Basic circulatory route

1
Blood Vessels and Hemodynamics
2
Chapter 21The Cardiovascular System Blood
Vessels and Hemodynamics

• Structure and function of blood vessels
• Forces involved in circulating blood
• Major types of circulation to be studied in lab

3
Basic circulatory route
Heart
Arteries
Veins
Arterioles
Capillaries
Venules
Tissues
4
Structure of Vessels

• Comparison of Arteries and Veins

• Blood flows away from heart in ________

arteries

• Blood flows toward heart in ______

veins

• Arteries are thicker than veins

• Veins have regularly spaced valves

• Which vessels have the highest pressure?

• Which vessels carry about 64 of the blood?

5
Distribution of Blood
6
Vessel Structure(Artery)
-----------------Tunica Interna
Endothelium, Basement Membrane Elastic Fibers
---------------Tunica Media
Smooth Muscle Elastic Fibers
------------Tunica Externa
Collagen Elastic Fibers
7
Types of Arteries

• Elastic Arteries (gt1cm)

• Less muscle and more elastic tissue

• Larger arteries such as aorta

• Why do the larger arteries have more elastic
  tissue? What purpose do they serve?

8
Types of Arteries Continued

• Muscular Arteries (0.1 10mm)

• Less elastic tissue and more muscle

• Medium size to smaller arteries

• Capable of greater vasoconstriction and
  vasodilation to adjust rate of flow

9
Smaller Vessels

• Arterioles

-Smallest arteries (10 100 ?m)
- Deliver blood to capillaries
- Smallest ones lose tunica externa
- Called resistance blood vessels because their
vasoconstriction (decrease in diameter) increases
resistance, and their vasodilation (relaxation)
decreases resistance to blood flow in the arteries
10
Capillaries (4 10 ?m)

• Microscopic vessels form microcirculation

• Tubes of endothelium and basement membrane

• Connect arterioles to venules

• Function in exchange of substances with tissues

• Interconnect like a net to form capillary beds

11
Venules (10 100 ?m)

• Small veins that collect blood from capillaries

• Tunica media contains only a few smooth muscle
  cells scattered fibroblasts

• Rather porous endothelium

12
MicrocirculationArterioles, Capillaries and
Venules
-------------------Arteriole
---------------Capillary
------Venule
13
Anastomoses

• Union of 2 or more arteries supplying the same
  body region
• Alternate route of blood flow through an
  anastomosis is known as collateral circulation
• Can also occur in veins, arterioles and venules

14
Physiology of Circulation-Blood Pressure

• Blood pressure (BP) is the force the blood exerts
  against vessel walls

• Difference in blood pressure (pressure gradient)
  along vessels causes blood to flow

• Blood flows from higher to lower pressure

• Pressure is highest in the aorta and lowest in
  the vena cavae

Though blood pressure is in every blood vessel,
most of our discussion will concern arterial
blood pressure
15
Blood Flow

• Two factors are responsible for blood pressure
• Blood flow
• Resistance to blood flow

• Amount of blood flowing through vessels per unit
  of time (milliliters per minute)
• What is causes blood to flow?
• Which direction does it flow?

16
Resistance (R) to blood flow

• Produced as the blood encounters friction and
  turbulence against the vessel and heart walls

• For blood to flow, blood pressure (BP) must
  overcome resistance (R)

• Increased resistance decreases blood flow

• Greatest resistance is in arterioles-called
  peripheral resistance (PR)

17
Blood Pressure Formula

• Blood pressure Flow X Resistance

• ?Flow causes ?BP, ?Flow causes ?BP

• ?R causes ?BP, ?R causes ?BP

18
Which of the following is true?

• Blood flows from lower to higher pressure
• 2. ? resistance causes ? blood pressure
• 3. ? resistance causes ? blood pressure
• 4. ? blood flow causes ? blood pressure

19
Factors in Flow and Resistance

• Factors in Flow

• Cardiac Output (CO)

Amount of blood ejected by left ventricle in
one minute

• Blood volume

Total amount of blood in body

• More than 10 drop causes drop in BP

20
Factors in Resistance

• Diameter of vessels, especially arterioles

vasoconstriction
Has arterial BP increased or decreased?

