Imprecise probabilities in engineering design

1
Imprecise probabilities in engineering design

Scott Ferson Applied Biomathematics scott_at_ramas.co
m Workshop on Uncertainty Representation in
Robust and Reliability-based Design ASME
DETC/CIE, Philadelphia, 10 September 2006
2
Imprecise probabilities (IP)

• Credal set (of possible probability measures)
• Relaxes the idea of a single probability measure
• Coherent upper and lower previsions
• de Finettis notion of a fair price
• Generalizes probability and expectation
• Gambles

3
Three pillars of IP

• Behavioral definition of probability
• Can be operationalized
• Natural extension
• Linear programming to compute answers
• Rationality criteria
• Avoiding sure losses (Dutch books)
• Coherence (logical closure)

ASL means you cannot be made into a money
pump Inverted interval bounds on a probability
would violate ASL Coherence means fully
recognizing the implications of your betting
rates P(A ? B) gt P(A) P(B), for disjoint A and
B, would violate coherence
4
Probability of an event

• Imagine a gamble that pays one dollar if an event
  occurs (but nothing otherwise)
• How much would you pay to buy this gamble?
• How much would you be willing to sell it for?
• Probability theory requires the same price for
  both
• By asserting the probability of the event, you
  agree to buy any such gamble offered for this
  amount or less, and to sell the same gamble for
  any amount less than or equal to this fair
  price and for every event!
• IP just says, sometimes, your highest buying
  price might be smaller than your lowest selling
  price

5
Credal set

• Knowledge and judgments are used to define a set
  of possible probability measures M
• All distributions within bounds are possible
• Only distributions having a given shape
• Probability of an event is within some interval
• Event A is at least as probable as event B
• Nothing is known about the probability of C

6
IP generalizes other approaches

• Probability theory
• Bayesian analysis
• Worst-case analysis, info-gap theory
• Possibility / necessity models
• Dempster-Shafer theory, belief / plausibility
  functions
• Probability intervals, probability bounds
  analysis
• Lower/upper mass/density functions
• Robust Bayes, Bayesian sensitivity analysis
• Random set models
• Coherent lower previsions

DeFinetti probability measures Credal
sets Distributions with interval-valued
parameters Contamination models Choquet
capacities, 2-monotone capacities
7
Assumptions

• Everyone makes assumptions
• But not all sets of assumptions are equal!
• Linear Gaussian Independent
• Montonic Unimodal Known correlation sign
• Any function Any distribution Any dependence
• IP doesnt require unwarranted assumptions
• Certainties lead to doubt doubts lead to
  certainty

8
Activities in engineering design

• Decision making
• Optimization
• Constraint propagation
• Convolutions
• Arithmetic
• Logic (event trees)
• Updating
• Validation
• Sensitivity analyses

often
sometimes
a lot
9
Convolutions (i.e., adding, multiplying,
and-gating, or-gating, etc., for quantifying the
reliability or risk associated with a design)
10
Probability boxes (p-boxes)
Interval bounds on an cumulative distribution
function (CDF)
1
Cumulative probability
0










1.0

2.0




3.0


0.0
X
11
A few ways p-boxes arise
1
CDF
0
Precise distribution
12
P-box arithmetic (and logic)

• All standard mathematical operations
• Arithmetic operations (, ?, , , , min, max)
• Logical operations (and, or, not, if, etc.)
• Transformations (exp, ln, sin, tan, abs, sqrt,
  etc.)
• Other operations (envelope, mixture, etc.)
• Faster than Monte Carlo
• Guaranteed to bounds answer
• Optimal answers generally require LP

13
Example

• Calculate A B C D, with partial
  information
• As distribution is known, but not its parameters

• Bs parameters known, but not its shape
• C has a small empirical data set
• D is known to be a precise distribution
• Bounds assuming independence?
• Without any assumption about dependence?

14

• A lognormal, mean .5,.6, variance
  .001,.01)
• B min 0, max 0.5, mode 0.3
• C sample data 0.2, 0.5, 0.6, 0.7, 0.75, 0.8
• D uniform(0, 1)

1
1
A
B
CDF
0
0
0
0.2
0.4
0.6
0
1
1
1
D
C
CDF
0
0
0
1
0
1
15
ABCD
1
Under independence
0











1.0

2.0




3.0


0.0
16
Generalization of methods

• Marries interval analysis with probability theory
• When information abundant, same as probability
  theory
• When inputs only ranges, agrees with interval
  analysis
• Cant get these answers from Monte Carlo methods
• Fewer assumptions
• Not just different assumptions
• Distribution-free methods
• Rigorous results
• Automatically verified calculations
• Built-in quality assurance

17
Can uncertainty swamp the answer?

• Sure, if uncertainty is huge
• This should happen (its not unhelpful)
• If you think the bounds are too wide, then put in
  whatever information is missing
• If there isnt any such information, do you want
  the results to mislead?

