Invertebrates

1
Chapter 33

• Invertebrates

2
Lets meet the Invertebrates
3
Life Without a Backbone

• Invertebrates
• Are animals that lack a backbone
• Account for 95 of known animal species

Xmas Tree Worm
4
A review of animal phylogeny
5
Invertebrate diversity
6
Invertebrate Diversity
7
Invertebrate Diversity
8
Sponges (Phylum Porifera)

• Sponge characteristics
• Sessile
• Porous body
• Choanocytes flagellated collar cells generate a
  water current through the sponge and ingest
  suspended food by phagocytosis
• Live in both fresh and marine waters
• Lack true tissues (groups of similar cells that
  form a functional unit). All animals except
  sponges belong to the clade Eumetazoa, the
  animals with true tissues
• Most sponges are hermaphrodites (each individual
  functions as both male and female)

9
Sponges

• Sponges are suspension feeders
• Capturing food particles suspended in the water
  that passes through their body

10
Cnidarians (Phylum Cnidaria)

• A diverse range of both sessile and floating
  organisms including hydras, jellies, sea
  anemones, and corals
• Cnidarian characteristics
• radial symmetry
• gastrovascular cavity (digestive compartment)
• Cnidocytes

movie
11
Cnidarian Body Plan

• Relatively simple diploblastic (two germ layers),
  radial body plan
• Basic body plan of a cnidarian is a sac with a
  central digestive compartment, the gastrovascular
  cavity
• A single opening functions as both mouth and anus
• There are two variations on this body plan
• The sessile polyp and the floating medusa

12
Cnidarian Feeding

• Cnidarians are carnivores
• That use tentacles to capture prey
• The tentacles are armed with cnidocytes
• Unique cells that function in defense and the
  capture of prey

Threads can inject poison into the prey, or stick
to or entangle the target
13
Classes of Phylum Cnidaria
14
Hydrozoan Life Cycle
The zygote develops into a solid ciliated
larva called a planula.
The planula eventually settles and develops
into a new polyp.
5
6
15
Classes Hydrozoa, Scyphozoa, Cubozoa, and
Anthozoa
16
Cnidarian Classes

• In the class Hydrozoa
• Most hydrozoans alternate between polyp and
  medusa forms. Freshwater Hydras exist only in the
  polyp form.
• In the class Scyphozoa
• Jellies (medusae) are the prevalent form of the
  life cycle
• In the class Cubozoa, which includes box jellies
  and sea wasps
• The medusa is box-shaped and has complex eyes
• Class Anthozoa includes the corals and sea
  anemones
• Which occur only as polyps

Hydra
Purple coral
17
Hydra movie 1
18
Hydra movie 2
19
Coral reproduction
20
Jellyfish movie
21
Bilateria

• Most animals have bilateral symmetry
• The vast majority of animal species belong to the
  clade Bilateria
• Which consists of animals with bilateral symmetry
  and triploblastic development

22
Flatworms

• Members of phylum Platyhelminthes
• Live in marine, freshwater, and damp terrestrial
  habitats. Some are parasitic.
• Are flattened dorsoventrally and have bilateral
  symmetry
• Undergo triploblastic development
• Are acoelomates (lack a coelom) with
  gastrovascular cavities.
• Lack a digestive system entirely and absorb
  nutrients across their body surface.

23
Flatworm Classes
24
Turbellarians

• Are nearly all free-living and mostly marine

25
Turbellarians

• Planarians are common examples of turbellarians
• They have light-sensitive eyespots and
  centralized nerve nets

26
Monogeneans and Trematodes

• Live as parasites in or on other animals They
  parasitize a wide range of hosts
• Most monogeneans are parasites of fish
• Trematodes (Flukes) that parasitize humans spend
  part of their lives in snail hosts

27
Tapeworms (Class Cestoda)

• Are also parasitic and lack a digestive system

28
Rotifers (Phylum Rotifera)

• Are tiny animals that inhabit fresh water, the
  ocean, and damp soil
• Rotifers are smaller than many protists
• But are truly multicellular and have specialized
  organ systems
• Rotifers have an alimentary canal
• A digestive tube with a separate mouth and anus
  that lies within a fluid-filled pseudocoelom
• Some species of rotifers reproduce by
  parthenogenesis
• In which females produce more females from
  unfertilized eggs

29
Rotifers (Phylum Rotifera)
30
Rotifer movie 2
31
Three Phyla of Lophophorates Ectoprocts,
Phoronids, and Brachiopods

• Lophophorates have a lophophore
• A horseshoe-shaped, suspension-feeding organ
  bearing ciliated tentacles that trap suspended
  food particles

