Sedimentary Geology Geos 240

1
Sedimentary GeologyGeos 240 Chapter
8Depositional EnvironmentsPart 5Shallow
Carbonates Evaporites

• Dr. Tark Hamilton
• Readings from Sediments Basins (81-67)
• Camosun College

2
(No Transcript)
3
Bahamas Platform Fringing Reefs
.
La Habana
4
Transgression Optimal Carbonate Factory
5
Continental Shelf Eastern Nicaragua
6
Florida Keys Shallow Back Reef Lagoon
Mangrove Swamps
20 km
7
The Great Barrier Reef Cretaceous through
Recent! Queensland OZ
8
Lateral Progradation Bahamas Bank
Reflection Seismic Section Interpretation
9
Cross Section of Redwater Reef, Dev.NW of
Edmontonflexed later
10
Devonian Reef, Gyrfalcon Bluff, Banks Is
11
Devonian Crinoid Reef, Princess Royal Is
12
Fossiliferous Producing Dev Kee Scarp Reef Norman
Wells
13
Devonian Coral Reef, Norman Wells NWT
14
Dev. Reef Dolomite/Stromotoporoid Norman Wells
15
Ordovician Bioherm, Niagara Falls
16
Devonian Reef Dolomitized StromotoporoidCairns
Formation, Grassi Lakes Reef, Canmore
17
Devonian Reef Dolomitized StromotoporoidCairns
Formation, Grassi Lakes Reef, Canmore
18
Devonian Reef Dolomitized StromotoporoidCairns
Formation, Grassi Lakes Reef, Canmore
19
(No Transcript)
20
Proterozoic Stromatolites, Dismal Lakes NWT
21
Silurian Stromatolites, Somerset Island NWT
Supertenuous Drape
Tidal Scour
Algal Mound Buildup
22
Sabkha DepositionalModel, Persian GulfArid Tidal
Coast
23
Ancient Tidal Limestone Facies
24
Mississippian Lisburne Limestone Tidal Crossbeds
Diagenetic Chert
25
Ordovician Intraclast Dolomite Breccia, Somerset
Is. NWT
26
Silurian Ripples Flasers Dolomites, Somerset
Is. NWT
27
The New Conservative Ordovician Burrow Mottled
Limestone Ottawa
28
Ordovician Tyndall Stone, Burrow Mottled
Dolomite, Red River Fm Manitoba
29
Ripups Scours Silurian Dolomites, Somerset Is.
NWT
30
Transgressive Phase Rising System Tract
31
Seds can come from Out of plane
Regressive Phase Falling System Tract
32
C-Ord. Cow Head Turbidites, NF
33
C-Ord. Cow Head Debris Flow, NF
34
C-Ord. Cow Head Deformed Clast
35
Exhumed Carboniferous Facies TransitionSverdrup
Basin, Ellesmere Island
Sverdrup Basin Rim
Bioclastic Debrites
Anhydrite, Shale, Detrital Carbonates
36
Evaporites Evaporite Basins

• Geographically Enclosed Water Bodies
• Tropics /- 30 Latitude, descending dry air
• Sabkhas, Playas, Salinas, Salt Lakes
• Incipient Rift Basins Triassic Margins of
  Atlantic
• Restricted Back Reef Basins Carbs Anhydrite
• Evaporated Cratonic/Epicontinental Seas Devonian
  of Alberta, Sask., Michigan Zechstein Perm/Penn
  of North Sea Basin
• Often alternate climatically with humid clastics

37
Usiglios Experiment Evaporation of Sea Water
Sequence of Salts
s.g. 1.035
Calcite
Anhydrite
Halite
Bitterns
38
Development of Evaporite Basin
39
Development of Evaporite Basin
40
Evaporite Minerals

• Dominant Evaporite Minerals include Carbonates,
  Chlorides, Sulphates, Borates Nitrates
• Marine systems dominantly produce Carbonates,
  Chlorides Sulphates
• Arid Terrestrial Systems produce unusual
  diagenetic minerals in pore spaces and beds of
  Borates Nitrates additional to the Carbonates,
  Chlorides Sulphates.
• Additional to the unusual Continental anion
  Chemistry, salts of metals form some unusual
  brine minerals, Cu, Ni, Zn, Pb, Ag and even
  (NH4) !
• Salts precipitate in inverse order depending on
  their solubility. (solubility in strong/odd
  brines is empirical)
• Salts in vadose zone porosity are important in
  soils

41
Textures in Resedimented Evaporites,
ItalyMessinian (5Ma) Mediterranean Basin
42
Evaporite Minerals

• Carbonates
• Mineral Formula
• Calcite CaCO3
• Dolomite CaMg (CO3 )2
• Siderite FeCO3
• Natrite Na2CO3 Natron6(H2O)
• Trona Na3(CO3)(HCO3)2(H2O)
• (Green River, WY Lake Magadi, Kenya)

43
Carbonate Minerals
Trona
Natrite
44
Sandstone with Cubic Halite CastsJurassic, Utah
45
Evaporite Minerals

• Chlorides
• Mineral Formula
• Halite NaCl
• Sylvite KCl
• Carnallite KMgCl3 ? 6H2O

46
Chloride Minerals
Sylvite
Halite Hopper Crystals
Carnallite
Halite
47
Cyclic Crossbedded Devonian Halite, Goderich ON
In what kind of Basin would Cyclic Halite beds
form?
In what sort of flow regime would Halite X-beds
form?
48
Evaporite Minerals

• Sulphates
• Mineral Formula
• Anhydrite CaSO4
• Gypsum CaSO4? 2H2O
• Langbeinite K2Mg2(SO4)3
• Polyhalite K2Ca2Mg(SO4)4 ? 2H2O
• Kieserite MgSO4? H2O
• Kainite KMg(SO4)Cl ? 3H2O

49
Interbedded Gypsum Calcsiltite,Silurian
Somerset Island
?
Solutional Collapse
50
Interbedded Anhydrite Shale Ellesmere Island
51
Sulphate Minerals
Polyhalite
Langbeinite
Kieserite
Kainite
52
Evaporite Minerals

• Nitrates
• Mineral Formula
• Niter KNO3
• Nitratine NaNO3? 2H2O
• Nitrocalcite Ca(NO3)2 ? 4H2O
• Nitrobarite Ba(NO3)2
• Gerhardtite Cu2(NO3)(OH)3

53
Nitrate Minerals
Niter
Nitratine
Nitrobarite
Gerhardtite
Nitrocalcite
54
Borax MinesDeath Valley CA
55
Evaporite Minerals

• Borates
• Mineral Formula
• Boracite Mg3ClB7O13
• Borax Na2B4O72 ? 10H2O
• Colemanite CaB3O4(OH)3 ? 3H2O
• HydroBoracite CaMg B3O4(OH)32 ? 3H2O
• Larderellite (NH4 )B5O6(OH)4
• Tincalconite Na2B4O7 ? 5H2O
• Ulexite NaCaB5O6(OH)6? 5H2O

56
Borate Minerals
Boracite
Colemanite
Hydroboracite
Borax
Larderellite
Ulexite
Tincalconite
57
Salar de Atacama, Antofagasta Chile
58
The End Chapter 8 Part 5!
