Title: EGFR Targets in Head and Neck Cancer


1
EGFR Targets in Head and Neck Cancer
Francisco G. Pernas, M.D. Vicente A. Resto, M.D.,
Ph.D. The University of Texas Medical
Branch Department of Otolaryngology Grand Rounds
Presentation March 31, 2011
2
EGFR Targets in Head and Neck Cancer
  • Outline
  • Introduction SCCA HN
  • Molecular Therapeutics
  • EGF Receptor
  • EGFR vIII Mutant
  • Updates in mAb Literature
  • Updates in Tki Literature
  • Conclusions

3
Introduction SCCA HN
4
SCC of the Head and Neck
  • 5th most common cancer worldwide.
  • In US alone 40,000 new cases annually.1
  • 11,000 Deaths annually.1
  • 200,000 Deaths worldwide annually.
  • Majority of cases present in advanced stages.

Site New Diagnoses Deaths
oral cavity pharynx 30,990 7,430
larynx 9,510 3,740
nasal cavity, nasopharynx, paranasal sinuses, cervical esophagus, skin nasal cavity, nasopharynx, paranasal sinuses, cervical esophagus, skin nasal cavity, nasopharynx, paranasal sinuses, cervical esophagus, skin
5
SCC of the Head and Neck
  • 60 of patients develop local disease recurrence
    within two years. 4
  • Current standard of care
  • Surgery and radiation
  • Platinum, 5-flourouracil or taxane based
    chemoradiation regimens.
  • Improvements in surgery and chemoradiation offer
    better organ preservation but they have resulted
    in only modest improvement in the 5-year survival
    of HNSCC in the past three decades.

6
SCC of the Head and Neck
  • 5-year survival rates of patients with locally
    advanced or metastatic disease are 48 and 26,
    respectively.
  • We need a better understanding of HNSCC at the
    cellular and molecular levels to guide
    development and use of new therapeutic
    interventions.

7
Risk factors for HNSCC
  • Lifestyle insults believed to cause 80 of HNSCC
  • Other causes include
  • HPV types 16 and 18 E6/E7 oncogenes
  • EBV LMP1 oncogene (nasopharyngeal carcinomas)

8
Molecular Therapeutics
9
Molecular Therapeutics
  • Only cetuximab (Erbitux) has been approved for tx
    of unresectable HNSCC.
  • Several drugs are in Phase III investigation.
    (All are EGFR targets)
  • Drugs in development
  • EGFR mAb
  • EGFR TKi EGFR/HER-2 dual TKi
  • VEGF mAb
  • COX-2 inhibitor
  • Farnesyl transferase inhibitor
  • Hypoxic cell sensitizer
  • Proteasome inhibitor
  • VEGF-2 TKi

Erolotinib, gefitinib, GW572016
SCH 66336
10
Biologics - Nomenclature
  • mab are monoclonal antibodies. i.e.
    Ceti(Humira)
  • ximab are chimeric monoclonal antibodies. i.e.
    Cetuximab (Erbitux)
  • mumab are humanized monoclonal antibodies.
    i.e. panitumumab, (Vectibix)
  • tinib are tyrosine kinase inhibitors. i.e..
    Gefitinib (Iressa), Erlotinib (Tarceva)
  • zomib are proteasome inhibitors. i.e.
    Bortezomib

11
Biologics - Nomenclature
  • Chimeric and humanized monoclonal antibodies
    are thought to be less likely to elicit
    neutralizing antibodies that can possibly reduce
    effectiveness.
  • cept indicate fusion of a receptor to the Fc
    portion of human IgG1 (alefacept Amevive for
    psoriasis, and etanercept Enbrel for rheumatoid
    arthritis).

12
EGF Receptor
13
EGFR
  • A 170180 kD transmembrane glycoprotein tyrosine
    kinase receptor.
  • Binds epidermal growth factor (EGF), transforming
    growth factor (TGF)-alpha, and other regulating
    proteins.
  • Activation results in a complex cascade of
    signaling pathways that influence normal cellular
    proliferation and differentiation and lead to
    strong mitogenic activity.

