Title: CCD Optical Calibration


1
CCD Optical Calibration
  • Steve Malton, UCL
  • Laserwire meeting, Oxford
  • June 9th 2004

2
Overview
  • Optics Layout
  • Current Configuration
  • New Optical System
  • Lens placement
  • IP and image spot travel range
  • Image spot size
  • Knife-edge Scans
  • CCD Resolution
  • Summary

3
Optics Layout
  • Laser focus at IP
  • IP spot imaged at CCD1
  • ss2 sy2 w2
  • CCD2 measures input beam radius
  • wIP M2 l f / w0

4
Current Configuration
2f
2f
  • PAC 076 imaging lens
  • 125 mm focal length
  • w0 0.01mm
  • Misplacement of imaging lens
  • 8 spot size for 10mm offset

Image spot size
Offset from ideal lens position (mm)
5
Travel Range 4f
  • Piezo-scanner has full scan range 5mrad at 10V
  • 8 in travel range for 10mm offset

Beam translation at CCD per volt applied to
piezo-scanner
Offset from ideal lens position (mm)
6
New Optical System
  • 2 lenses
  • Collimate
  • Refocus
  • Lens 1 placement
  • Can test collimation using CCDs
  • Lens 2 placement
  • irrelevent
  • CCD placement
  • Minimise image
  • 11 imaging produces small spot size
  • If f1 ? f2, get magnification

f1
f2
7
Collimated Beam
Travel per volt at CCD (mm)
  • Assuming we can measure 10µm variation, sampling
    over 1m
  • Lens 1, placement to 0.1mm
  • lt 0.1 in travel range

Beam radius after collimation (mm)
Beam spot size at CCD (mm)
8
Travel Range - New
  • Translation of spot at IP 62.0431 mm per volt
    applied to scanner
  • Translation of spot at CCD 62.0239mm/V

IP
Post-IP
9
Knife-Edge Scans
  • Measure total intensity at photodiode
  • 3 translation stages
  • Crossed x-y stages, coarse
  • Picomotor stage, fine
  • x-position
  • Picomotor steps
  • Interferometer to calibrate step size

PICOMOTOR
STAGE
10
Example of knife edge
  • Knife edge is stepped through the laser by the
    picomotor stage
  • Intensity measured by photodiode
  • Fit to error function for beam radius wbeam

11
Stage calibration
  • Fitted wbeam at points along laser axis
  • Measurement with interferometer calibrates stage
    step size

Forward
Beam Spot Size 2 s (microns)
Reverse
Interferometer
Knife-edge position (microns)
12
CCD Resolution
  • Current setup at RHUL
  • (Splitter CCD) distance matched to (splitter
    knife edge)
  • Measure different beam sizes by moving focussing
    lens
  • Compare wccd against wknife

13
Summary
  • 2 lens imaging system
  • Better lens placement
  • Image travel range and beam spot size closer to
    IP values
  • Testing performance of both systems _at_ RHUL
  • Knife edge scans
  • Fit for beam radius
  • To cross check with CCD beam size
  • CCD Resolution
  • compare wccd and wknife
