The STAR Experiment at Brookhaven National Laboratory

1
The STAR Experiment at Brookhaven National
Laboratory

• Michael Cherney
• Creighton University

2
Traditional High Energy Physics Probing the Small

• High Energy gives Small Wavelength? h / p
• Small Wavelength needed to Resolve the Small?min
  1.22 ? / d

3
The Standard Model
12 Force Carriers
12 Basic Particles
4
Hadrons -Particles Containing Quarks

• Mesons
• quark-antiquark pairs
• most of the hadrons coming out of a collision
• Baryons
• 3 quarks
• the hadrons going into the collision (protons
  and neutrons)

5
RHIC Physics Probing Particle Thermodynamics

• Phases of Atomic Matter
• solid
• liquid
• gas
• plasma of constituants

• Phases of Nuclear Matter
• liquid drop model
• hadron gas
• quark-gluon plasma

Spherical Nucleus
Spherical Water Drops
6
The Big Bang and Particle Evolution
7
Expansion and Cooling
8
Recreating the Process
9
Pressure and Heat from Collisions
10
Progression of a Collision
11
Fireball from a Gold-Gold Collision
12
The Little Bang and Particle Evolution
13
Brookhaven National Laboratory
14
The Brookhaven Accelerators
STAR
15
Tandem Van de Graaff
Ion Source and Initial Acceleration
16
Booster
17
AGS
18
Transfer line
19
RHIC tunnel
Superconducting Magnets
20
Radio Frequency Sources
21
The STAR Detector
22
The STAR Facility
The detector can be rolled in and out of the
interaction region.
23
STAR in the Assembly Building
24
The Interaction Region
Waiting for STAR to be rolled in
25
Cabling
26
Detector in Place
27
Side View of STAR
28
The Time Projection Chamber
L 4 m
d 4 m
29
Drift Field
Cylindrical Field Cages and Central Membrane
provide uniform drift field.
30
TPC Endcap
Copper Pads
31
Ionization in the TPC
Very large electric field near the wire results
in ionization. Smaller field in drift region
32
Constructed in Berkeley
33
Moved to Brookhaven
34
The STAR Magnet
Pole Tip
Barrel
0.5 Tesla Magnet
35
Magnetic Field Allows Charge and Momentum
Determination

• F qv x B
• ma qv x B
• m v2/r qvB?
• mv qB?r

36
Magnet Fabrication
37
Beam Pipe
38
Silicon Vertex Detector
39
On the platform
40
Data Acquistion
41
Trigger
Millions of Collisions per Second Only a Few
Recorded for Analysis
42
Access
43
Monitoring the Experiment
44
Reconstructing the Collision
45
Event Monitoring
46
Acknowledgments

• STAR Operations Group
• RHIC Operations Group
• Thomas McShane, SJ