• Viscosity of blood

• Length of vessels

21
Flow and Blood PressureBlood flow in redBlood
pressure in green
22
Resistance and Blood PressureBlack arrows
represent vasoconstriction
23
Measurements of Arterial blood pressure

• Systolic pressure(SP) and diastolic pressure (DP)

• Systolic pressure(SP)

• Pressure in arteries when left ventricle is
  contracting

• High number on blood pressure reading

• Diastolic pressure(DP)

• Pressure in arteries when left ventricle is
  relaxing

• Low number on blood pressure reading

24
Measuring Arterial BP

• BP measured in millimeters of mercury (mm Hg)

• Use sphygmomanometer

• Usually taken in upper arm

• High number is systolic pressure

• Low number is diastolic pressure

• Typical reading is 120 mmHg/80 mmHg

• 140/90 or above considered high

25
Sphygmomanometer
26
The low number of a blood pressure reading occurs
when the _______________.
1. ventricle is pumping 2. ventricle is
relaxing 3. AV valves are closed 4. SLvalves
are open
27
Other Pressures

• Pulse pressure (PP)

• Difference in Systolic and diastolic pressures or
  PPSP-DP

• High during exercise, anxiety, influence of
  certain drugs and with hardening of arteries

• Mean Arterial Blood Pressure (MAP or MABP)

• Single measure of arterial BP

• Formula

MAP Diastolic Pressure (Pulse Pressure ?3)
28
The mean arterial blood pressure for a BP of
120/75 is _____________.
1. 80 mmHg 2. 90 mmHg 3. 95 mmHg 4. 100 mmHg
29
Pressure Gradients Different Vessels

• Arterial Pressure Gradient

• Difference in arterial pressure from Aorta to
  capillaries

• Averages about 60 mmHg

• Capillary Pressure Gradient

• Difference in pressure from arteriole to venule
  side of capillary bed

• Averages about 20 mmHg

• Venous Pressure Gradient

• Difference in pressure from venules to Vena cavae

• Averages about 16 mmHg

30
Blood Pressures in Various Vessels
31
Capillary Exchange

• Passage of water and solutes between capillary
  plasma and interstitial fluid

• Three Methods

- Diffusion is movement of solute from ____ to
____ concentration
high
low
- Transcytosis is movement of large molecules
across capillary cells by ________________________
____
formation of pinocytotic vesicles
32
Capillary Exchange Continued

• Bulk Flow Movement of water and solute between
  the blood and interstitial fluid because of
  differences in pressure.

- Movement of fluid and solute from capillaries
into interstitial fluid is _______
filtration
- Movement of fluid and solute from interstitial
fluid into capillaries is __________
reabsorption
33
(No Transcript)
34
Bulk Flow continued

• Two opposing pressures at work

- Blood Hydrostatic Pressure (BHP) is the blood
pressure that pushes fluid out of blood. What
produces it?
- Blood Osmotic Pressure (BOP, AKA BCOP) is a
suction pressure that pulls fluid into blood
Opposing Pressures
BHP BOP
Blood pressure pushes fluid out
Blood osmotic pressure pulls fluid in
Capillary cross-section
35
Capillary Exchange Continued
? means greater than

• Mechanism of Filtration and Reabsorption

?
- On arteriole side of capillary, BHP BOP
push pull
?
?
-On venule side of capillary, BOP BHP pull
push
?
- Higher BHP on arteriole side pushes water and
solute from capillary into interstitial fluid -
filtration
- Higher BOP on venule side pulls water and
solute from interstitial fluid into capillary -
reabsorption
36
Capillary Exchange Diagram
Lymph Capillary
Filtration
Reabsorption
BHP (push) (35 mmHg)
BOP (pull) 26 mmHg
BOP (pull) (26 mmHg)
BHP (push) (16 mmHg)
Blood Capillary
37
Which of the following causes capillary
filtration?
1 BOPgtBHP 2 BHPgtBOP 3 BHPBOP 4 vasoconstriction
38
Venous pressure and venous return

• Venous pressure is very low and can not account
  for all of the return of blood to heart

• Factors that aid in venous return

- Contraction of skeletal muscles squeeze
veins and push blood toward
heart
- Breathing helps
- Venous valves prevent backflow of blood once
it is squeezed past them
39
Illustration of Venous Return
40
Blood Pressure Regulation

