POWER Engineers Tom McAuliffe Geothermal Steam
Flow Measurement
2
Fundamentals

• References
• ASME MFC-3M 1989
• Miller Flow Measurement Engineering Handbook
• Bernouillis Equation

3
Venturis
Note300 Flange Rating for Stainless

• Highly Accurate
• Low Energy Loss
• Oil filled diaphragm seals
• Multivariable flow transmitter

4
Fundamentals Redux

• Amagats Law (S of the Volumes)

• Daltons Law (S of the Pressures)

5
Density of the mixture
Miller eqn 2.9 2.100
rH2O is calculated at the water vapors partial
pressure
6
Steam Properties, rf (XpH2O or pH2OTSH)
If you cant dazzle them with brilliance
Saturated Steam Conditions
Superheated Steam conditions
pH2O is the water vapors partial pressure
7
NCG Compressibility Factors
Hint use MS Excels Goal Seek function to solve
8
Z Compressibility Factors
9
e, The Gas Expansion Factor a minor fly in the
ointment

• Problem density change through meter

k is the isentropic exponent t is the ratio of
throat to upstream pressure
10
Expansion Factor e versus k

• Solution Cheat. Use the k for steam alone
• e is not sensitive to variations
  in k

11
Only 0.45 change in e over a wide range of k
values
12
The flow equation
As elegant as it gets
SI Units