32
Ectoprocts

• Are colonial animals that superficially resemble
  plants

33
Phoronids

• Are tube-dwelling marine worms ranging from 1 mm
  to 50 cm in length

34
Brachipods

• Superficially resemble clams and other
  hinge-shelled molluscs
• But the two halves of the shell are dorsal and
  ventral rather than lateral, as in clams

35
Nemerteans (Phylum Nemertea)

• Commonly called proboscis worms or ribbon worms
• The nemerteans unique proboscis
• Is used for defense and prey capture
• Is extended by a fluid-filled sac
• Nemerteans also have a closed circulatory system
• In which the blood is contained in vessels
  distinct from fluid in the body cavity

36
Molluscs (Phylum Mollusca)

• Phylum Mollusca Includes snails and slugs,
  oysters and clams, and octopuses and squids
• Mollusc characteristics
• Body plan muscular foot, visceral mass, and a
  mantle
• Mantle is a fold of tissue that drapes over the
  visceral mass and secretes the shell.
• Most molluscs are marine, though some inhabit
  fresh water and some are terrestrial
• Molluscs are soft-bodied animals, but most are
  protected by a hard shell
• Most molluscs have separate sexes with gonads
  located in the visceral mass
• The life cycle of many molluscs includes a
  ciliated larval stage called a trochophore

37
Mollusc anatomy
38
Classes of molluscs
39
Chitons

• Class Polyplacophora is composed of the chitons
  (Oval-shaped marine animals encased in an armor
  of eight dorsal plates)

40
Gastropods

• About three-quarters of all living species of
  molluscs belong to class Gastropoda

41
Gastropods

• Gastropod characteristics
• Most are marine, but there are also many
  freshwater and terrestrial species
• Possess a single, spiraled shell
• Slugs lack a shell or have a reduced shell
• The most distinctive characteristic of this class
  is a developmental process known as torsion,
  which causes the animals anus and mantle to end
  up above its head

42
Bivalves (Molluscs of class Bivalvia)

• Include many species of clams, oysters, mussels,
  and scallops
• Have a shell divided into two halves

43
Bivalves

• The mantle cavity of a bivalve contains gills
  that are used for feeding as well as gas exchange

44
Clam locomotion
45
Cephalopods

• Class Cephalopoda includes squids and octopuses
• Carnivores with beak-like jaws surrounded by
  tentacles of their modified foot

46
Octopus

• Most octopuses creep along the sea floor in
  search of prey

47
Squid

• Squids use their siphon to fire a jet of water,
  which allows them to swim very quickly

48

• One small group of shelled cephalopods
• The nautiluses, survives today

49
Annelids

• Annelids
• Segmented worms
• Have bodies composed of a series of fused rings
• 3 Classes Oligochaeta, Polychaeta, Hirudinea

50
Classes of Annelida
51
Oligochaetes

• Oligochaetes (class Oligochaeta)
• Are named for their relatively sparse chaetae
  (bristles made of chitin)
• Include the earthworms and a variety of aquatic
  species
• Earthworms eat their way through the soil,
  extracting nutrients as the soil moves through
  the alimentary canal
• Which helps till the earth, making earthworms
  valuable to farmers

52
Earthworm anatomy
53
Polychaetes

• Members of class Polychaeta possess paddlelike
  parapodia that function as gills and aid in
  locomotion

54
Leeches

• Members of class Hirudinea are blood-sucking
  parasites, such as leeches

55
Nematodes (roundworms)

• Nematodes are nonsegmented pseudocoelomates
  covered by a tough cuticle
• Among the most widespread of all animals,
  nematodes, or roundworms
• Are found in most aquatic habitats, in the soil,
  in moist tissues of plants, and in the body
  fluids and tissues of animals

56
Nematode movie
57
Nematodes

• The cylindrical bodies of nematodes are covered
  by a tough coat called a cuticle

58
Nematodes

• Some species of nematodes are important parasites
  of plants and animals

Trichinella spiralis encysted in human muscle
tissue
59
Arthropods

• Arthropods are segmented coelomates that have an
  exoskeleton and jointed appendages
• Two out of every three known species of animals
  are arthropods
• Members of the phylum Arthropoda
• Are found in nearly all habitats of the biosphere

60
Arthropod Characteristics

• The diversity and success of arthropods
• Are largely related to their segmentation, hard
  exoskeleton, and jointed appendages
• Arthropods have an open circulatory system
• In which fluid called hemolymph is circulated
  into the spaces surrounding the tissues and
  organs
• A variety of organs specialized for gas exchange
  have evolved in arthropods
• The body of an arthropod is completely covered by
  the cuticle, an exoskeleton made of chitin
• When an arthropod grows it molts its exoskeleton
  in a process called ecdysis