18
Decision making
19
Knights dichotomy

• Decisions under risk
• The probabilities of various outcomes are known
• Maximize expected utility
• Not good for big unique decisions or when
  gamblers ruin is possible
• Decisions under uncertainty
• Probabilities of the outcomes are unknown
• Several strategies, depending on the analyst

20
Decisions under uncertainty

• Pareto (some strategy dominates in all scenarios)
• Maximin (largest minimum payoff)
• Maximax (largest maximum payoff)
• Hurwicz (largest average of min and max payoffs)
• Minimax regret (smallest of maximum regret)
• Bayes-Laplace (maximum expected payoff assuming
  scenarios are equiprobable)

21
Decision making in IP

• State of the world is a random variable, X ? X
• Outcome (reward) of an action depends on X
• We identify an action a with its reward fa X ?
  R
• In principle, wed like to choose the decision
  with the largest expected reward, but how do we
  do this?
• We explore how the decision changes for different
  probability measures in M, the set of possible
  ones

22
Comparing actions a and b

• Strictly preferred a gt b Ep( fa) gt Ep( fb) for
  all p ?M
• Almost preferred a ? b Ep( fa) ? Ep( fb) for
  all p ?M
• Indifferent a ? b Ep( fa) Ep( fb) for all p
  ?M
• Incomparable a b Ep( fa) lt Ep( fb) and
• Eq( fa) gt Eq( fb) some p,q ?M
• where Ep( f ) p(x) f (x), and
• M is the set of possible probability distributions

? x ? X
23
E-admissibility

• Vary p in M and, assuming it is the correct
  probability measure, see which decision emerges
  as the one that maximizes expected utility
• The result is the set of all such decisions for
  all p ? M

24
Alternative maximality

• Maximal decisions are undominated for some p
• Ep( fa) ? Ep( fb), for some action b, for some p
  ? M
• Actions cannot be
• linearly ordered,
• but only partially
• ordered

25
Another alternative ?-maximin

• We could take the decision that maximizes the
  worst-case expected reward
• Essentially a worst-case optimization
• Generalizes two criteria from traditional theory
• Maximize expected utility
• Maximin

26
Several IP decision criteria
?-maximax
?-maximin
E-admissible
maximal
interval dominance
27
Example
(due to Troffaes 2004)

• Suppose we are betting on a coin toss
• Only know probability of heads ? 0.28, 0.7
• Want to decide among six available gambles
• 1 Pays 4 for heads, pays 0 for tails
• 2 Pays 0 for heads, pays 4 for tails
• 3 Pays 3 for heads, pays 2 for tails
• 4 Pays ½ for heads, pays 3 for tails
• 5 Pays 2.35 for heads, pays 2.35 for tails
• 6 Pays 4.1 for heads, pays ?0.3 for tails

f1(H) 4, f1(T) 0 f2(H) 0, f2(T) 4 f3(H)
3, f3(T) 2 f4(H) ½, f4(T) 3 f5(H)
2.35, f5(T) 2.35 f6(H) 4.1, f6(T) ?0.3
28
E-admissibility

• M is a one-dimensional space of probability
  measures
• Probability Preference
• p(H) lt 2/5 2
• p(H) 2/5 2, 3 (indifferent)
• 2/5 lt p(H) lt 2/3 3
• 2/5 lt p(H) lt 2/3 1, 3 (indifferent)
• 2/3 lt p(H) 1

29
Criteria yield different answers
?-maximax 2
?-maximin 5
E-admissible 1,2,3
maximal 1,2,3,5
interval dominance 1,2,3,5,6
30
So many answers

• Topic of current discussion and research
• Different criteria are useful in different
  settings
• The more precise the input, the tighter the
  outputs
• ? criteria usually yield only one decision
• ? criteria not good if many sequential decisions
• Some argue that E-admissibility is best overall
• Maximality is close to E-admissibility, but much
  easier to compute, especially for large problems

31
IP versus traditional approaches

• Decisions under IP allow indecision when your
  uncertainty entails it
• Bayes always produces a single decision (up to
  indifference), no matter how little information
  may be available
• IP unifies the two poles of Knights division
  into a continuum