14
EGFR
  • Ligand binding results in
  • receptor dimerisation
  • activation of the intrinsic kinase domain
  • phosphorylation of tyrosine residues within the
    cytoplasmic tail.
  • Proteins dock on phosphorylated residues, leading
    to the activation of signaling pathways that
    promote cell growth, proliferation,
    differentiation, and migration.

15
ErbB subfamily of Tyrosine Kinase
  • Enzyme that can transfer phosphate from ATP to a
    tyrosine residue at the C-terminus.
  • An important mechanism in signal transduction.
  • Tyrosine kinase inhibitors act by competing with
    ATP for binding to the kinase.
  • Block transfer of phosphate.

16
erbB Family Ligands
  • Epidermal Growth Factor (EGF)
  • Transforming Growth Factor-a (TGF-a)

17
erbB Family of Receptors
  • erbB receptor family consists of 4 closely
    related members
  • erb B1 (EGFR, Her1)
  • erb B2 (Her2/neu)
  • erb B3 (Her3)
  • erb B4 (Her4)

Gefitinib, Cetuximab, Erlotinib
Herceptin
18
EGFR in HNSCC
  • Over-expression of EGFR is observed in 42 to 80
    of studied HNSCCs.
  • 7/8 trials showed a poorer outcome for patients
    with EGFR over-expression (756 patients).
  • EGFR expression seems to be strongly correlated
    with worse prognosis in HNSCC in patients treated
    with either chemotherapy /or XRT.
  • Suggesting over-expression may be associated with
    chemo/XRT resistance in these patients.

19
EGFR Structure
20
Simplified signaling cascade downstream of EGFR
EGFR
21
Reasons to block EGFR
  • Activation of receptor plays a critical role in
    the activation of cascades that been implicated
    in
  • Cell proliferation
  • Metastasis
  • Resistance to radiotherapy
  • Angiogenesis
  • Inhibition of apoptosis.
  • Over-expressed or constitutively activated in
    80-100 of SCCHN tumors.
  • Over-expression is correlated to resistance to tx
    and poorer outcomes.

22
Ways to Block EGFR
23
Anti-EGFR Therapeutic Agents
Tyrosine Kinase Inibitors (TKIs) Monoclonal Antibodies (mAb)
Agents gefitinib (Iressa) erlotinib (Tarceva) lapatinib cetuximab (Erbitux) panitumumab
Mechanism bind selectively to intracellular tyrosine kinase domain of EGFR bind specifically to extracellular ligand-binding domain of EGFR
Administration oral daily intravenous every 1-3 weeks
Adverse Effects rash diarrhea nausea rash hypersensitivity reactions
24
Updates in Cetuximab Literature
25
  • International Phase III trial
  • Stage III or IV SCCA, nonmetastatic Ca of
    oropharynx, hypopharynx, or larynx
  • 424 Pts. (73 centers in US, 14 Intl)
  • 213 ? XRT only
  • 211 ? XRT cetuximab

26
(No Transcript)
27
  • Conclusions
  • Cetuximab XRT is better than XRT alone in
    increasing locoregional disease control and
    survival
  • Downfalls
  • Does not compare to standard chemotherapy (5-FU
    and Cisplatin).

28
  • Retrospective chart review
  • Comparing cetuximab XRT with double modality
    chemo (ie, cisplatin 5-FU) XRT
  • SCCA of oral cavity, oropharynx, or larynx
  • Stage III to IVB
  • Unclear how selection of cetuximab vs chemo
    was done.

29
  • There did not appear to be differences in LRC,
    DMFS, DSS, or OS.

30
  • 2 yrs, 221 pts retrospective chart review
  • SCCA oropharynx, larynx, or hypopharynx
  • Compared concurrent cisplatin XRT to cetuximab
    XRT.
  • Patients were selected to receive cetuximab
    rather than cisplatin secondary to
  • auditory concerns, 30.6
  • renal,4.1
  • cardiac, 2.0
  • performance status, 16.3

31
Failure-free survival among patients with cancer
of (A) oropharynx, hypopharynx, or larynx (B)
oropharynx and (C) hypopharynx/ larynx treated
with cisplatin
32
Over-all survival among patients with cancer of
(A) oropharynx, hypopharynx, or larynx (B)
oropharynx and (C) hypopharynx/ larynx treated
with cisplatin
33
  • Conclusions
  • Concurrent cisplatin achieved better control
    rates, failure free survival and overall survival
    than cetuximab
  • Downfalls
  • Retrospective
  • Non-blinded
  • potential for pts selected to get cetuximab to
    be sicker.

