WELL LOG ANALYSIS CENTER
Prepared by Marian Kielt, D.Sc on the base OIGW
data
2
CONTENTS

• ORGANIZATION SCHEME
• RANGES OF WELL LOG ANALYSIS
• HISTORY
• STAFF
• MAJOR AREA ACTIVITY
• CUSTOMERS
• DIGITALIZATION, SCANNING AND ARCHIVISATION
  WELL LOGS DATA
• RANGE OF FORMATIONAL WELL LOG ANALYSIS
• ANALYSIS OF OLD LOGS
• DIPMETER DATA
• CAST DATA
• IMAGER DATA
• FULL WAVE SONIC DATA
• GEOLOGICAL WELL LOG ANALYSIS
• DEPTH-TO-TIME TRANSFORMATION OF WELL LOGS
• CASED AND PRODUCTION WELL
  LOGS ANALYSIS

3
(No Transcript)
4
RANGES OF WELL LOG ANALYSIS

• WELL LOG ANALYSIS CENTER specjalized in
• re-standarization of Old-logs
• Russian-type well log analysis (reanimation
  of Old-logs)
• formational analysis of well logs,
• processing of dipmeter data
• structural and stratigraphical analysis of
  dipmeter data
• processing and analysis of FWS
• geological well logs analysis
• depth-to-time transformation of well logs,
  dipmeter processings and results
• scanning / digitizing analog well logs

5
HISTORY

• The GEOFIZYKA TORUN Well Log Analysis began its
  activity in 1968 from the analog data processing
  and then, since 1980 from partial digital data
  processing.
• Tektronix 4051 with Geofiert software
  (Poland) since 1980,
• PC / AT 286 and 386 with GEO software
  (Poland) since 1989
• PC 386 and 486 with digitizers and
  digitizers software (Poland) since 1992
• DEC / AT RS 6000-375 PXG with Halliburtons
  Log Analysis Software and
• SIERRA Geological Software (USA) since 1992
• PC / AT 486 and VAX with scanner and
  scanners software (UK) since 1994
• IBM RS 6000-375 with Log Analysis Software
  and Geological Software
• (HALLIBURTON and SIERRA - USA) since 1994
• PENTIUM II since 1998

6
HISTORY

• IBM RS-6000-590 since 1998
• RDA and EZDIP Dipmeter Analysis Software
  (RESDIP and MHSoft - USA)
• since 1998
• LOGM / MWLA Multi Well Log Analysis Software
  (MWLA - Canada) since
• 1999
• CYCLOLOG Geological Analysis Software (ENRES
  - Holand) since 1999
• PENTIUM III since 1999 and 2000
• PETROLOG Complexional and Muti Well Analysis
  Software (Crocker
• Processing Data - Australia) since 1999 and
  2000
• IBM RISC 6000 since 2000
• DESKTOP PETROPHYSICS III (Well Log Analysis
  Software from HLS -
• USA) since 2000

7
STAFF

• About 27 log analysts and petrophysicists having
  high professional qualifi-cation in range of
  formational and geological analysis of well logs
• analog Old E-logs and digital well logs
  analysis in different geological structures
• (Mesozoic, Zechstein, Rotliegendes,
  Carbonian, Devonian, Sylurian, Ordovician
• and Cambrian Basins of the Polish Lowlands),
• digital well logs analysis in different
  geological structures (Mesozoic, Zechstein,
• Rotliegendes, Carbonian, Devonian,
  Sylurian, Ordovician and Cambrian Basins
• of the German, Latvian, Lithuanian, Polish
  and Russian Baltic Sea Shelf),
• Old E-Logs analysis (geological structures in
  the Sakhalin Island, Bielorusia and
• Lithuania),
• multi well analysis in different geological
  structures (Zechstein, Rotliegendes) of
• the Polish Lowlands,