32
Comparison to Bayesian approach

• Axioms identical except IP doesnt use
  completeness
• Bayesian rationality implies not only avoidance
  of sure loss coherence, but also the idea that
  an agent must agree to buy or sell any bet at one
  price
• Uncertainty of probability is meaningful, and
  its operationalized as the difference between
  the max buying price and min selling price
• If you know all the probabilities (and utilities)
  perfectly, then IP reduces to Bayes

33
Why Bayes fares poorly

• Bayesian approaches dont distinguish ignorance
  from equiprobability
• Neuroimaging and clinical psychology shows humans
  strongly distinguish uncertainty from risk
• Most humans regularly and strongly deviate from
  Bayes
• Hsu (2005) reported that people who have brain
  lesions associated with the site believed to
  handle uncertainty behave according to the
  Bayesian normative rules
• Bayesians are too sure of themselves (e.g.,
  Clippy)

34
Robust Bayes

35
Derivation of Bayes rule

• P(A B) P(B) P(A B) P(B A) P(A)
• P(A B) P(A) P(B A) / P(B)
• The prevalence of a disease in the general
  population is 0.01.
• If a diseased person is tested, theres a 99.9
  chance the test is positive.
• If a healthy person is tested, theres a 99.99
  chance the test is negative.
• If you test positive, whats the chance you have
  the disease?

Almost all doctors say 99 or greater, but the
true answer is 50.
36
Bayes rule on distributions

• posterior ? prior ? likelihood

posterior (normalized)
likelihood
prior
37
Two main problems

• Subjectivity required
• Beliefs needed for priors may be inconsistent
  with public policy/decision making
• Inadequate model of ignorance
• Doesnt distinguish between ignorance and
  equiprobability

38
Solution study robustness

• Answer is robust if it doesnt depend sensitively
  on the assumptions and inputs
• Robust Bayes analysis, also called Bayesian
  sensitivity analysis, investigates this

39
Uncertainty about the prior

• class of prior distributions ? class of posteriors

posteriors
priors
likelihood
40
Uncertainty about the likelihood
class of likelihood functions ? class of
posteriors
posteriors
likelihoods
prior
41
Uncertainty about both
Posteriors
Priors
Likelihoods
42
Uncertainty about decisions

• class of probability models ? class of decisions
• class of utility functions ? class of decisions
• If you end up with a single decision, great.

• If the class of decisions is large and diverse,
  then any conclusion should be rather tentative.

43
Bayesian dogma of ideal precision

• Robust Bayes is inconsistent with the Bayesian
  idea that uncertainty should be measured by a
  single additive probability measure and values
  should always be measured by a precise utility
  function.
• Some Bayesians justify it as a convenience
• Others suggest it accounts for uncertainty beyond
  probability theory

44
Sensitivity analysis
45
Sensitivity analysis with p-boxes

• Local sensitivity via derivatives
• Explored macroscopically over the uncertainty in
  the input
• Describes the ensemble of tangent slopes to the
  function over the range of uncertainty

46
Monotone function
Nonlinear function
range of input
range of input
47
Sensitivity analysis of p-boxes

• Quantifies the reduction in uncertainty of a
  result when an input is pinched
• Pinching is hypothetically replacing it by a less
  uncertain characterization

48
Pinching to a point value
1
1
Cumulative probability
Cumulative probability
0
0
1
2
3
0
1
2
3
0
X
X
49
Pinching to a (precise) distribution
1
1
Cumulative probability
Cumulative probability
0
0
1
2
3
0
1
2
3
0
X
X
50
Pinching to a zero-variance interval
1
Cumulative probability
0
1
2
3
0
X

• Assumes value is constant, but unknown
• Theres no analog of this in Monte Carlo

51
Using sensitivity analyses

• There is only one take-home message
• Shortlisting variables for treatment is bad
• Reduces dimensionality, but erases uncertainty

52
Validation
53
How the data come
400
350
300
Temperature degrees Celsius
250
200
1000
900
800
700
600
Time seconds
54
How we look at them
55
One suggestion for a metric
1
Area or average horizontal distance between the
empirical distribution Sn and the predicted
distribution
Probability
0
200
250
300
350
450
400
Temperature
56
Pooling data comparisons

• When data are to be compared against a single
  distribution, theyre pooled into Sn
• When data are compared against different
  distributions, this isnt possible
• Conformance must be expressed on some universal
  scale

