE
Select LB Method (Zoltan_Set_Params)
Re-partition (Zoltan_LB_Partition)
Register query functions (Zoltan_Set_Fn)
Move data (Zoltan_Migrate)
Clean up (Zoltan_Destroy)
38
Current Development in Zoltan

• Partitioning for complex objectives.
• Communication and computation.
• Overlapped preconditioners.
• Work with Pinar (LBL).

• Heterogeneous partitioning.
• Model machine as hierarchy of components.
• Partition each level of hierarchy.
• Work with Flaherty (RPI), Teresco (Williams).

• Multiconstraint geometric partitioning.
• Find one partition that is good with respect to
  multiple weights.
• Graph-based multiconstraint partitioning
  available in Zoltan through ParMETIS3.0.

39
For More Information...

• Zoltan Home Page
• http//www.cs.sandia.gov/Zoltan
• Users and Developers Guides
• Download Zoltan software under GNU LGPL.
• Email
• zoltan_at_cs.sandia.gov
• kddevin_at_sandia.gov
• rheaphy_at_sandia.gov