34
Cetuximab vs Doublet Chemo
  • Holy Grail?
  • Double blind studies comparing cetuximab versus
    Cisplatin/5FU or Cisplatin/Taxol.
  • Most researchers instead focusing on adding
    cetuximab to existing protocols.

35
  • Prospective, blinded, 2 arms
  • Pts w confirmed recurrent or metastatic
    squamous-cell carcinoma of HN

36
  • Treatment
  • Arm 1
  • Carboplatin or cisplatin 5-Fu
  • Arm 2
  • Carboplatin or cisplatin 5-Fu cetuximab

37
(No Transcript)
38
  • Conclusions
  • Cetuximab does not seem to worsen XRT-related
    mucositis, but there is risk of acneiform rash
  • Addition of cetuximab improved overall survival
    when given as first-line treatment in patients
    with recurrent or metastatic SCCA

39
  • Phase II
  • Enrolled 36 patients, Stage III-IVb, previously
    untreated

40
  • Findings
  • HPV expression resulted in better progression
    free survival and overall survival.
  • EGFR expression was observed in 37 of 39
    available biopsies and did not impact response to
    therapy or clinical outcome.
  • 3-year progression-free survival ? 87
  • 3-year overall survival ? 91
  • Complete response in 70 of patients.

41
(No Transcript)
42
  • Conclusions
  • Demonstrated that addition of cetuximab to
    induction chemo followed by maintenance cetuximab
    produced acceptable rates of cumulative cisplatin
    toxicities.
  • Three-year PFS and OS survival were very
    promising in a population with more than 90
    stage IV disease.

43
  • Panitumumab FDA approved for Colon Ca
  • fully human IgG2 mAb targeting EGFR
  • Less immunogenic than chimeric mAb
  • Longer half-life and higher affinity for EGFR
    than other mAbs

44
  • Treatment algorithm
  • Panitumumab was administered weekly
  • Paclitaxel was given weekly i.v. over 60 min
    after panitumumab
  • Carboplatin was given i.v. over 3045 min
    following paclitaxel
  • Patients were treated using a dose-painting IMRT
    approach with a single plan to deliver 35
    fractions once daily over 7 weeks

45
  • Conclusions
  • Generally well tolerated with comparable and
    acceptable rates of mucositis.
  • At median follow-up of 21 months, 18 of 19
    patients (95) remained disease free

46
Areas of Future Research
47
  • EGFRvIII
  • Extensively studied in gliomas where it is
    related to increased tumorigenicity.
  • Not observed in normal tissue, unique to cancer.
  • Truncated version of wildtype EGFR, that is
    constitutively phosphorylated in a
    ligand-independent manner.
  • Difficult to study in-vitro, must transfect cells.

48
EGFRvIIIA.k.a. de2-7 EGFR or ?EGFR
  • Variant III EGFR (100-140kDa) oncoprotein.
  • Has an in-frame deletion of extracellular domain.
  • Preferentially activates cascade by PI3K.

49
  • EGFRvIII
  • Present in 42 of patients with HNSCC

50
  • EGFRvIII
  • Less in vitro cellular death when treated with
    cetuximab
  • Larger tumor volumes and decrease response in
    mouse model

51
Conclusions EGFRvIII cells were less sensitive
to cisplatin and cetuximab. This leads to
enhanced growth and resistance to targeting.
52
Interestingly EGFRvIII Cells were equally
susceptible to EGFR TKI treatment. This is
consistent with the fact that both EGFRvIII and
EGFRwt contain an intact tyrosine kinase domain.
53
Is HPV a Factor?
54
  • Conclusions
  • HPV positive OP cancer higher overall survival,
    disease-free progression and lower local-regional
    relapse
  • Implications in EGFR directed therapy?

55
HPV EGFR Over-expression
  • In general, there is a greater benefit from
    cetuximab for patients with oropharyngeal cancer
    compared with other subsites.
  • RTOG 0920 will help determine if HPV status has
    clinical implications in regards to response to
    cetuximab.