8
STAFF

• multi well analysis in different geological
  structures (Sylurian, Cambrian)
• of the Polish, Latvian, Lithuanian, Sveden
  and Russian Baltic Sea),
• Old E-Logs analysis (different geological
  units in the Poland),
• dipmeter data processings, also structural
  and stratigraphical analysis in
• the Mesozoic, Zechstein, Rotliegendes,
  Carbonian, Devonian, Sylurian,
• Ordovician and Cambrian Basins of the
  German, Latvian, Lithuanian,
• Polish and Russian Baltic Sea Shelf,
• dipmeter data processings, also structural
  and stratigraphical analysis in
• the Mesozoic, Zechstein, Rotliegendes,
  Carbonian, Devonian, Sylurian,
• Ordovician and Cambrian Basins in the
  Polish Lowlands),

9
STAFF

• FWS processing and mehcanical parametrs
  estimation
• depth-to-time transformation of well logs (for
  seismic interpretation),
• well logs analysis in structural and
  hydrocarbon field scale,
• digital well logging data analysis in the
  different geological structures in
• the (Mesozoic, Zechstein, Rotliegendes,
  Carbonian, Devonian, Sylurian,
• Ordovician and Cambrian Basins of the Polish
  Lowlands),
• well logging data analysis in semi-regional
  and regional scale (lithostra-
• tigraphical correlation and mapping of
  geological and petrophysical
• parameters),
• well logs QC
• well data management

10
MAJOR AREA ACTIVITY
Different geological structures
POLAND SAKHALIN RUSSIA
CUBA
EGIPT

KAZAKHSTAN,

BELORUS

LITHUANIA



RUSSIA
11
CUSTOMERS

• SALT MINES in INOWROCLAW - POLAND
• INVESTGAS - POLAND
• POGC - POLAND
• POLISH GEOLOGICAL INSTITUTE - POLAND
• POLTEX METAN POLAND
• APACHE POLAND
• CAL ENERGY
  POLAND
• CONOCO -
  POLAND
• FRONTIER
  POLAND
• WARMIA POLAND
• MEDUSA POLAND
• RWE-DEA POLAND
  OIL
•
  ANKA SHELL - U. K.
•
  HAMPTON DATA SYSTEMS - U.K.
•
  ROBERTSON - U. K.
•
  SHERITT - CANADA
•
  WINTERSHALL - GERMANY
•
  F / X - GERMANY

12
DIGITALIZATION, SCANNING AND ARCHIVISATION
WELL LOGS DATA

• organization of digitalization and / or
  scanning of well logs data (preparation of
• organization file)
• log guality control (QC)
• digitalization and / or scanning logs,
  especially Old-Logs (Russian-type Logs)
• quality control of scanning and / or
  digitalization processes
• archivisation of digitized and / or scanning
  files
• building of well log data base

13
RANGE OF FORMATIONALWELL LOG ANALYSIS

• preparation of digital well log files (MERGE)
• log quality control
• preparation of composite logs in API
  standards
• pre-interpretation (environments corrections)
• cross-plots and histograms
• multimineral analysis (lithology, porosity,
  saturation) of conventional well logs
• graphical visualization of well logs (API
  standards)
• presentation log data in ASCII standard and /
  or LIS and other formats

14
OIL SATURATION IN MAIN DOLOMITE DEPOSTS
(ZECHSTEIN, POLISH LOWLAND)
15
OIL SATURATION IN CARBONIFEROUS DEPOSITS
(LUBLINIAN SINKLINORIUM, POLAND)
16
ANALYSIS OF OLD LOGS

• log quality control
• preparation of composite logs and diagram in
  API standards
• pre-interpretation (environments corrections)
• reconstruction of pseudo-acoustical and
  pseudo-density profiles for utilities in
• seismic and geological workstations
• estimated symetrical resistivity logs
  (pseudo-laterologs) from BKZ curves
• formational analysis of Old-logs
• presentation log data in ASCII standard and /
  or LIS and other formats
• preparation of digital file for utilities in
  seismic and geological workstations
• graphical visualization of well logs in API
  standards

17
Formational analysis of dolomite profile
18
Formational analysis of complicated lithological
profile
19
DIPMETER DATA

• preparation of digital well logs files (MERGE)
• preparation of composite logs and diagrams in
  API standards
• structural processing of dipmeter data
• stratigraphical processing of dipmeter data
• depth-to-time transformation of geological
  data
• graphical visualization of interpretation
  results
• presentation log data in ASCII standard and /
  or LIS and other formats

