Ch 17 notes

1
Ch 17 notes

• WAVES

2
What is a Wave?

• Waves-rhythmic disturbances that carry energy
  through matter or space
• Medium-material through which a wave can travel
  and transfer energy
• solid, liquid, gas, or combination

3
Three main types

• Transverse Wave-medium move at right angle to
  direction of wave
• Longitudinal Waves-matter vibrates in the same
  direction as the wave travels, parallel
• Surface Wave-travels along a surface separating
  two media, most common are ocean waves

4
Transverse Wave

• Wavelength Crest
• Amplitude
• _ _ _ _ _ _ _ _ _ _ _ _ _ _ _rest point
  (equilibrium) _ _
• Amplitude
• Trough

5
Transverse Wave

• Crest-highest point of the wave above the rest
  point
• Trough-lowest point below the rest point
• Wavelength-distance between a point on one wave
  and the same point on the next cycle of the wave
• Amplitude-max displacement of the medium from its
  rest point, corresponds to the amt of energy a
  wave carries (more energy greater amplitude)

6
Transverse Wave

• Frequency- of wavelengths that pass a fixed
  point each second, measured in Hertz (Hz)
  (Increasing Frequency wavelength decreases)
• Period-time it takes for one wavelength to pass a
  point (Increasing Frequency period decreases)

7
Longitudinal Waves

• Longitudinal Waves-matter vibrates in the same
  direction as the wave travels, parallel

8
Longitudinal Waves

• aka compressional waves
• compression-area where particles in a medium are
  spaced close together
• rarefaction-area where particles in a medium are
  spread out

9
Surface Wave

• Surface Wave-travels along a surface separating
  two media, most common are ocean waves

10
Wave speed

• Velocity wavelength x frequency
• V ? (lambda) x f
• m/s m x Hz

11
Wave Speed

• One end of a rope is vibrated to produce a wave
  with a wavelength of 0.25meters. The frequency of
  a wave is 3 hertz. What is the speed of the wave?

12
Wave Speed

• Wavelength 0.25m
• Frequency 3Hz
• Speed ?
• Speed Wavelength x Frequency
• Speed 0.25m x 3Hz
• Speed 0.75m/s

13
Behavior of waves

• Reflection
• wave bounces off a surface that it cannot pass
  through
• does not change speed or frequency, but wave can
  be flipped upside down

14
Reflection
15
Mount Moran, one of the Grand Tetons, Wyoming
16
Behavior of waves

• Refraction
• bending of a wave as it enters a new medium at an
  angle
• one side of the wave moves more slowly than the
  other side

17
Refraction
18
As an ocean wave approaches the shore at an
angle, the wave bends, or refracts, because one
side of each wave front slows down before the
other side does.
19
Behavior of waves

• Diffraction
• bending of wave as it moves around an obstacle or
  passes through a narrow opening
• diffracts more of its wavelength is large
  compared to the size of an opening or obstacle

20
Diffraction
Crepuscular rays, due to scattering
21
Behavior of waves

• Interference
• occurs when two or more waves overlap and combine
  together
• Two types
• constructive-the waves add together
• destructive-the waves subtract from each other as
  they overlap

22
Constructive
23
Destructive
24
Interference
25
Node versus Antinode
Areas where destructive interference continually
occurs are called nodes. Areas where constructive
interference continually occurs are called
antinodes
26

• Standing wave
• a wave that appears to stay in one placer it
  does not seem to move through the medium.
• It forms only if half a wavelength or a multiple
  of half a wavelength fits exactly into the length
  of a vibrating cord.

27
Sound

• Speed of sound depends on
• type of medium-solid best conductor
• no sound on moon or in space (no medium)
• temperature of medium-faster at higher temps

28
Sound

• Intensity rate at which a waves energy flows
  through a given area
• Loudness human perception, measured in decibels
  (dB)

29
Sound

• Pitch highness or lowness of a sound
• high frequency high pitch
• low frequency low pitch
• human hear between 20 20,000 Hz
• Ultrasonic is above 20,000 Hz
• Infrasonic (subsonic) is below (thunder)

30
Sound

• Resonance if the sound that reaches an object
  is at the same frequency of the object, the
  object will begin to vibrate at that frequency
• Noise pollution includes sounds that are loud,
  annoying or harmful to the ear

31
Why do concert places usually have carpet on
walls and floors?
32
Doppler effect

• A change in sound frequency caused by motion of
  the sound source, motion of the listener, or both
• Higher pitch, higher frequency as object
  approaches
• Lower pitch, lower frequency as sound source
  moves away

33
(No Transcript)
34
(No Transcript)