61
Segmentation

• Early arthropods, such as trilobites showed
  little variation from segment to segment
• As arthropods evolved the segments fused, and the
  appendages became more specialized
• The appendages of some living arthropods are
  modified for many different functions

62
Subphyla of Arthropoda
63
Cheliceriforms

• Named for clawlike feeding appendages called
  chelicerae
• Includes spiders, ticks, mites, scorpions, and
  horseshoe crabs
• Most of the marine cheliceriforms are extinct
• But some species survive today, including the
  horseshoe crabs

64
Cheliceriforms

• Most modern cheliceriforms are arachnids
• A group that includes spiders, scorpions, ticks,
  and mites

65
Arachnids

• Arachnids have an abdomen and a cephalothorax
• Which has six pairs of appendages, the most
  anterior of which are the chelicerae. (4 pairs of
  walking legs)

66
Myriapods

• Subphylum Myriapoda
• Includes millipedes and centipedes
• Millipedes, class Diplopoda
• Have a large number of legs
• Each trunk segment has two pairs of legs
• Centipedes, class Chilopoda
• Are carnivores with jaw-like mandibles
• Have one pair of legs per trunk segment

67
Insects

• Subphylum Hexapoda, insects and their relatives
• Are more species-rich than all other forms of
  life combined
• Live in almost every terrestrial habitat and in
  fresh water
• The internal anatomy of an insect includes
  several complex organ systems

68
Insect anatomy
69
Insects

• Flight is one key to the great success of insects
• An animal that can fly can escape predators, find
  food, and disperse to new habitats much faster
  than organisms that can only crawl

70
Metamorphosis

• Many insects undergo metamorphosis during their
  development
• In incomplete metamorphosis, the young, called
  nymphs
• Resemble adults but are smaller and go through a
  series of molts until they reach full
  size (example grasshoppers)
• Insects with complete metamorphosis have larval
  stages specialized for eating and growing that
  are known by such names as maggot, grub, or
  caterpillar
• The larval stage looks entirely different from
  the adult stage
• Metamorphosis from the larval stage to the adult
  stage occurs during a pupal stage

71
Metamorphosis
movie
72
26 Orders of Insects
73
26 Orders of Insects
74
Crustaceans

• While arachnids and insects thrive on land
• Crustaceans, for the most part, have remained in
  marine and freshwater environments
• Crustaceans, subphylum Crustacea
• Typically have biramous (branched) appendages
  that are extensively specialized for feeding and
  locomotion

75
Decapods

• Decapods are all relatively large crustaceans
• And include lobsters, crabs, crayfish, and shrimp

76
Decapod movie
77
Planktonic crustaceans

• Planktonic crustaceans include many species of
  copepods
• Which are among the most numerous of all animals

78
Barnacles

• Barnacles are a group of mostly sessile
  crustaceans whose cuticle is hardened into a shell

79
Deuterostomes

• Echinoderms and chordates are deuterostomes
• Chordates and echinoderms share the
  characteristics of deuterostomes
• Radial cleavage
• Formation of the mouth at the end of the embryo
  opposite the blastopore

80
Echinoderms

• Echinoderm characteristics
• Sea stars and most other echinoderms are
  slow-moving or sessile marine animals
• A thin, bumpy or spiny skin covers an
  endoskeleton of hard calcareous plates
• Unique to echinoderms is a water vascular system
• network of hydraulic canals branching into tube
  feet that function in locomotion, feeding, and
  gas exchange

81
Echinoderm movie
82
Echinoderm anatomy
83
Echinoderm classes
84
Sea Stars

• Sea stars, class Asteroidea
• Have multiple arms radiating from a central disk
• The undersurfaces of the arms bear tube feet,
  each of which can act like a suction disk

85
Brittle Stars

• Brittle stars have a distinct central disk and
  long, flexible arms

86
Sea Urchins and Sand Dollars

• Sea urchins and sand dollars have no arms, but
  they do have five rows of tube feet that function
  in movement

Sand Dollar
87
Sea Lilies and Feather Stars

• Sea lilies live attached to the substrate by a
  stalk
• Feather stars
• Crawl about using their long, flexible arms

88
Sea Cucumbers

• Sea cucumbers do not look much like other
  echinoderms
• They lack spines, and their endoskeleton is much
  reduced

89
Sea Daisies

• Sea daisies were discovered in 1986
• And only two species are known

90
Chordates (Phylum Chordata)

• Chordates
• Two subphyla of invertebrates as well as the
  hagfishes and the vertebrates
• Share many features of embryonic development with
  echinoderms

91
Review of Animal Phyla
