Basic Electronics

1
Forging new generations of engineers
2
Gateway To Technology

• Basic Electronics

3
Electricity-Electronics

• Electricity The flow of electrons.
• Electronics The study of the flow of electrons
  in active devices.

4
Resistor

• Reduces current flow.
• Changes electrical energy into heat energy.
• Rated in watts (amount of heat energy can
  transfer into the air).

5
Capacitor

• A device that stores/holds energy.

6
The First Transistor
http//www.computerhistory.org/timeline/timeline.p
hp?timeline_categorycmpnt
7
Transistor Defined

• A transistor is a small electronic device that
  can cause changes in a large electrical output
  signal by small changes in a small input signal.

8
The 3 Transistor Leads

• Base
• Collector
• Emitter

9
PNP Transistor
10
Transistor Schematic
11
Diode

• A device that allows current to flow in only one
  direction. ( to -)

12
(No Transcript)
13
LED
14
Photocell

• Light
• Low resistance
• Dark
• High resistance

15
Thermistor

• Thermal-Resistor
• Temperature rises
• Resistance drops
• Temperature lowers
• Resistance increases

16
Night Light