56
Importance of Rash
  • Acneiform rash induced by cetuximab was initially
    thought to be reason to stop therapy.
  • Seems the more severe the rash the better
    response to cetuximab.
  • Biomarker of response?

57
Importance of Rash
  • Rash may be due to EGFR-R521K genotype or other
    EGFR variation.
  • Specifically EGFR-R521K demonstrates increased
    cetuximab binding.
  • Pts with EGFR-R521K developed more severe rash.
  • Patients with the G/G genotype of EGFR-R521K who
    significantly developed skin rash showed a trend
    to prolonged progression-free survival on
    cetuximab/docetaxel treatment.

58
Updates in TKi Literature
59
Tumor Microenvironment
  • Response of tumors to radiation depends on
  • Cell-extracellular matrix interactions
  • Tumor oxygenation
  • Manipulating this microenvironment has proven
    challenging.
  • Anti-angiogenic therapy has been used to
    normalize tumor microenvironment (VEGF)

60
Tumor Microenvironment
  • Pharmacologic inhibition of EGFR can decrease
    VEGF expression and therefore modify
    angiogenesis.
  • Theory
  • Erlotinib would indirectly lead to vascular
    normalization and decrease tumor hypoxia.
  • Thereby leading to greater effects of chemo and
    radiotherapy.

61
  • In mice, Erlotinib
  • Increased blood flow
  • Decreased hypoxia
  • Oxygenation benefits
  • Better drug delivery
  • Free radical formation

62
Chemo-sensitized Radio-sensitized
63
  • Conclusions
  • Erlotinib
  • Modulated tumor vascularity
  • Modulated tumor oxygenation
  • Resulted in improved response to cisplatin and
    radiation.
  • Similar effects have been shown with cetuximab.

64
  • Tyrosine Kinase Inhibitors
  • What makes Tki clinically interesting
  • Orally administered
  • Small molecule size
  • Intra-cellular target
  • Chemo-sensitizer
  • Radio-sensitizer
  • While gefitinib has had poor clinical responses,
    other TKis have shown promise.
  • Only demonstrated in vitro.

65


Cetuximab induced EGFR translocation to nucleus.
66

Radiation induced EGFR translocation to nucleus.
67

Dasatinib blocked XRT and cetuximab induced EGFR
translocation to nucleus and phosphorylation of
EGFR.
68
  • Conclusions
  • Nuclear translocation of EGFR has been shown to
    correlate with resistance to both cetuximab and
    radiation.
  • Cetuximab can result in paradoxical
    phosphorylation/activation of EGFR.
  • Suggests that Dasatinib can limit EGFR
    translocation to the nucleus and may enhance
    radiotherapy plus cetuximab.

69
  • Phase I/II trial.
  • 31 patients (Stage III IV).
  • Received erlotinib daily throughout XRT and 8
    days prior to XRT with 70Gy.
  • Cisplatin at days 8, 29, and 50.

70
  • Complete response seen in 74.2 of patients.
  • Progression free survival ? 61 (3yrs)
  • Overall survival ? 72 (3yrs)

71
Patients who developed acneiform rash tended to
have better overall survival.
72

73
Future
  • Work started by Bonner et. al. by adding
    cetuximab to XRT needs to be supplemented in view
    of
  • Doublet chemotherapy advancement in HN
  • Further studies combining EGFR targeted therapies
    with cisplatin/5FU
  • Demonstrate chemo and radio sensitizing
    properties of EGFR blockade in patients
  • Take advantage of sensitizing properties of EGFR
    biologics

74
Conclusions
  • EGFR is highly over expressed in HN Scca
  • Mutant forms exist, which are constitutively
    activated, resulting in decreased activity of
    EGFR blocking.
  • Early Phase II trial data suggests addition of
    cetuximab or erlotinib improves disease free
    progression and survival.
  • HPV status may help target therapy.
  • Acneiform rash is a marker of positive response
    to both monoclonal antibodies and TKi.

75
Conclusions
  • Targeting EGFRvIII specifically with Tki.
  • Further work is needed to determine which tumors
    are responders to EGFR targets.
  • Further work is needed to develop new protocols
    that limit toxicities of combining chemo and EGFR
    biologics.
Write a Comment
User Comments (0)
About PowerShow.com
