Technical Equipment for agricultural anaerobic digesters in Europe

1
Technical Equipment for agricultural anaerobic
digesters in Europe
Camilo Andrés Wilches Tamayo Biogas weser ems
GmbH Co KG
2
Table of contents

• Companys Presentation
• Possible Biogas Power Plant configurations
• Renewable raw materials
• Biowaste
• Technical equipment
• Feeding system
• Pumping system
• Heating system
• Agitators
• Gas storage in the digester
• Pasteurization

3
The company

• biogas weser ems GmbH Co .KG is a company with
  over 10 years experience specializing in design,
  planning and construction of biogas power plants
• More than 150 installed biogas plants
• Installed capacity gt98 MWel
• Energy parks 8,5MWel
• International Projects

4
Possible configurations of the biogas plant

• Renewable raw materials.
• Majority of German plants (EEG 2004)
• Independence of the farmer
• Price 19 cent/kWh Germany
• 13.5 cent/kWh Spain
• 28 cent/kWh Italy
• Special Equipment
• Solid feeder
• Pumps
• Agitators

Renewable raw materials. NaWaRo
5
Possible configurations of the biogas plant

• Biowaste
• This region has an intensive food and livestock
  production
• Waste market
• Price 9 cent/kWh Germany
• 13.5 cent/kWh Spain
• 22 cent/kWh Italy
• Special Equipment
• Pasteuritzation unit
• 2 Pumps are required
• Double walled digester with leakage detection

Biowaste
6
Technical equipment
Biogas
Feeding system
Heating system
Digestates Storage
CHP
Pumps
Biogas
Biogas
Digester 1
Digester 2
7
Technical equipment
Feeding system
8
Technical equipment Feeding system

• Depends of the substrate
• Dry matter lt 12 pumped from tanks to the
  digesters
• Dry matter gt 25 solid feeder and augers to the
  digesters
• Configurations Walking floor corn,
  cereals
• (size 20-120 m³)
• Mixer feeder straw
• (size 8 -80m3) manure straw
• paste materials (powder)
• liquid producing materials

9
Technical equipment
Feeding system
Pumps
10
Technical equipment Pumping system

• In general a susbtrate is pumpable when
• Dry matter lt12 , homogeneos, particle size lt
  12mm
• Pumping system
• Any possible substrate
• movement is allowed

11
Technical equipment Pumps

• Most of the pumps used are Positive Displacement
  Pumps
• Pumps type
• Rotary lobe pump
• price high wear (more maintenance)
• size -
• easy maintenance suction
  capacity lt 0,9 bar
• Progresive cavity pump
• less maintenance time demanding
  maintenance
• high pressure (25 bar) -
• suction capacity lt 0,9 bar
• 500 kW power plant 11 kW, 50 m3/h

12
Technical equipment Pumps

• Long distance between substrate storage tank and
  pump station ?
• Centrifugal pump
• directly in the tank
• Normally used for manure
• DM 8 11 kW 90 m3/h.

13
Questions? (Break 5 min)
14
Technical equipment
Feeding system
Heating system
CHP
Pumps
15
Technical equipment Heating system

Heat requirements (625 kW biowaste) Heat up
substrate (8C to 40) 38,64 kWth Maintain
temperature digesters 170 kWth (outside
temperature -12C) Pasteurizer 70C 1 hour
80 kWth External user (green house,
industry,,,)
A
B
T 40
T 35
16
Technical equipment Heating system

17
Technical equipment Agitators
Feeding system
Heating system
Digestates Storage
CHP
Pumps
Digester 1
Digester 2
18
Technical equipment Agitators

• Submersible Agitators Used in all installations
• Possibility to change - height
  - orientation
• 17kW -gt
  agitate 1000 m3
• 10 min
  every hour
• always during digester feeding
• Dry substrate Agitators Used for dry substrates
• straw, mais, cereals, offal flour
• Low density
  of the substrates
• lt 1 g / cm3
• Destroy acumulations of solids.
• 15kW
  similar capacities

19
Technical equipment Gas storage membrane
Biogas
Feeding system
Heating system
Digestates Storage
CHP
Pumps
Biogas
Biogas
Digester 1
Digester 2
20
Technical equipment Gas storage membrane

• Digesters section

21
Technical equipment Pasteurization
Biogas
Feeding system
Heating system
Digestates Storage
CHP
Pumps
Pasteurization
Biogas
Biogas
Digester 1
Digester 2
22
Technical equipment Pasteurization

• Heat treatment (EU 1774)
• avoid risk of dispersal of patogens from any
  animal subproduct
• 70C, 1h
• Pumpable material
• Two pumps are required
• Tanks with heating and mixing system.
• When sizing consider heating time (4 h)
• Pasteurized material should not be put directly
  in to digester

23
Questions? Camilo Wilches
T. biogas-weser-ems GmbH Co.KG camilo.wilches_at_bio
gas-weser-ems.de www.biogas-weser-ems.de
