Title: Radioactive Decay II


1
Radioactive Decay II
  • Removal of Daughter Products
  • Radioactivation
  • Exposure-Rate Constant

2
Removal of Daughter Products
  • In some cases, especially for diagnostic or
    therapeutic applications of short-lived
    radioisotopes, it is useful to remove the
    daughter product from its relatively long-lived
    parent, which continues producing more daughter
    atoms for later removal and use
  • The greatest yield per milking will of course be
    gotten at time tm since the previous milking,
    assuming complete removal of the daughter product
    each time

3
Removal of Daughter Products (cont.)
  • Waiting longer than tm is counterproductive, as
    the activity of the daughter present then begins
    to decline along with the parent
  • Frequent (or continuous) milking would give a
    greater total yield of the daughter product,
    however

4
Removal of Daughter Products (cont.)
  • Assuming that the initial parent activity is
    ?1(N1)0 and the initial Ath-daughter activity is
    zero at time t 0, the daughters activity at
    any later time t is obtained from

5
Removal of Daughter Products (cont.)
  • This equation tells us how much Ath-daughter
    activity exists at time t as a result of the
    parent-source disintegrations, regardless of
    whether or how often the daughter has been
    separated from its source
  • Thus the amount of daughter activity available to
    be removed from the source at time t is that
    given by this equation minus the daughter
    activity previously removed and still existing
    elsewhere at the same time t

6
Removal of Daughter Products (cont.)
  • Alternatively, if we let ?1(N1)0 represent the
    initial activity of the parent source at time t
    0, and if the Ath daughter is completely removed
    at a later time t1 (not necessarily the first
    milking), then the additional Ath daughter
    activity that can be removed at a subsequent time
    t2 is given by

7
Removal of Daughter Products (cont.)
  • If only a single daughter is produced (?1A ?1)
    and if we assume t1 0 and t2 t, then

8
Radioactivation by Nuclear Interactions
  • Stable nuclei may be transformed into radioactive
    species by bombardment with suitable particles,
    or photons of sufficiently high energy
  • Thermal neutrons are particularly effective for
    this purpose, as they are electrically neutral,
    hence not repelled from the nucleus by Coulomb
    forces, and are readily captured by many kinds of
    nuclei
  • Tables of isotopes list typical reactions which
    give rise to specific radionuclides

9
Radioactivation by Nuclear Interactions (cont.)
  • Let Nt be the number of target atoms present in
    the sample to be activated
  • where NA Avogadros constant (atoms/mole)
  • A gram-atomic weight (g/mole),
    and
  • m mass (g) of target atoms only
    in the
  • sample

10
Radioactivation by Nuclear Interactions (cont.)
  • If ? is the particle flux density (s-1 cm-2) at
    the sample, assuming that the sample
    self-shielding is negligible, and ? is the
    interaction cross section (cm2/atom) for the
    activation process in question, then the initial
    rate of production (s-1) of activated atoms is
  • assuming as usual that we are dealing with
    expectation values

11
Radioactivation by Nuclear Interactions (cont.)
  • Correspondingly the initial rate of production of
    activity of the radioactive source being thus
    created is given by
  • where ? is the total radioactive decay
    constant of the new species

12
Radioactivation by Nuclear Interactions (cont.)
  • If we may assume that ? is constant and that Nt
    is not appreciably depleted as a result of the
    activation process, then the rates of production
    given by these equations are also constant
  • As the population of active atoms increases, they
    decay at the rate ?Nact (s-1)
  • Thus the net rate at which they accumulate can be
    expressed as

13
Radioactivation by Nuclear Interactions (cont.)
  • After an irradiation time t gtgt ?, the rate of
    decay equals the rate of production, and the net
    rate of population increase becomes zero thus
    the equilibrium activity level is given directly
    by
  • where the subscript e stands for equilibrium

14
Radioactivation by Nuclear Interactions (cont.)
  • At any time t after the start of irradiation,
    assuming the initial activity to be zero (?Nact
    0 at t 0), the activity in becquerels can be
    shown to be related to its equilibrium activity
    by
  • Or, assuming that no decay occurs during the
    irradiation period t (which will be approximately
    correct if t ltlt ?), the activity at time t may be
    approximated by

15
Growth of a radionuclide of decay constant ? due
to a constant rate of nuclear interaction
16
Radioactivation by Nuclear Interactions (cont.)
  • Sometimes it is necessary to calculate the
    equilibrium activity level on the basis of the
    initial rate of growth of activity, without
    knowing the flux density or cross section for the
    interaction
  • An example would be the prediction of the maximum
    activity level of a particular radionuclide that
    would be reached ultimately in a neutron shield,
    knowing only the activity resulting from a short
    initial irradiation period

17
Radioactivation by Nuclear Interactions (cont.)
  • Combining the equations for initial rate of
    production of activity and for the equilibrium
    activity level, we have

