Surface water monitoring in Latvia macrozoobenthos

1
Surface water monitoring in Latvia -
macrozoobenthos

• Didzis Levans
• Natalja Grudule
• State agency "Latvian Environment, geology and
  meteorology agency (LEGMA)

2
Surface water monitoring programs of Latvia
(LEGMA)

• National surface water monitoring program
• ICP-Waters and ICP-IM programs
• Data are sent to EIONET (EUROWATERNET)

3
National surface water monitoring (LEGMA)

• Linked to the EU Water Framework Directive
  (2000/60/EC)
• Based on the Law on Water management designates
  four river basin districts (RBD) for Latvia
• Venta River Basin District
• Lielupe River Basin District
• Gauja River Basin District
• Daugava River Basin District

4
Background of the National surface water
monitoring program with respect to macrozoobenthos

• Sampling frequency - once a year
• Spring or autumn
• Total sampling sites 245 (rivers and lakes)
• Composition and abundance of benthic
  macroinvertebrate fauna (species level)

5
Total number of sampling sites for
macrozoobenthos in 2007
6
Sampling methods

• The methods are used for the rhitral and potamal
  reaches of rivers
• Macroinvertebrate samples are collected with
  hand-net (frame size 25 x 25 cm mesh size of 0.5
  mm)
• In the selected stretches of rivers 10 individual
  macroinvertebrate samples by means of kick
  sampling are taken
• Samples are fixed in etanol (70) solution
• APHA (USA standard methods)

7

• the individual samples are taken according to the
  occurrence of all biotopes in small rivers
• If the rivers are deeper than 1 meter, the
  samples are taken only in costal parts

8
ICP-IM and ICP-Waters programs

• Physically chemical parameters, 12 times per
  year
• Heavy metals - 6 per year
• Biological quality elements - macroinvertebrates
  - 2 per year

9
ICP and IM monitoring stations
1- Rucava 2 Amula, 3 Zvirbuli, 4 Tervete,
5 L. Jugla, 6 Taurene, 7 - Tulija
10
ICP-Waters monitoring sites

• Five sampling points
• Liela Jugla, 0,2 km upstream to Zaki (Daugava
  River basin)
• Tervete, upstream to Tervete (village) (Lielupe
  River Basin)
• Stream of Zvirbuli, Kemeru Bog, (Lielupe River
  Basin)
• Amula (mouth) (Venta River Basin)
• Tulija 0,3 km upstream to Zoseni (Gauja River
  Basin)

11
Observations used for assessment
12
The methods for ICP monitoring

• For ICP Waters, qualitative samples of
  invertebrate fauna from streams or rivers are
  used
• Absence or presence of indicator species reflect
  the water quality
• The methods are the same as used for the
  Integrated monitoring

13
Integrated monitoring

• There are only two sampling stations Taurene
  and Rucava
• The samples are collected twice a year - in
  spring and autumn
• Composition and abundance of benthic
  macroinvertebrate fauna (species level)

14
Additional observations used for assessment
within ICP-IM
15
The methods for Integrated Monitoring

• Macrozoobenthos samples are taken from hard
  bottoms of riffles
• An adequate sampling site often covers a stream
  length of 10 times the width of the stream
• Samples are colleced using the kick-sampling
  method using a hand-net
• Kick-sampling can be performed in waters with
  velocities of 0.1 - 1 m/s and down to 1 m depth

16
The methods for Integrated Monitoring

• Sampling net (frame size 0.25 x 25 cm a mesh
  size of 0.5 mm)
• Sample are transfered into 1 litre jars
  containing 96 ethanol solution
• In laboratory the specimens are identified mainly
  to the species level
• Density (ind/m2) and biomass (g/m2) are estimated
  and also the Shannon-Wiener diversity index
  calculated

17
References how to identify the species to family
level

• 1  Edington J.M., Hildrew A.G. Caseless Caddis
  Larvae (Trichoptera). A Revised Key to the
  Caseless Caddis Larvae of the British Isles, with
  Notes on their Ecology, 1995, 134pp. SP 53.
• 2. Macan T.T. Gastropods. A Key to the British
  Fresh- and Brackish-Water Gastropods, with Notes
  on their Ecology, Fourth edition, 1977 (reprinted
  1994), 46pp. SP 13.
• 3.  Savage A.A. Larval Corixidae, 1999, 56pp. SP
  57.
• 4. Elliott J.M., Humpesch U.H., Macan T.T. Larval
  Mayflies (Ephemeroptera) Larvae of the British
  Ephemeroptera a Key with Ecological Notes, 1988,
  145pp. SP 49.
• 5. Elliott J.M. Alderflies, Lacewings and
  Spongeflies. British Freshwater Megaloptera and
  Neuroptera a Key with Ecological Notes, 1996,
  69pp. SP 54.
• 6.  Cranston P.S. Orthocladiinae Larvae
  (Chironomidae). A Key to the Larvae of the
  British Orthocladiinae (Chironomidae), 1982,
  152pp. SP 45.

18
References how to identify the species to family
level

• 7.   Mundy S.P. Bryozoans. A Key to the British
  and European Freshwater Bryozoans, 1980, 31pp. SP
  41.
• 8. Gledhill T., Sutcliffe D.W., Williams W.D.
  Malacostracan Crustaceans. British Freshwater
  Crustacea Malacostraca a Key with Ecological
  Notes, 1993, 176pp. SP 52.
• 9.       Hynes H.B.N. Stoneflies. A Key to the
  Adults and Nymphs of the British Stoneflies
  (Plecoptera), with Notes on their Ecology and
  Distribution, Third edition, 1977 (reprinted
  1993), 92pp. SP 17.
• 10.   Nilsson, A. (ed.) Aquatic Insects of North
  Europe.
  Vol. 1 Ephemeroptera,
  Plecoptera, Heteroptera, Megaloptera, Neuroptera,
  Coleoptera, Trichoptera and Lepidoptera. 1996.
  274 pages. Vol. 2 Odonata and Diptera. 1997.
  440 pages.
• 11. Swedish Environmental Protection
  Agency Envinonmental Quality Criteria, Lakes and
  Watercourses, Report 5050, 2000.

19
Quality assessment

• The following monitoring data is used to define
  parametric values of indicative parameters that
  characterise chemical elements of ecological
  status and biological element - Saprobity index
  acc. to Sladecek.
• National catalogue of indicator species of
  feshwater saprobity established in 1995.

20
The Final reports of the project ''Transposition
and Implementation of the EU Water Framework
Directive in Latvia'' funded by the DEPA (
DANCEE)

• Classification and presentation of status of
  waters (including proposal for surface water
  reference conditions and network )
• http//www.vidm.gov.lv/eng/projekti/es_vides_proje
  kti/?doc3315

21
Reference conditions in Latvia rivers
