Oceanic Crust and Rocks Appendices

1
Oceanic Crust and Rocks(Appendices)

• JFM505E Physics and Structure of the Earths
  Crust

2
Comparision of Characteristics of Typical
Refraction and Reflection Techniques
Comparision of Characteristics of Typical
Refraction and Reflection Techniques for Deep
Crustal Structure Studies (Braile and Chiang,
1986)
3
Summary of Advantages and Limitations of
Refraction and Reflection Techniques for Deep
Crustal Structure Studies (Braile and Chiang,
1986)
4
SEISMIC RESOLUTION

• Vertical Resolution
• Horizontal Resolution
• Vertical Resolution
• For 2 reflections (one from the top and one from
  the bottom of a thin layer),
• there is a limit on how close they can be, yet
  still be separable (Yilmaz,
• 1989).
• The dominant wavelength of seismic waves is given
  by
• ?v / f,
• where v is velocity and f is the dominant
  frequency.
• The acceptable threshold for vertical resolution
  generally is a quarter of
• the dominant wavelength.

5

• (Yilmaz, 1989)

6
(Yilmaz, 1989)
7
Lateral Resolution

• Lateral resolution refers to how close two
  reflecting points can be
• situated horizontally, yet be recognized as two
  separate points rather
• than one (Yilmaz, 1989).

8

• The total energy arriving within the time
  interval (t1-t0), which equals half the dominant
  period (T/2), interferes constructively.
• AA is called a half-wavelength Fresnel zone
  (Hilterman, 1982) or the first Fresnel zone
  (Sheriff, 1984). Two reflecting points that fall
  within this zone generally are considered
  indistinguishable as observed from the Earths
  surface.
• The Fresnel zone width is a measure of lateral
  resolution.
• The Fresnel zone radius (rOA)
• r?(z? / 2)1/2(v / 2) (t / f)1/2
• t(2z / v)

9
(Yilmaz, 1989)
10
Layers of Oceanic Crust
http//www.womenoceanographers.org/Default.aspx?pi
d28EF75D5-D130-46c0-947E-5CCBC627B0EEidKathrynG
illis
11

• Layer 1 Vp 1.6-2.5 km/s, Thickness 0.4 km,
  Rocks Sediment
• Layer 2 Vp 3.4-6.2 km/s, Thickness 1.4 km
• Layer 2A Vp 3.5 km/s, Rocks Fractured
  Basalt
• Layer 2B Vp 5.2 km/s, Rocks Massive Basalt
  with Dykes
• Layer 2C Vp 6.1 km/s, Rocks Dykes with
  Massive Basalt
• Layer 3 Vp 6.4-7.0 km/s, Thickness 5 km
• Layer 3A Vp 6.8 km/s, Rocks Metagabbros and
  gabbros with pockets of plagiogranite and
  protrusions of serpentine
• Layer 3B Vp 7.3 km/s, Rocks Gabbros and
  metagabbros with serpentinite protrusions and
  pockets of cumulate ultramafic
• Moho
• Upper Mantle Vp 7.4-8.6 km/s
• Rocks Serpentinized ultramafics lt 6.9 km/s
• Anomalous mantle (close to ridge axis) 7.8
  km/s
• Harzburgite and lherzolite 8.1 km/s
• (Kearey and Vine, 1992, p20)

12
(Ehlers and Blatt, 1982)
13
(Hamblin and Christiansen, 1998)
14
(Hamblin and Christiansen, 1998)
15
Ophiolites

• Description
• The term ophiolite refers to a distinctive rock
  assemblage containing ultramafic, gabbroic and
  basaltic rocks, often capped by layers of deep
  sea sediments.
• Locations
• Well described ophiolite suites are located Bay
  of Islands in Newfound land, Troodos in Cyprus,
  Semail in Oman and eastern Papua in New Guinea.
• Process (Obduction)
• Initial stage of collision, the oceanic plate is
  thrust over the continental plate.

16
Possible mechanisms for obduction of ophiolite
sheets onto continental margin (Ehlers and Blatt,
1982)
17
Ophiolitic rocks in Turkey (Piril, 2003)

• Within the Tethyan belt, Turkey is well known for
  extensive areas of
• ophiolitic rocks in the mountains of the Alpine
  chain.
• In NW Turkey, a complete ophiolite sequence has
  not been found.
• Izmir-Ankara-Erzincan suture zone (ophiolitic
  zone ) formed during Early
• Tertiary continental collision following
  northward subduction of Tethyan
• oceanic lithosphere
• The Izmir-Ankara-Erzincan suture zone separates
  the Pontides from the
• Anatolides-Taurides.
• It is the boundary between Gondwana and Laurasia,
  and two separate
• Oceanic lithospheres, Palaeo-Tethys and
  Neo-Tethys, have been
• consumed along the suture
• In contrast, the Tauride ophiolites in the south
  are larger and more
• complete, of mid- to late Cretaceous age.

18
Tectonic map of the Eastern Mediterranean
(Robertson, 2000)
19
Plate tectonic sketches showing the simlified
evolution of southern Turkey a) Late Triassic, b)
Late Cretaceous, c) Late Eocene (Robertson, 2002)
20
Ophiolitic rocks in the Island of Cyprus

• The Troodos ophiloite in the Island of Cyprus
  formed at a spreading center
• above a subduction zone.

http//www.womenoceanographers.org/Default.aspx?pi
d28EF75D5-D130-46c0-947E-5CCBC627B0EEidKathrynG
illis
21
Map of the Troodos Ophiolite (Staudigel et al.,
1999)
22

• The Troodos ophiolite belongs to the
  mid-Cretaceous,
• and formed 91 my ago.
• A belt of ophiolites of this age stretches far to
  the east,
• ending with the well known Samail ophiolite in
  Oman.
• Uplift of Troodos to its present position took
  place
• episodically, but was initiated 20 My ago.

23
Ophiolites in the Island of Cyprus. The vertical
slabs of rock are dikes intruding into lavas that
erupted on the seafloor. The transition from
lavas to sheeted dikes (Layer 2B)
http//www.womenoceanographers.org/Default.aspx?pi
d28EF75D5-D130-46c0-947E-5CCBC627B0EEidKathrynG
illis
24
Ophiolitic Rocks in Oman

• http//www.angelfire.com/ms/snasir/page14.html

25

• Ophiolites are very common in the Middle East.
  They occur in elongate belts that make up an
  integral part of the Alpine mountain chains.
• These ophiolites extend eastward and southward
  from Cyprus into Syira, the Turkey-Iran boerder
  fold belt, through Neyriz in Iran , then across
  the Arabian Gulf into Oman. The Semail ophiolite
  , Sultanate of Oman, is part of these ophiolits.
• It provides the best exposure in the world to
  study oceanic lithosphere.
• The Semail ophiolite crops out in a belt 600 km
  long and 150 km wide and between 5 and 10 km
  thick.
• The Sultanate of Oman forms the southeastern
  corner of the Arabian Plate (http//www.angelfire.
  com/ms/snasir/page14.html ).

26
(Hamblin and Christiansen, 1998)
27
(Hamblin and Christiansen, 1998)
28
(Hamblin and Christiansen, 1998)
29
(Hamblin and Christiansen, 1998)
30
(Hamblin and Christiansen, 1998)
31
(Hamblin and Christiansen, 1998)
32
(Hamblin and Christiansen, 1998)
