Title: 7'9 Reactions That Create A Chirality Center


1
7.9Reactions That Create A Chirality Center
2
Example
  • Chiral, but racemic

Achiral
3
epoxidation from this direction gives R epoxide
R
4
Example
Br2, H2O
CH3CHCH2Br
OH
  • Chiral, but racemic

Achiral
5
Example
HBr
CH3CHCH2CH3
Br
  • Chiral, but racemic

Achiral
6
Many reactions convert chiral reactants to
chiral products.
  • However, if the reactant is racemic, the product
    will be racemic also.
  • Remember "Optically inactive starting
    materials can't give optically active products."

7
Example
HBr
  • Chiral, but racemic

Chiral, but racemic
8
Example
HO2C
H
H2O
fumarase
CO2H
H
Fumaric acid
(S)-()-Malic acid
9
7.10Chiral MoleculeswithTwo Chirality Centers
  • How many stereoisomers when a particular
    molecule contains two chirality centers?

10
Class Exercise
2
3
  • What are all the possible R and S combinations
    of the two chirality centers in this molecule?

11
2,3-Dihydroxybutanoic acid
2
3
  • What are all the possible R and S combinations
    of the two chirality centers in this molecule?

Carbon-2 R R S S Carbon-3 R S R S
12
2,3-Dihydroxybutanoic acid
2
3
  • 4 Combinations 4 Stereoisomers

Carbon-2 R R S S Carbon-3 R S R S
13
2,3-Dihydroxybutanoic acid
2
3
  • 4 Combinations 4 Stereoisomers
  • What is the relationship between these
    stereoisomers?

Carbon-2 R R S S Carbon-3 R S R S
14
2,3-Dihydroxybutanoic acid
2
3
enantiomers 2R,3R and 2S,3S 2R,3S and 2S,3R
Carbon-2 R R S S Carbon-3 R S R S
15



16
2,3-Dihydroxybutanoic acid
2
3
but not all relationships are enantiomeric
  • stereoisomers that are not enantiomers are
    diastereomers

Carbon-2 R R S S Carbon-3 R S R S
17
Isomers
constitutional isomers
stereoisomers
enantiomers
diastereomers
18
? -9.5
? 9.5
enantiomers
enantiomers
? -17.8
? 17.8



19
Fischer Projections
  • recall for Fischer projection horizontal bonds
    point toward you vertical bonds point away
  • staggered conformation does not have correct
    orientation of bonds for Fischer projection

CO2H
CH3
20
Fischer projections
  • transform molecule to eclipsed conformation in
    order to construct Fischer projection

21
Fischer projections
22
Erythro and Threo
  • stereochemical prefixes used to specify relative
    configuration in molecules with two chirality
    centers
  • easiest to apply using Fischer projections
  • orientation vertical carbon chain

23
Erythro
  • when carbon chain is vertical, same (or
    analogous) substituents on same side of Fischer
    projection

CO2H
H
HO
HO
H
CH3
9.5
9.5
24
Threo
  • when carbon chain is vertical, same (or
    analogous) substituents on opposite sides of
    Fischer projection

17.8
17.8
25
Two chirality centers in a ring
S
R
S
R
trans-1-Bromo-1-chlorocyclopropane
  • nonsuperposable mirror images enantiomers

26
Two chirality centers in a ring
S
S
R
R
cis-1-Bromo-1-chlorocyclopropane
  • nonsuperposable mirror images enantiomers

27
Two chirality centers in a ring
S
S
R
R
cis-1-Bromo-1-chloro-cyclopropane
trans-1-Bromo-1-chloro-cyclopropane
  • stereoisomers that are notenantiomers
    diastereomers

28
7.11Achiral MoleculeswithTwo Chirality Centers
  • It is possible for a molecule to have chirality
    centers yet be achiral.

29
2,3-Butanediol
3
2
  • Consider a molecule with two equivalently
    substituted chirality centers such as
    2,3-butanediol.

30
Three stereoisomers of 2,3-butanediol
2R,3R
2S,3S
2R,3S
chiral
chiral
achiral
31
Three stereoisomers of 2,3-butanediol
2R,3R
2S,3S
2R,3S
chiral
chiral
achiral
32
Three stereoisomers of 2,3-butanediol
these two areenantiomers
2R,3R
2S,3S
chiral
chiral
33
Three stereoisomers of 2,3-butanediol
these two areenantiomers
2R,3R
2S,3S
chiral
chiral
34
Three stereoisomers of 2,3-butanediol
the third structure is superposable on
its mirror image
2R,3S
achiral
35
Three stereoisomers of 2,3-butanediol
  • therefore, this structure and its mirror
    imageare the same
  • it is called a meso form
  • a meso form is an achiral molecule that has
    chirality centers

2R,3S
achiral
36
Three stereoisomers of 2,3-butanediol
CH3
  • therefore, this structure and its mirror image
    are the same
  • it is called a meso form
  • a meso form is an achiral molecule that has
    chirality centers

H
HO
H
HO
CH3
2R,3S
achiral
37
Three stereoisomers of 2,3-butanediol
  • meso forms have a plane of symmetry and/or a
    center of symmetry
  • plane of symmetry is most common case
  • top half of molecule is mirror image of bottom
    half

2R,3S
achiral
38
Three stereoisomers of 2,3-butanediol
A line drawnthe center ofthe Fischer
projection of ameso formbisects it intotwo
mirror-image halves.
2R,3S
achiral
39
Cyclic compounds
meso
S
R
There are three stereoisomers of
1,2-dichloro-cyclopropane the achiral (meso)
cis isomer and two enantiomers of the trans
isomer.
40
7.12MoleculeswithMultiple Chirality Centers
41
How many stereoisomers?
  • maximum number of stereoisomers 2n
  • where n number of structural units capable of
    stereochemical variation
  • structural units include chirality centers and
    cis and/or trans double bonds
  • number is reduced to less than 2n if meso forms
    are possible

42
Example
  • 4 chirality centers
  • 16 stereoisomers

43
Cholic acid (Figure 7.12)
  • 11 chirality centers
  • 211 2048 stereoisomers
  • one is "natural" cholic acid
  • a second is the enantiomer of natural cholic acid
  • 2046 are diastereomers of cholic acid

44
How many stereoisomers?
  • maximum number of stereoisomers 2n
  • where n number of structural units capable of
    stereochemical variation
  • structural units include chirality centers and
    cis and/or trans double bonds
  • number is reduced to less than 2n if meso forms
    are possible

45
How many stereoisomers?
  • 3-Penten-2-ol

R
E
E
S
H
OH
HO
H
R
Z
Z
S
OH
H
H
HO