57
Universal scale
N(2, 0.6) normal(range0.454502,3.5455,
mean2, var0.36) max(0.0001,exponential(1.7))
(range0.0001,9.00714, mean1.699999,1.700
1, var2.43,2.89) mix(U(1,5),N(10,1)) 2.3
(range2.3,28.9244, mean14.95,
var70.9742)
1
1
1

Probability
0
0
0
1
10
100
1000
0
1
2
3
4
0
10
5

• uiFi (xi) where xi are the data and Fi are
  their respective predictions

58
Backtransforming to physical scale
1
G
u
Probability
Probability
0
0
5
1
3
2
4
59
Backtransforming to physical scale

• The distribution of G?1(Fi (xi)) represents the
  empirical data (like Sn does) but in a common,
  transformed scale
• Could pick any of many scales, and each leads to
  a different value for the metric
• The likely distribution of interest is the one
  used for the validation statement

60
Epistemic uncertainty in predictions
a N(5,11,1) show a b 8.1 show b in blue b
15 breadth(env(rightside(a),b))
4.023263478773 b 11 breadth(env(rightside(a),b
)) / 2 0.4087173895951
1
1
1
Probability
d 0
d ? 4
d ? 0.4
0
0
0
0
10
20
0
10
20
0
10
20

• In left, the datum evidences no discrepancy at
  all
• In middle, the discrepancy is relative to the
  edge
• In right, the discrepancy is even smaller

61
Epistemic uncertainty in both
z0.0001 zz 9.999 show z,zz a
N(6,7,1)-1 show a b -1mix(1,5,7,
1,6.5,8, 1,7.6,9.99, 1, 3.3,6, 1,4,8,
1,4.5,8, 1,5,7, 1,7.5,9, 1,4,8, 1,5,9,
1,6,9.99) show b in blue b -0.2mix(1,
9,9.6,1, 5.3,6.2, 1,5.6,6, 1,7.8,8.4,
1,5.9,7.8, 1,8.3,8.7, 1,5,7, 1,7.5,8,
1,7.6,9.99, 1, 3.3,6, 1,4,8, 1,4.5,8,
1,5,7, 1,8.5,9, 1,7,8, 1,7,9,
1,8,9.99) breadth(env(rightside(a),b))
2.137345705795 c -4 b -0.2mix(1,
9,9.6,1, 5.3,6.2c, 1,5.6,6c, 1,7.8,8.4,
1,5.9,7.8, 1,8.3,8.7, 1,5,7, 1,7.5,8,
1,7.6,9.99, 1, 3.3,6, 1,4,8, 1,4.5,8c,
1,5,7c, 1,8.5,9, 1,7,8, 1,7,9,
1,8,9.99) breadth(env(rightside(a),b)) / 2
1.329372857714
1
1
1
d 0
d ? 0.05
d ? 0.07
Probability
0
0
0
0
5
10
0
5
10
0
5
10
Predictions in white Observations in blue
62
Backcalculation
63
A typical problem

• How can we design an shielding system if we cant
  well specify the radiation distribution?
• Could plan for worst case analysis
• Often wasteful
• Cant account for rare even worse extremes
• Could pretend we know the distribution
• Unreasonable for new designs or environments

64
IP solution

• Natural compromise that can express both
• Gross uncertainty like intervals and worst cases
• Distributional information about tail risks
• Need to solve equations containing uncertain
  numbers
• Constraint propagation, or backcalculation

65
Cant just invert the equation

• Total ionizing dose Radiation / Shielding
• Shielding Radiation / Dose
• When Shielding is put back into the forward
  equation, the resulting dose is wider than planned

66
How come?
a 2,8 b 0,4 c a b bb c / a cc
a bb c 0, 32 cc 0, 128
128/32 4

• Suppose dose should be less than 32, and
  radiation ranges between 50 and 200
• If we solved for shielding by division, wed get
  a distribution ranging between ltltgtgt
• But if we put that answer back into the equation
• Dose Radiation / Shielding
• wed get a distribution with values as large as
  128, which is four times larger than planned

67
Backcalculation with p-boxes

• Suppose A B C, where
• A normal(5, 1)
• C 0 ? C, median ? 15, 90th ile ? 35, max ?
  50

68
Getting the answer

• The backcalculation algorithm basically reverses
  the forward convolution
• Not hard at allbut a little messy to show
• Any distribution totally inside B is
  sure to satisfy the constraint
  its a kernel

