Modern Imaging in Breast Cancer

1
Modern Imaging in Breast Cancer

• Dr Linda Hacking
• Consultant Radiologist

2
October is Breast Cancer Awareness Month

• Breast cancer is commonest cancer in UK
  (excluding non-melanoma skin cancer)
• 46,000 new cases per year
• 300 men, remainder women
• 80 over 50 years of age
• 1 in 9 women will get it in their lifetime

3
Bad news/Good news

• Incidence has increased by 50 in last 25years
• 12,000 women and 70 men died from breast cancer
  in 2008
• 1,300 deaths in women under 50
• More than half deaths are in women over 70

4
Bad news/Good news

• Since 1980s breast cancer death rates have fallen
  by one third
• Breast cancer is no longer the commonest cause of
  cancer death in women
• More than 8 out of 10 women survive beyond 5
  years (5 out of 10 in 1970s)
• Now twice as likely to survive 10 years as 40
  years ago.
• 2 out of 3 women survive beyond 20 years
• Breast cancer death rates falling faster in UK
  than rest of Europe

5
Reasons for improvements in outcomes

• Screening
• Improved treatments (Tamoxifen etc)
• Improved cancer services including imaging

6
(No Transcript)
7
Why are these improvements happening

• Breast screening?? (also increased diagnosis
  rate)
• Improved treatments (tamoxifen etc.)
• Overall improvements in care (including imaging)

8
Breast Screening

• NHS Breast Screening Programme (NHSBSP)
• Began 1988-90
• Not Blackpool Victoria.
• Nearest centre Lancaster (vans, WGD)
• Invited for Mammograms from age 50-69
• Extended from 47-73 years from 2012 (target)
• Past upper age limit, option to arrange mammogram.

9
Breast Screening

• Will cause increase in incidence of cancer
• Early cancers and pre-cancer (DCIS) are found
  that would never have led to a problem

10
For Breast Screening

• One woman will be over-treated for every two
  lives saved
• 1000 lives a year saved
• Impact on population vs individual womans life.

11
Against breast screening

• 10 of cancers are over-diagnosis and therefore
  over treatment
• It is impossible to estimate lives saved because
  of all other factors
• Impact on population vs impact on individual
  womans life

12
Today we are talking about diagnosis
13
The Symptomatic Breast Clinic

• Lump or thickening
• Change in size or shape
• Redness or rash in skin or nipple
• Indrawing of nipple
• Skin puckering or dimpling
• Lump in armpit

14
Referral to Breast Clinic

• May simply need to see senior clinician- no
  further advice, no further investigations.
• Triple assessment/Double assessment
• See Senior Clinician (1)
• Imaging (2)
• Biopsy or needle test (FNA) (3)

15
Modern Imaging and Biopsy

• Tests to be done at first clinic appointment for
  most patients
• Most patients will have a benign diagnosis
• Less than 1 in 10 patients attending our clinic
  will have a malignant diagnosis
• 9 out of 10 will be benign
• In new clinic, results for patients seen Monday,
  Tuesday available for Friday
• Wednesday, within a week

16
Modern Imaging and Biopsy

• Quick accurate diagnosis for the majority of
  patients who will have a benign diagnosis
• As much information as possible about what we are
  dealing with in the minority if patients who have
  a malignant diagnosis
• Treatment can then be tailored to the individual
  patient

17
Mammography

• Symptomatic patients
• Women gt35 years of age
• Uses x-radiation
• Invented in 1960s, modern type of machine 1969
• Still not in universal use 1986 (when I started
  in radiology)
• First unit Blackpool 1990 (Fylde Coast incl.NHS)
• Blackpool Victoria Mammography unit 1999.
• October 2010 Full Field Digital mammography

18
(No Transcript)
19
(No Transcript)
20
(No Transcript)
21
(No Transcript)
22
(No Transcript)
23
(No Transcript)
24
(No Transcript)
25
(No Transcript)
26
Mammography

• Problems
• X-radiation
• Dense breasts
• Young women
• Men
• Implants
• No imaging 100 accurate