20
ORIENTED RESISTIVITY PICTURE Fracture
localization in main dolomite (ZECHSTEIN, POLISH
LOWLANDS, POLAND)
21
RESISTIVITY MAPPING PICTURE Main dolomite
internal structures (ZECHSTEIN, POLISH LOWLANDS,
POLAND)
22
RDA PRESENTATION OF
RESULTS IN TIME
SCALE (CARBONIFEROUS, FORE-SUDETIC MONOCLINE,
POLAND)
23
FAULT VECTOR PICTURE IN DEVONIAN DEPOSITS
LUBLINIAN SINCLINORIUM, POLAND)
24
FAULT VECTOR PICTURE OF DEVONIAN SEDIMENTS
(LUBLINIAN SINCLINORIUM, POLAND)
25
VECTOR PICTURE IN EOLIAN DEPOSITS (ROTLIEGENDES,
POLISH LOWLANDS)
26
CAST DATA
CAST PICTURES IN BASE LIMESTONE (ZECHSTEIN,
POLISH LOWLAND)
27
IMAGER DATA
IMAGER PICTURES IN CARBONATES (MAIN
DOLOMITE - ZECHSTEIN, POLISH LOWLAND)
28
FULL WAVE SONIC DATA
FULL WAVE SONIC WAVEFORM (ZECHSTEIN, POMORIAN
ANTICLINORIUM, POLAND)
29
GEOLOGICAL WELL LOGS ANALYSIS

• analysis of well logs in structural and
  hydrocarbon field scale
• analysis of well logging data in semi-regional
  and regional scale
• structural and stratigraphical analysis of
  dipmeter data
• lithophysical correlation of well profiles
• geologic modeling and mapping
• seismic-well log analysis
• geologic interpretation of borehole profiles
• preparation of composite logs and diagrams in
  API standards
• presentation of log data in ASCII standard and
  / or LIS and other formats

30
DEPTH-TO-TIME TRANSFORMATION OF
WELL LOGS

• preparation of digital well logs file (MERGE)
• reconstruction of pseudoacoustical and
  pseudodensi-ty profiles
• construction of synthetic and pulsed
  seismogram
• preparation of digital files for utilities in
  seismic and geological workstations
• presentation of log data in ASCII standard and
  / or LIS and other formats

31
SELECTED WELL LOGS IN DEPTH AND TIME
SCALE (FORE-SUDETIC MONOCLINE, POLAND)
32
RDA PRESENTATION OF DIPMETER
RESULTS IN TIME SCALE (CARBONIFEROUS,
FORE-SUDETIC MONOCLINE, POLAND)
33
SOFTWARE
CASED AND PRODUCTION WELL LOGS ANALYSIS

• CHARM - cased hole analysis and
• reservoir monitoring
• LDCP - rate of change of the
• impedance curves to indicate the
• presents of cement when the
• contrast of cement and the
• annular fluid is small
• PLA 1, PLA 2, PLA VG -
• production log analysis
• PETROLOG - cement log
• analysis
• also
• DESKTOP PETROPHYSICS
• CHARM - cased hole analysis
• and reservoir monitoring

• preparation of digital well logs
• files (MERGE)
• cased hole analysis
• cement bond log analysis
• production well log analysis
• preparation of diagrams in API
• standards
• presentation log data in ASCII
• standardand / or LIS and other
• formats

34
WATER WELL LOGS ANALYSIS (POMORIAN ANTICLINORIUM,
POLAND)
35
WATER WELL LOGS ANALYSIS (POMORIAN ANTICLINORIUM,
POLAND)
36
PRODUCTION WELL LOGS ANALYSIS (FORE-SUDETIC
MONOCLINE, POLAND)
37
CONTACTS
MARIAN KIELT,
D.Sc. E-mail mkielt_at_geofizyka.torun.
pl fax/ tel 48 - 56 - 65 93 211
cell 48 - 56 - 502 543