1
B
0
-10
0
10
20
30
40
50
69
Check it by plugging it back in

• A B C ? C

70
When you Know that A B C A B C A ?
B C A / B C A B C 2A C A² C
And you have estimates for A, B A, C B ,C A,
B A, C B ,C A, B A, C B ,C A, B A, C B ,C A, B A,
C B ,C A C A C
Use this formula to find the unknown C A B B
backcalc(A,C) A backcalc (B,C) C A B B
backcalc(A,C) A backcalc(B,C) C A B B
factor(A,C) A factor(B,C) C A / B B
1/factor(A,C) A factor(1/B,C) C A B B
factor(log A, log C) A exp(factor(B, log C)) C
2 A A C / 2 C A 2 A sqrt(C)
71
Hard with probability distributions

• Inverting the equation doesnt work
• Available analytical algorithms are unstable for
  almost all problems
• Except in a few special cases, Monte Carlo
  simulation cannot compute backcalculations trial
  and error methods are required

72
Precise distributions dont work

• Precise distributions cant express the target
• A specification for shielding giving a prescribed
  distribution of doses seems to say we want some
  doses to be high
• Any distribution to the left would be better
• A p-box on the dose target expresses this idea

73
Conclusions
74
New organization

• In the past, focus on where uncertainty arose
• Parameters
• Drivers
• Model structure
• Today, focus is on the nature of uncertainty
• Ignorance (epistemic uncertainty)
• Variability (aleatory uncertainty)
• Vagueness (semantic uncertainty, fuzziness)
• Confusion, mistakes

75
Untenable assumptions

• Uncertainties are small
• Sources of variation are independent
• Uncertainties cancel each other out
• Linearized models good enough
• Underlying physics is known and modeled
• Computations are inexpensive to make

76
Need ways to relax assumptions

• Possibly large uncertainties
• Non-independent, or unknown dependencies
• Uncertainties that may not cancel
• Arbitrary mathematical operations
• Model uncertainty

77
Good engineering
Dumb luck
Honorable failure
Negligence
78
Take-home messages

• It seems antiscientific (or at least silly) to
  say you know more than you do
• Bayesian decision making always yields one
  answer, even if this is not really tenable
• IP tells you when you need to be careful and
  reserve judgment

79
References
http//www.sciencemag.org/cgi/content/short/310/57
54/1680 http//www.sciencedirect.com/science?_ob
ArticleURL_udiB6T24-3VXBPWR-1_user10_handleV
-WA-A-W-V-MsSWYWW-UUA-U-AABDWWZUBV-AABVYUZYBV-CVUE
BVVZZ-V-U_fmtsummary_coverDate012F312F1996_
rdoc1_origbrowse_srch23toc234908231996239
99419998237027221_cdi4908viewc_acctC000050
221_version1_urlVersion0_userid10md5c6985d
af53c5402c195c1106cec9622f

• Cosmides, L., and J. Tooby. 1996. Are humans good
  intuitive statisticians after All? Rethinking
  some conclusions from the literature on judgment
  under uncertainty. Cognition 581-73.
• Hsu, M., M. Bhatt, R. Adolphs, D. Tranel, and
  C.F. Camerer. 2005. Neural systems responding to
  degrees of uncertainty in human decision-making.
  Science 3101680-1683.
• Kmietowicz, Z.W. and A.D. Pearman. 1981. Decision
  Theory and Incomplete Knowledge. Gower,
  Hampshire, England.
• Knight, F.H. 1921. Risk, Uncertainty and Profit.
  L.S.E., London.
• Troffaes, M. 2004. Decision making with imprecise
  probabilities a short review. The SIPTA
  Newsletter 2(1) 4-7.
• Walley, P. 1991. Statistical Reasoning with
  Imprecise Probabilities. Chapman and Hall,
  London.

80
Web-accessible reading

• http//maths.dur.ac.uk/dma31jm/durham-intro.pdf
• (Gert de Coomans gentle introduction to
  imprecise probabilities)
• http//www.cs.cmu.edu/qbayes/Tutorial/quasi-bayes
  ian.html
• (Fabios Cozmans introduction to imprecise
  probabilities)
• http//idsia.ch/zaffalon/events/school2004/school
  .htm
• (summer school on imprecise probabilities)
• http//www.sandia.gov/epistemic/Reports/SAND2002-4
  015.pdf
• (introduction to p-boxes and related structures)
• http//www.ramas.com/depend.zip
• (handling dependencies in uncertainty modeling)
• http//www.ramas.com/bayes.pdf
• (introduction to Bayesian and robust Bayesian
  methods in risk analysis)
• http//www.ramas.com/intstats.pdf

81
End
82
