Gyprock ShadowSet

1
Gyprock ShadowSet

• The easy-to-install finishing touch
• for contemporary homes

2
ShadowSetTM A more dramatic effect - for a
lower installation cost

• Paper-wrapped plasterboard profile
• 10mm thick. Fibre reinforced.
• 105mm broad flat section
• 12mm stepped recess on one edge.
• Plant-On or Flush installation
• Unique to Gyprock
• Patent pending
• Registered design

3
Plant-On Installation

• Install ceiling sheets min. 30mm from the
  plasterboard wall (40mm from the frame)
• Use Gyprock RE/SE with the square edge at the
  ceiling level, or install plasterboard sheets
  vertically, or fill any recess in the wall lining
  at the ceiling level.
• Install top wall sheets first, finishing close to
  the ceiling joists
• For rendered brick applications, it may be
  necessary to check in ceiling joists or use
  furring channel to lower the ceiling
• Fix ShadowSet using Gyprock Cornice Cement.
  Gyprock screws may be used to hold the profile
  in place until the cement sets.
• Fill gaps between the wall sheet and the edge of
  the ShadowSet profile with Gyprock Wet Area
  Acrylic Sealant.

4
ShadowSetTM Flush Application

• Install wall sheets (as for Plant on)
• Install Rondo 308 or 129 furring channel to the
  ceiling joists
• At end walls, the furring channel must stop at
  least 30mm short of the wall linings
• Fix ShadowSet to the furring channel using
  plasterboard screws at max. 600mm centres.
• Alternatively, check in ceiling joists, ensuring
  structural and ceiling height requirements are
  met
• Fill any gaps between the wall sheet and the edge
  of the ShadowSet profile with Gyprock Wet Area
  Acrylic Sealant.
• Trim the recessed edge from the ceiling sheet and
  butt the edge up to the edge of the ShadowSet
• Tape and set as for a plasterboard butt joint.

5
Gyprock RE/SE Plasterboard makes it easy

• RE/SE 1210mm x 6000mm and 1350 x 6000mm is now
  widely available.
• With standard RE/RE board, there is a risk of
  some of the recess showing near the cornice or
  the skirting.
• 1210mm will cover standard 2440mm frame heights
  without cutting. (10mm bottom gap 1210mm
  1210mm 10mm top gap or to cover variation).
• 1350mm will cover 2740mm frame heights, by
  increasing the bottom gap to 30mm or 40mm. These
  project typically have wider skirtings.

6
ShadowSet is 25 lower cost than square set
ShadowSet is 50 lower cost than P 50.

7
Important Information for Carriers
As CSRs new cornice Gyprock ShadowSetTM is flat,
it needs to be handled a little more carefully,
to minimise risks of damage

• Carry on edge (rather than horizontally)
• It is best carried by two people. (Be safe
  avoid damage)
• Where carried by one person, carry with hands 1
  metre apart, lift slowly to avoid flexing and
  always lift with your legs
• Stack in the same way as stacked on the pallet
• These recommendations apply for all cornices,
  though are particularly important for flat
  profiles, like ShadowSet.

Specifications Length 4200mm
