Title: Wavefront Sensing I


1
Wavefront Sensing I
  • Richard Lane
  • Department of Electrical and Computer Engineering
  • University of Canterbury
  • Christchurch
  • New Zealand

2
Location
3
Astronomical Imaging Grouppast and present
  • Dr Richard Lane
  • Professor Peter Gough
  • Associate Professor P. J. Bones
  • Associate Professor Peter Cottrell
  • Professor Richard Bates
  • Dr Bonnie Law Dr Roy Irwan
  • Dr Rachel Johnston Dr Marcos van Dam
  • Dr Valerie Leung Richard Clare
  • Yong Chew Judy Mohr

4
Contents
  • Session 1 Principles
  • Session 2 Performances
  • Session 3 Wavefront Reconstruction for 3D

5
Principles of wavefront sensing
  • Introduction
  • Closed against open loop wavefront sensing
  • Nonlinear wavefront sensing
  • Shack-Hartmann
  • Curvature
  • Geometric
  • Conclusions

6
Imaging a star


7
The effect of turbulence
8
Adaptive Optics system
9
Closed loop system
Reduces the effects of disturbances such as
telescope vibration, modelling errors by the
loop gain
Design limited by stability constraints
Does not inherently improve the noise
performance unless the closed loop measurements
are easier to make
10
Postprocessing systemfeedforward compensation
Distorted incoming wavefront
Detector plane
telescope
Computer
  • Fixed
  • mirror

Wavefront sensor
11
Open loop system (SPID)
Sensitive to modelling errors No stability
issues with computer post processing Problem is
not noise but errors in modelling the system
T
time
Temporal coherence of the atmosphere
12
Modelling the problem (step1)
  • The relationship between the measured data and
    the object and the point spread function is
    linear
  • Data object convolution point spread function
    noise
  • (psf)
  • A linear relationship would mean that if we
    multiply the input by a we multiply the output by
    a. The output doesnt change form

13
Modelling the problem (step 2)
  • The relationship between the phase and the psf is
    non linear
  • psf Fourier magnitude phase correlation
    transform

14
Phase retrieval
Wrapped ambiguity
Correct MAP estimate
ML estimation
MAP estimation
  • Nonlinearity caused by 2p wrapping interacting
    with smoothing

15
Role of typical wavefront sensor
  • To produce a linear relationship between the
    measurements and the phase
  • Speeds up reconstruction
  • Guarantees a solution
  • Degrades the ultimate performance
  • phase weighting basis function

16
Solution is by linear equations
  • Measurement Interaction Basis function
  • vector matrix
    Coefficents
  • ith column of T corresponds to the measurement
    that would occur if the phase was the ith basis
    function
  • Three main issues
  • What has been lost in linearising?
  • How well you can solve the system of equations?
  • Is it the right equations?

17
The effect of turbulence
There is a linear relationship between the mean
slope of the phase in a direction and the
displacement of the image in that direction.
18
Trivial example
  • There is a linear relationship between the mean
    slope and the displacement of the centroid
  • Measurements are the centroids of the data
  • Interaction matrix is the scaled identity
  • Reconstruct the coefficients of the tip and tilt

19
Quality of the reconstruction
  • The centroid proportional to the mean slope
    (Primot el al, Welsh et al).
  • The best Strehl requires estimating the least
    mean square (LMS) phase (Glindemann).
  • To distinguish the mean and LMS slope you need to
    estimate the coma and higher order terms

LMS slope
Mean slope
Phase
20
Difference between the lms and mean tilt
Ideal image
Coma distortion
  • Peak value is better than the centroid for
    optimising the Strehl
  • Impractical for low light data

Detected image
21
Where to from here
  • The real problem is how to estimate higher
    aberration orders.
  • Wavefront sensor can be divided into
  • pupil plane techniques, that measure slopes
    (curvatures) in the divided pupil plane,
  • Shack-Hartmann
  • Curvature (Roddier), Pyramid (Ragazonni)
  • Lateral Shearing Interferometers
  • Image plane techniques that go directly from data
    in the image plane to the phase (nonlinear)
  • Phase diversity (Paxman)
  • Phase retrieval

22
Geometric wavefront sensing
  • Pyramid, Shack-Hartmann and Curvature sensors are
    all essentially geometric wavefront sensors
  • Rely on the fact that light propagates
    perpindicularly to the wavefront.
  • A linear relationship between the displacement
    and the slope
  • Essentially achromatic

23
Geometric optics model
  • A slope in the wave-front causes an incoming
    photon to be displaced by
  • Model is independent of wavelength and spatial
    coherence.

24
Generalized wave-front sensor
  • This is the basis of the two most common
    wave-front sensors.

Converging lens
Aberration
Focal plane
Shack-Hartmann
Curvature sensor
25
Trade-off
  • For fixed photon count, you trade off the number
    of modes you can estimate in the phase screen
    against the accuracy with which you can estimate
    them
  • To estimate a high number of modes you need good
    resolution in the pupil plane
  • To make the estimate accurately you need good
    resolution in the image plane

26
Properties of a wave-front sensor
  • Linearization want a linear relationship between
    the wave-front and the measurements.
  • Localization the measurements must relate to a
    region of the aperture.
  • Broadband the sensor should operate over a wide
    range of wavelengths.
  • ? Geometric Optics regime

27
Explicit division of the pupil
Direct image
Shack-Hartmann
28
Shack-Hartmann sensor
  • Subdivide the aperture and converge each
    subdivision to a different point on the focal
    plane.
  • A wave-front slope, Wx, causes a displacement of
    each image by zWx.

