The use of EPR in Nitric Oxide Research

1
The use of EPR in Nitric Oxide Research

• Neil Hogg,
• Medical College of Wisconsin
• SFRBM 2005
• Austin, TX

2
A STABLE free radical gas
N
O
3
Direct Detection of NO by EPR

• Broad ugly looking spectrum
• Need high concentration
• Unsuitable for biological detection

?
Spin Trapping
4
Strategies used for the EPR detection of Nitric
Oxide
Fe/ Dithiocarbamate
Nitronyl Nitroxides
Hemoglobin/ Myoglobin
DNIC
5
The Nitronyl Nitroxides
CPTIO
6
Brief History

• First reported by Osieki and Ullman (1968) JACS,
  90, 1078
• Proposed use as NO dosimeter by Nadeau and
  Boocock (1977) Anal. Chem. 49, 1672
• Role as Biological NO spin trap. Joseph et al
  (1993), BBRC, 192, 926
• Antagonism of EDRF. Akaike et al (1993)
  Biochemistry. 32, 827

7
Mechanism
INO
NNO
Joseph et al (1993), BBRC, 192, 926
8
NO detection
NO
Joseph et al (1993), BBRC, 192, 926
9
Origin of EPR spectrum (NNO with two equivalent N
centers)
1 2 3
2 1
10
Origin of EPR spectrum (INO with two inequivalent
N centers)
1 1 2 1 2
1 1
11
Spectral Overlap of NNO and INO
12
Overlap Minimized on low-field lines (Left side
of spectrum)
Hogg et al (1995), Free Rad. Res., 22, 47
13
Better way Multiple Linear regression uses all
the data
MLR
(Simulation using WinSim)
14
Reaction characteristics

• Reaction of NO converts one radical to another
  therefore not spin-trapping in the traditional
  sense.
• Rate const of 1000 M-1s-1 therefore fast enough
  to compete with oxygen but not fast enough to
  compete with (e.g.) superoxide.
• Cannot use the DMPO trick of using huge amounts
  of trap to offset a small rate constant due to
  the fact that the trap itself has an EPR spectrum

15
Problem with too much trap..
If we used 10 mM CPTIO, then CPTIO spectrum would
be 40 times bigger but CPTI would be the same
size!
16
Reaction stoichiometry?
2 NOs consumed per CPTIO
Hogg et al (1995), Free Rad. Res., 22, 47
17
NO/CPTIO generates nitrosating intermediates.
Zhang et al (2004), Am.J.Physiol., 287, L467
18
CPTIO/CPTI are redox active nitroxides makes
for many problems in complex systems
SIN-1 and CPTIO
? CPTIO ? CPTI TEMPOL (control)
Singh et al (1999), Arch. Biochem. Biophys..,
361, 331
19
Advantages/Disadvantages

• Clear NO-dependent change in EPR spectrum allows
  quantification of kinetics of NO formation.
• Works best in simple chemical systems as both
  reactant and product nitroxides are easily
  reduced by cellular reductants.
• The nitroxides are good oxidants and so care must
  be taken to examine if the redox properties of
  the nitroxides are altering the chemistry of the
  system
• Nitrogen dioxide is a product of the reaction and
  so these compounds my inhibit NO but enhance
  nitrosation/nitration reactions.

20
Dinitrosyl Iron Complexes (DNIC)

• NO Staph Aureus
• g2.04 signal indicates presence of DNIC
• Endogenous signal from NO in all cell types
• Likely derives from NO interaction with Iron
  Sulfur clusters

Stadler et al (1993), Arch.Biochem.Biophys., 302,
4
21
Dithiocarbamates
NO
Heat killed yeast loaded with Dethyldithiocarbama
te/Fe
Mordvintcev, P et al (1991), Anal.Biochem., 199,
142
22
Hydrophilic Alternative

• MGD (N-methyl-D-glucamine dithiocarbamate not
  Miller Genuine Draft)

N-Methyl-D-glucamine
Tsuchiya et al (2002), Biochem. J., 367, 771
23
In vivo NO spin trapping
Time Course of S-band EPR signal from MGDFe2 NO
in the tail of a rat
Komarev et al (1993), BRRC, 195, 1191
24
EPR imaging of NO using MGD

Spatial mapping of nitric oxide generation in
the ischemic heart using electron paramagnetic
resonance imaging.Kuppusamy P, Wang P,
Samouilov A, Zweier JL.
25
Problems.?
Tsuchiya et al (2002), Biochem. J., 367, 771
26
Iron/DithiocarbamatesAdvantages/Disadvantages

• Actually traps the NO therefore 15N experiments
  can be used to identify the source of the signal.
• Use in in vivo NO spin trapping and EPR imaging.
• Potential for signal from sources other than NO
  (S-nitrosothiols/nitrite/HNO)
• Dithiocarbamates are good metal chelators and may
  inhibit metal ion-dependent enzymes (SOD, NOS
  etc).
• A Cu/dithiocarbamate signal overlaps the Fe/NO
  signal and can cause problems in situations where
  copper is present.

27
Hemoglobin/Myoglobin

• Reacts with NO with rate constant gt 107 M-1s-1
• Cheap and plentiful.
• The reaction is accompanied by a UV-vis spectral
  change and a change in EPR spectrum

28
Reactions of NO with Hb
29
Reaction of NO with MbO2

• Major spectral changes going from oxyMb to metMb.
• Watch out for mixing artifacts when using pure NO
  solutions!

Zhang and Hogg (2002), FRBM., 32, 1212
30
EPR of metHb
g6
g2
31
EPR metHb at 4 K (He)
32
Determination of metHb concentration using
correlation

• IF the shape of the line does not change then
  dont double integrate.
• Plot spectrum against that of a standard and the
  slope will immediately give you the concentration.

33
metHb standardization
Sensitivity of 100 nM
34
metHb during NO inhalation
35
Advantage/Disadvantages of metHb detection

• Simply easily analyzable signal.
• Highly sensitive at liquid He temperatures
• Not necessarily specific for NO (peroxynitrite
  and other oxidants could do the same thing)
• NO is not trapped and so cannot do 15N
  experiments.

36
Reactions of NO with Hb
37
EPR deoxyHb with NEM at 77 K
38
EPR deoxyHb with IP6 at 77K
39
Analysys of HbNO spectra
Piknova et al (2005), JBC.(in Press)
40
HbNO in blood after NO inhalation
Piknova et al (2005), JBC.(in Press)
41
Piknova et al (2005), JBC.(in Press)
42
Advantage/Disadvantages of HbNO detection

• Complex multi-component signal.
• Sensitive at liquid N2 temperatures
• NO is trapped and so can do 15N experiments.
• Needs to be deoxygenated!!

43
In conclusion

• EPR is a phenomenally useful tool in NO research
  for both in vitro, ex vivo and in vivo studies
• EPR direct detection of NO is possible after its
  stabilization by association with metal centers.
• EPR can also be detected by reactions that form
  or destroy paramagnetic species.
• Homework Design a non-metallic, non-redox active
  NO spin-trap. Send compounds to Neil Hogg,
  Department of Biophysics, Medical College of
  Wisconsin, Milwaukee, WI.

44
Acknowledgements
Barbora Piknova Yanhong Zhang Agnes
Keszler Netanya Spencer Ravinder Singh Raman
Kalyanaraman Bill Antholine Brian Bennett Jim
Hyde Mark Gladwin Alan Schechter Chris
Reiter Dany Kim-Shapiro Ron Mason ..many others
whos work I have used
National Biomedical EPR Center Medical College of
Wisconsin (EB001980)