18
Radioactivation by Nuclear Interactions (cont.)
  • Therefore the equilibrium activity level is equal
    to the initial production rate of activity
    multiplied by the mean life ?
  • This method of course required that the mean life
    (or the decay constant) be known for the
    radioactive product of interest

19
Exposure-Rate Constant
  • The exposure-rate constant ?? of a radioactive
    nuclide emitting photons is the quotient of
    l2(dX/dt)? by A, where (dX/dt)? is the exposure
    rate due to photons of energy greater than ?, at
    a distance l from a point source of this nuclide
    having an activity A
  • It is usually stated in units of R m2 Ci-1 h-1 or
    R cm2 mCi-1 h-1

20
Exposure-Rate Constant (cont.)
  • This quantity was defined by the ICRU to replace
    the earlier specific gamma-ray constant ?, which
    only accounts for the exposure rate due to
    ?-rays, whereas ?? also included the exposure
    rate contributions (if any) of characteristic
    x-rays and internal bremsstrahlung, and
    establishes the arbitrary lower energy limit ?
    (keV) below which all photons are ignored

21
(No Transcript)
22
Exposure-Rate Constant (cont.)
  • It will be seen that ?? is greater than ? by by
    2 or less, except for Ra-226 (12) and I-125 (in
    which case ? is only about 3 of ?? because
    K-fluorescence x-rays following electron capture
    constitute most of the photons emitted)
  • In extreme cases like this, where ? would be
    useless if defined literally (i.e., for ?-rays
    only), x-rays have been sometimes included in ?
    even though the definition did not call for it

23
Exposure-Rate Constant (cont.)
  • In the following we will show how the specific
    ?-ray constant ? can be calculated for a given
    point source
  • The exposure-rate constant ?? may be calculated
    in the same way by taking account of the
    additional x-ray photons (if any) emitted per
    disintegration

24
Exposure-Rate Constant (cont.)
  • At a location l meters (in vacuo) from a ?-ray
    point source having an activity A Ci, the flux
    density of photons of the single energy Ei is
    given by
  • where ki is the number of photons of energy
    Ei emitted per disintegration

25
Exposure-Rate Constant (cont.)
  • This can be converted to energy flux density as
    follows
  • in which Ei is to be expressed in MeV/photon
  • It will be more convenient to express ?Ei in
    units of J/s m2, while still expressing Ei in
    MeV, in which case the above equation becomes

26
Exposure-Rate Constant (cont.)
  • We can relate this energy flux density to the
    exposure rate by recalling

27
Exposure-Rate Constant (cont.)
  • For photons of energy Ei the exposure rate is
    given by
  • and the total exposure rate for all of the
    ?-ray energies Ei present is

28
Exposure-Rate Constant (cont.)
  • Substituting the expression for the energy flux
    density, we obtain
  • This can be converted into R/h, remembering that
    1 R 2.58 ? 10-4 C/kg and 3600 s 1 h

29
Exposure-Rate Constant (cont.)
  • The specific ?-ray constant for this source is
    defined as the exposure rate from all ?-rays per
    curie of activity, normalized to a distance of 1
    m by means of an inverse-square-law correction
  • where Ei is expressed in MeV and ?en/? in
    m2/kg

30
Exposure-Rate Constant (cont.)
  • If (?en/?)Ei,air is given instead in units of
    cm2/g, the constant in this equation is reduced
    to 19.38
  • ? may be obtained in units of R cm2/mCi h
    directly with this equation if (?en/?)Ei,air is
    expressed in cm2/g in place of m2/kg

31
Exposure-Rate Constant (cont.)
  • For the special case of Ra-226 in equilibrium
    with its progeny, ? is usually expressed in R
    cm2/mg h, the activity of the Ra-226 being
    expressed in terms of its mass
  • Also, the accepted value of 8.25 R cm2/mg h
    refers not to a bare point source, but rather
    to one in which the ?-rays are filtered through
    0.5 mm of Pt(10 Ir) in escaping

32
Exposure-Rate Constant (cont.)
  • Applying this to an example, 60Co, we note first
    that each disintegration is accompanied by the
    emission of two photons, one at 1.17 MeV and the
    other at 1.33 MeV
  • Thus the value of ki is unity at both energies
  • The mass energy absorption coefficient values for
    air at these energies are

33
Exposure-Rate Constant (cont.)
  • Hence the equation for ? becomes
  • which is close to the value given in the
    table, considering the difference in units

34
Exposure-Rate Constant (cont.)
  • The exposure rate (R/hr) at a distance l meters
    from a point source of A curies is given by
  • where ? is given for the source in R m2/Ci h,
    and attenuation and scattering by the surrounding
    medium are assumed to be negligible

35
Exposure-Rate Constant (cont.)
  • A quantity called the air kerma rate constant
    that is related to the exposure rate constant was
    also defined by the ICRU
  • The defining equation is
  • The units recommended are m2 J kg-1 or m2 Gy Bq-1
    s-1
  • Unfortunately the ICRU chose the same symbol, ??,
    for this constant, which may cause confusion