29
Fundamental problem
  • Resolution in the pupil plane is inversely
    proportional to the resolution in the image plane
  • You can have good resolution in one but not both
    (Uncertainty principle)

Pupil
D
w
30
Loss of information due to subdivision
  • Cannot measure the average phase difference
    between the apertures
  • Can only determine the mean phase slope within an
    aperture
  • As the apertures become smaller the light per
    aperture drops
  • As the aperture size drops below r0 (Fried
    parameter) the spot centroid becomes harder to
    measure

31
  • Subdivided aperture

32
Implicit subdivision
  • If you dont image in the focal plane then the
    image looks like a blurred version of the
    aperture
  • If it looks like the aperture then you can
    localise in the aperture

33
Explanation of the underlying principle
  • If there is a deviation from the average
    curvature in the wavefront then on one side the
    image will be brighter than the other

If there is no curvature from the atmosphere
then it is equally bright on both sides of focus.
34
Slope based analysis of the curvature sensor
The displacement of light from one pixel to its
neighbour is s determined by the slope of the
wavefront
35
Slope based analysis of the curvature sensor
  • The signal is the difference between two slope
    signals
  • ?Curvature

36
Phase information localisation in the curvature
sensor
  • Diffraction blurring geometric expansion

37
Curvature sensing
  • Localization comes from the short effective
    propagation distance,
  • Linear relationship between the curvature in the
    aperture and the normalized intensity difference
  • Broadband light helps reduce diffraction effects.

38
Curvature sensing signal
Simulated intensity measurement
Curvature sensing estimate
  • The intensity signal gives an approximate
    estimate of the curvature.
  • Two planes help remove scintillation effects

39
Irradiance transport equation
  • Linear approximation gives

40
Solution inside the boundary
  • There is a linear relationship between the signal
    and the curvature.
  • The sensor is more sensitive for large effective
    propagation distances.

41
Solution at the boundary (mean slope)
  • If the intensity is constant at the aperture,
  • H(z) Heaviside function

I1 I2 I1- I2
42
The wavefront also changes
  • As the wave propagates, the wave-front changes
    according to
  • As the measurement approaches the focal plane the
    distortion of the wavefront becomes more
    important, and needs to be incorpoarated (van Dam
    and Lane)

43
Non-linearity due to the wavefront changing
  • As a consequence the intensity also changes!
  • So, to second order
  • The sensor is non-linear!

44
Origin of terms
  • Due to the difference in the curvature in the x-
    and y- directions (astigmatism).
  • Due to the local wave-front
  • slope, displacing the curvature
  • measurement.

45
Consequences of the analysis
  • As z increases, the curvature sensor is limited
    by nonlinearities K and T.
  • A third-order diffraction term limits the spatial
    resolution to

46
Analysis of the curvature sensor
  • As the propagation distance, z, increases,
  • Sensitivity increases.
  • Spatial resolution decreases.
  • The relationship between the signal and the
    curvature becomes non-linear.

47
Tradeoff in the curvature sensor
  • Fundamental conflict between
  • Sensitivity which dictates moving the detection
    planes toward the focal plane
  • Aperture resolution which dictates that the
    planes should be closer to the aperture

48
Geometric optics model
  • Slopes in the wave-front causes the intensity
    distribution to be stretched like a rubber sheet
  • Wavefront sensing maps the distribution backto
    uniform

49
Intensity distribution as a PDF
  • The intensity can be viewed as a probability
    density function (PDF) for photon arrival.
  • As the wave propagates, the PDF evolves.
  • The cumulative distribution function (CDF) also
    changes.

50
  • Take two propagated images of the aperture.
  • D1 m, r00.1 m and ?589 nm.

Intensity at -z
Intensity at z
51
  • Can prove using the irradiance transport equation
    and the wave-front transport equation that
  • This relationship is exact for geometric optics,
    even when there is scintillation.
  • Can be thought of as the light intensity being a
    rubber sheet being stretched unevenly

52
  • Use the cumulative distribution function to match
    points in the two intensity distributions.
  • The slope is given by

x1 x2
53
Results in one dimension
Actual (black) and reconstructed (red) derivative
54
Simulation results
55
Comparison with Shack-Hartmann
56
Conclusions
  • Fundamentally geometric wavefront sensors are all
    based on the same linear relationship between
    slope and displaced light
  • All sensors trade off the number of modes you can
    estimate against the quality of the estimate
  • The main difference between the curvature and
    Shack-Hartmann is how they divide the aperture
  • Question is how to make this tradeoff optimally.
Write a Comment
User Comments (0)
About PowerShow.com