27
Field Digital Mammography

• Better on all counts
• Dense breast
• Younger women
• Less radiation

28
(No Transcript)
29
(No Transcript)
30
(No Transcript)
31
(No Transcript)
32
(No Transcript)
33
Ultrasound

• First imaging lt35, and men
• To clarify lumps and cysts on mammogram
• To do image guided biopsy
• To look at axilla (armpit)

34
Ultrasound
35
Cyst
36
Fibroadenoma
37
Ultrasound guided biopsy
38
Ultrasound guided biopsy

• Needle guided into abnormality under direct
  vision
• Can be needle test (FNA)
• Or Core biopsy
• Uses local anaesthetic
• Takes 5-10 minutes
• a bit like getting ears pierced
• Complications- bruising, pain

39
Ultrasound guided biopsy

• Quick very accurate results
• A patient specific individual plan if surgery
  required
• Tumour grade if malignant
• Hormone receptor status (Tamoxifen, herceptin)
• Size and extent of mass(es)
• Lymphnodes
• Test done Tuesday, results Friday

40
Core Biopsy Needle
41
Ultrasound guided biopsy
42
Mammographic stereotactic biopsy

• Mass seen on mammogram, not on ultrasound
• Micro-calcification chalky bits- can be benign,
  can be malignant or pre-malignant (DCIS)
• No lump felt
• Standard core biopsy
• Vacuum assisted core biopsy
• Special devices

43
Mammographic stereotactic biopsy

• Previously may have needed general anaesthetic
  surgery to remove abnormality
• Now outpatient procedure under local anaesthetic
• Most turn out to be benign

44
Vacuum assisted biopsy
45
(No Transcript)
46
Vacora vs 14G biopsy
47
Sample can be x-rayed
48
(No Transcript)
49
(No Transcript)
50
(No Transcript)
51
Breast MR (magnetic resonance)
52
Breast MR

• Also major investment in breast coils and
  software for new MR scanner
• Increased comfort
• Ease of interpretation (software)

53
(No Transcript)
54
Breast MR

• Recently in press
• In UK not used in every case
• Lobular carcinoma
• Multifocal carcinoma
• Problem solving when imaging/clinical/pathology
  do not match
• Doubts about mastectomy/ local excision
• Question of recurrence
• Implants

55
(No Transcript)
56
(No Transcript)
57
(No Transcript)
58
(No Transcript)
59
(No Transcript)
60
(No Transcript)
61
Breast MRI

• Adds to planning of surgery

62
So far

• We have been talking about diagnosis
• Imaging also helps during surgery

63
Localisation of mass not felt

• Marker with ultrasound
• Wire with stereotactic mammography
• Mass can be x-rayed while patient still
  anaesthetised

64
Excised specimen
65
Also during surgery-Sentinel Lymph Node Biopsy
(SLNB)
66
SNLB

• Small amount radioactivity injected into breast
• On morning before afternoon surgery
• Or afternoon before morning surgery
• Also blue dye in theatre
• Goes to first lymph node
• Surgeon uses probe in theatre
• No drain, much reduced complication rate compared
  with Node Clearance
• Seroma, lymphoedema, pain, numbness
• Overnight stay vs several day stay

67
SLNB

• A small percentage will require further surgery
  once node examined in lab
• Nodes examined with ultrasound and FNA prior to
  surgery
• Not suitable for everyone

68
(No Transcript)
69
Surgical probe
70
The Future

• Tomosynthesis
• On table sentinel node diagnosis
• Answers about breast screening

71
http//www.youtube.com/watch?vP5n3Avqqo2c
72
To Summarise

• Blackpool Victoria has opened a brand new breast
  clinic
• We have the latest technology available for the
  best possible care for our patients
• The new clinic pathway for rapid access and
  diagnosis will benefit all of our patients
• Most patients will have a benign diagnosis
  delivered quickly

73

• For the few patients who unfortunately have a
  malignant diagnosis
• They will be treated quickly, with all of the
  latest technologies available
• We should be able to upgrade for the future

74
The outlook is good
75
Thanks to the team!
