Thermal Management of IGBTs using

1
Thermal Management of IGBTs using
Micro-Capillary Pumped Loops Prof. Scott K.
Thomas (WSU) Dr. Kirk L. Yerkes (AFRL/PRPS) Prof.
Dorian Liepmann (UC Berkeley)
2
What is a µCPL?

• Passive heat transfer device (no moving parts)
• Two-phase (evaporation/condensation)
• Fabricated onto silicon chip using standard
  photolithographic techniques

3
Silicon/Borosilicate Glass Sandwich
Vapor/liquid lines in silicon Evaporator/condenser
grooves in glass
4
Experimental Setup at AFRL/WPAFB
Heat input CO2 laser Heat output water-cooled
calorimeter (0.12 W 10) Insulation Vacuum
chamber w/ thermocouple, power and water
feedthroughs
5
Mounting Fixture for µCPL
Acrylic holding fixture to reduce parasitic heat
losses XYZ stage for positioning within the
vacuum chamber
6
Copper Calorimeter
Mounted to µCPL using RTV sealant Constant head
reservoir controls mass flow rate Thermocouples
located within vacuum chamber Direct mass flow
rate measurement
7
Flow Visualization
