1
STULZ TeleCompTrol Version 3.3
2
STULZ TeleCompTrol Version 3.3

• Operating System
• - Windows 95 / 98 / 2000 / NT
• Copy Protection by Dongle (Copy Protection Plug)
• Coupling via BUS - and / or Modem - Connection
• Alarm Monitoring
• Alarm Reforwarding via SMS
• Unit Status - inquiry (manually)
• Unit Status - Scanning (automatically)

3
STULZ TeleCompTrol Set-up
PC with Stulz Monitoring Program
Mobile Phone SMS
Alarm Reforwarding
4
Standard Window
5
Password Protection

• Password Protection in 3 Levels
• 1. Administrator Level Access to all Program
  Functions
• 2. User Level 1 Read / Write Access only
• 3. User Level 2 Read Access only

6
Interface Allocation

• Allocation of COM Ports
• Alarm - Channel
• Scan - Channel (Modem)
• Scan - Channel (Bus)
• Parallel Use of BUS - and MODEM -
  Connection requires a 3. COM Port

7
Configuration Alarm-/Scan-Channel
8
Alarm Reforwarding

• 2 Alarm Reforwards via Modem
• Suitable Receivers
• - PC with Telemonitoring Software
• - Handy via SMS Service (TAP or UCP Protocol)

9
Configuration of unit groups
10
Configuration of unit groups

• Definition of Group- Names and SDC - ID
• SDC - Password
• Configuration BUS - or Modem - Connection
• Unit Scanning
• - Cycles between 1 - 24 h - Status Hitory up
  to 168 h

11
Alarm Messages

• Alarm Messages can be stored as txt - File

12
Connection Window