• Local regulation within tissues
• Central (neural) regulation by brain

41
Local Regulation
Assures proper blood flow into capillaries
Tissues regulate blood flow to meet their
needs Changes in blood chemistry, and
temperature cause vasodilation or
vasoconstriction -What chemicals cause
vasodilation and increased blood flow into
capillaries? -What is relationship between
temperature and change of blood flow to
capillaries?
42
Central Control of Blood Pressure Flow

• Role of Cardiovascular Centers -
  cardioacceleratory, cardioinhibitory vasomotor
  centers of the medulla oblongata

- Help regulate heart rate stroke volume
- Specific neurons regulate vessel diameter
- Regulate by input from sensory receptors and
output to heart
43
Input to the Cardiovascular Center

• Higher brain centers such as cerebral cortex,
  limbic system hypothalamus

- anticipation of competition
- increase in body temperature

• Proprioceptors in muscles and tendons

- input during physical activity

• Baroreceptors in blood vessels

- changes in pressure within blood vessels

• Chemoreceptors in blood vessels and brain

- monitor concentration of chemicals in the blood
44
Output from the Cardiovascular Center

• Heart

- Parasympathetic (vagus nerve) - decreased heart
rate
- Sympathetic (cardiac accelerator nerves) -
increased contractility rate

• Blood vessels

- Sympathetic vasomotor nerves

• Decreased stimulation produces dilation
  decreased BP

• Increased stimulation produces constriction
  increased BP

45
Input and Output Summary
46
Neural Regulation of Blood Pressure
Aortic/Carotid Reflexes

• Baroreceptor reflexes (AKA Left Heart Reflex)

- Carotid sinus reflex

• Receptors in carotid artery wall

• Sensory input to cardiovascular center in medulla

• Maintains normal BP in the brain

- Aortic reflex

• Receptors in wall of ascending aorta

• Sensory input to cardiovascular center in medulla

• Maintains general systemic BP

47
Innervation of the Heart

• Sensory information from baroreceptors
• Speed up the heart with sympathetic stimulation
• Slow it down with parasympathetic stimulation (X)
• Cause vasodilation or vasoconstriction

48
Baroreceptors monitor blood pressure. What
adjustments would occur if blood pressure to the
brain were to suddenly decrease?

• 1. ? cardiac output and widespread vasodilation
• 2. ? cardiac output and widespread
  vasoconstriction
• 3. ? cardiac output and widespread vasodilation
• 4. Nothing

49
Chemoreceptor Reflexes

• Carotid bodies and aortic bodies
• Detect changes in blood levels of O2, CO2, and H
  (hypoxia, hypercapnia or acidosis )
• Cause stimulation of cardiovascular center
• Increases sympathetic stimulation to heart
  vessels
• ?Cardiac output and increase in blood pressure
• Also affect breathing rates

50
Hormonal Regulation of Blood Pressure

• Renin-angiotensin-aldosterone (RAA) system
• Decrease in BP or decreased blood flow to kidney
• Release of renin results in 2 steps that form
  angiotensin II
• Systemic vasoconstriction increases resistance
• Causes ?NaCl (salt) reabsorption, and increased
  salt results in
• ________________________________________________
• Epinephrine norepinephrine
• Increases heart rate force of contraction
• Causes vasoconstriction in skin abdominal
  organs
• Vasodilation in cardiac skeletal muscle
• Antidiuretic hormone (ADH) causes
  vasoconstriction and water retention

51
Carotid baroreceptors monitor pressure in the
__________________

• (A) kidneys
• (B) brain
• (C) heart
• (D) lungs

52

• Which of the following maintains adequate blood
  pressure to the brain when a person stands up?
• (A) ?stimulation of carotid baroreceptors with
  reflex slowing of the heart and vasodilation
• (B) ?stimulation of carotid baroreceptors with
  reflex slowing of the heart and vasoconstriction
• (C) ?stimulation of carotid baroreceptors with
  reflex speeding-up of the heart and
  vasoconstriction
• (D) ?stimulation of carotid baroreceptors with
  reflex slowing of the heart and vasodilation

53
Clinical Terms

• Hypertension
• Aneurysm

Hypertension and salt
54

• Claudication
• Deep Venous Thrombosis
• Phlebitis
• Phlebotomist
• Venipuncture
