DavinciTurboRIP SW for Small Dye-Sublimation printer Proposal

1
DavinciTurboRIP SW for Small Dye-Sublimation
printer Proposal

• www.fullbitsoft.com

2
Contents

• Introduction
• Key Features
• Features Sheet
• Why DavinciTurboRIP ?
• How to setting printers ?
• Benefits
• Contact US

3
Introduction

• Let me introduce DavinciTurboRIP for
  Dye-Sublimation for small printing business.
• Recently, epson published small A3 printer (Epson
  R1800), 8 head, same spec as LFP, using 180
  nozzles . Dye-sublimation does not need 8colors
  , CMYK 4 color is OK.
• We changed 8colors as CMYK Double, (Korean
  Patented RIP SW Technology) Fast as LFP.
• (CMYK Double mode 720x360 dpi 14 sq m/h) Epson
  R1800 A3 Printer, RIPPrint option.

4
Key Features

• CMYK Double High Speed Printing Technics (Korean
  Patent)
• Support Roll Paper, 1 Job over 10m , 100m above
  printing OK.
• Support N x N Copy Print
• Support Nesting Print
• Support Mirror print option (for use of
  Dye-Sublimation)
• Direct printing from Variable Windows
  applications.( Word, PowerPoint, .. )
• Supported Printers (for Dye-Sublimation) Epson
  R1800/2400/4800/7800/9800
• Support General RIP SW features

5
Feature sheet
Features Specification
Supported files EPS, JPG, TIF, PSD, BMP, PNG
16 bit Image Engine enable 16 bit gradation smooth
RIP Print
Batch Job Print ( RIP Queue Support)
Direct Printing from Windows Application (Word, PowerPoint, HWP..)
Variable Dot Support
N x N copy print
Nesting print
Printing Options /Tile/ Crop/Sewing Line/Cutting Line/ Color Bar
Density generate support
Supported Device for Density SpectroScan, EyeOne, DTP41
ICC Profiles Support ( Vector / Raster )
User defined Color Curve
Special option 4channel CMYK for dye-sublimation inks, rest 4channel CMYK for pigment (sublimation transfer paper printing ) Explain later
Generating ICC Profile services, remote AS

6
Why DavinciTurboRIP for Dye-Sublimation?

• Patented CMYK Double technology ( Korea Patent
  10-0662211 ) , High speed CMYK Double (CMYKCMYK)
  mode enabled in RIP SW.
• SW color Mirroring (YMCKKCMY) decrease
  bidirection banding.
• Support Roll paper, You can setting automatic
  large printing size printing even 100m above.
  (need large roll paper setter)
• Cheap Epson R1800 printer enable Fast printing
  system, same as LFP. ( 14 sq m /h )
• Target Area All kind of Dye-Sublimation mass
  production printing is OK.
• Special option for dye-sublimation ink printing
  and sublimation transfer paper printing(pigment
  inks). 4channels CMYK for dye-sublimation inks,
  4channels CMYK for pigment inks. - Twin Printing
  method enable, one printer prints dye-sublimation
  and pigment inks also.

Channels Channels Channels Channels Channels Channels Channels Channels
1 2 3 4 5 6 7 8
Original Y M C K Pk R B Go
TurboRIP Y M C K K C M Y
Channels Channels Channels Channels Channels Channels Channels Channels
1 2 3 4 5 6 7 8
Original Y M C K Pk R B Go
4-dye-sub 4-pigment Y M C K Y M C K
7
How to setting printer ?
Step1. Change cartridges fill inks
Setting Roll papers

1. Setting Roll Paper Guide.(Included Epson R1800)
2. DavinciTurboRIP for Dye-Sublimation version
   supports Roll paper and default setting for Roll
   paper. So you must using Roll paper only.

• Setting Infinite refill Kit .
• Setting inks like this way. (Original
  YMCKPkRBGo
• Changed YMCKKCMY )

Print with DavinciTurboRIP

1. Install DavinciTurboRIP for Dye-sublimation and
   print to Epson R1800 printer.
2. Select ICC profiles proper dye-sublimation inks.

8
Benefit

• Cheap printer (Epson R1800, R2400, R1900) enable
  almost same speed as LFP (Paper width 33 cm)
• - Epson R1800 Printer Infinite refill
  equipment DavinciTurboRIP for Dye-Sublimation
  3500 below.
• No need change ink cartridge when printing mass
  productions. Using Infinite refill equipment.
• Patented CMYK Double Technology enables high
  speed (same as LFP), SW Mirroring decrease
  bidirection banding.
• Support Roll Paper, 1 Job above 10m, When using
  External Roll setter, 100m above printing is OK.
• Support ICC Profiles.
• Direct print from any Windows application ( for
  example, word, powerpoint , excel , Corel draw ..
  All program is OK. )
• Support optional design program (Davinci Pro),
  Easy to learn, many cliparts and samples included
  ( clipart, sample 10,000 EA )

9
Contact US Sales contact sales_at_fullbitsoft.com
Technical contact as_at_fullbitsoft.com Tel.
82-505-505-5009 Fax. [phone] http//ww
w.fullbitsoft.com
Thank You !
