Get the Best Out of Oracle Data Pump Functionality

1
(No Transcript)
2
Get the Best Out of Oracle Data Pump Functionality

• Dean Gagne (Oracle)
• Viljo Hakala (Nokia)

3
Agenda

• Moving large amounts of data with Transportable
  Tablespaces
• Filtering metadata using the INCLUDE and EXCLUDE
  parameters
• Restarting stopped/failed jobs
• Hear about Nokia Corporation's database
  environment
• How Nokia uses the REMAP_DATA parameter to
  scramble data
• How Nokia regenerates primary keys without having
  to use additional software or scripts

4
What is Oracle Data Pump?

• New feature starting in Oracle Database
  10g Release 1
• Enables very fast bulk data and metadata movement
  between Oracle databases
• High-speed, parallel Export and Import utilities
  (expdp and impdp) as well as a Web-based Oracle
  Enterprise Manager interface
• Jobs can be restarted without loss of data,
  whether or not the stoppage was voluntary or
  involuntary
• Jobs support fine-grained object selection.
  Virtually any type of object can be included or
  excluded
• Supports the ability to load one instance
  directly from another (network import) and unload
  a remote instance (network export)

5
Moving Large Amounts of Data With Transportable
Tablespace
6
What is Transportable Tablespace?

• An Oracle Database feature that allows data file
  transfer from a database to another via a simple
  os copy and a light specific export/import
• Data Pump will move metadata only
• Data moves with data file copy
• Much faster than using direct path or external
  tables

7
Moving Large Amounts of Data With Transportable
Tablespaces

• Restrictions
• Tablespaces need to be self contained
• All dependent objects must be included in
  tablespace set
• Tablespaces need to be read only for duration of
  export and datafile copying.
• Not restartable
• Must be privileged account
• Notes
• Use RMAN CONVERT to change endianness (if needed)
• Data Pump moves only metadata
• Can use network link
• For a full list of what is exported
• select unique seq_num, full_pathfrom
  datapump_pathswhere het_type
  'TRANSPORTABLE_EXPORTorder by seq_num

8
Transportable Tablespaces Self Containment
Check

• Create table part_tab(id number) tablespace a
  partition by range (id) (partition low value
  less than (100) tablespace b, partition hi
  values less than (1000) tablespace c)
• Create index part_ind on part_tab.id tablespace
  d
• Transportable tablespace export requires all 4
  tablespaces
• (a, b, c, d)
• DBMS_TTS.TRANSPORT_SET_CHECK procedure to verify
• accepts a comma separated list of tablespace
  names
• SELECT FROM transport_set_violations

9
Transportable Tablespace Steps

• Source system tasks
• Optionally run DBMS_TTS.TRANSPORT_SET_CHECK
• Set tablespaces read only
• Run expdp command with tablespace list
• Data Pump will list required dumpfiles and
  datafiles in log file
• Copy datafiles and dumpfiles to target system
• Optionally set tablespaces read write
• Target system tasks
• Run impdp command
• Optionally set tablespaces to read write

10
Table Mode with Transportablealways

• Can export/import tables, partitions, and indexes
  regardless of tablespace closure
• Cant have any storage in system, sysaux, temp
  tablespaces
• Data Pump export will list tablespaces that need
  to be read only if not already done
• Data Pump export will list datafiles and
  dumpfiles that need to be copied to target
• Data Pump import can use filters dont have to
  import the complete dumpfile set
• Can import only one partition Data Pump creates
  a non-partitioned table
• Partition_optionsdepartition creates
  non-partitioned tables for every partition

11
Export Table Mode with TransportablealwaysExpdp
scott/tiger tablespt1,pt2 transportablealways

• Table filter needs to be complete tables or
  partitions from the same table
• ptab1,ptab2, etc or ptab1lo,ptab1hi
• ORA-29335 tablespace 'USER1' is not read
  onlyORA-29335 tablespace 'USER2 is not read
  only
• Dump file set for SCOTT.SYS_EXPORT_TABLE_01 is
  /oracle/work/tab_tts.dmp
• Datafiles required for transportable tablespace
  USER1 /oracle/dbs/user1.fDatafiles required
  for transportable tablespace USER2
  /oracle/dbs/user2.f

12
Import Using Transportable Table Mode Dumpfile

• Impdp scott/tiger tablesptab2hi
  rename_tableptab2himy_tab1 transport_datafiles

• Created table is my_tab1
• Impdp scott/tiger tablesptab2 partition_optionsd
  epartition transport_datafiles
• Created tables are ptab2_lo, ptab2_hi
• Creates all tablespaces even if no objects
  created due to import filters
• Cleans up any unused tablespace segments that are
  not imported

13
Filtering Metadata
14
Filtering Metadata Overview

• Perform selective export/import job based on
  object type
• Exp/imp had limited filtering
• Grants, index, triggers, statistics, constraints
• Data Pump has almost complete filtering
  capabilities

15
Filtering Metadata Using INCLUDE and EXCLUDE
Parameters

• If using exclude parameter, everything else is
  included
• If using include parameter, everything else is
  excluded
• Cant use exclude and include in the same Data
  Pump job
• Specify complete path or partial path. Objects
  matching the specified path will be
  excluded/included.
• Query to find exclude/include object types
• select unique seq_num, full_pathfrom
  sys.datapump_pathswhere het_type
  'DATABASE_EXPORT' order by seq_num
• Job_type het_type
• FULL
  DATABASE_EXPORT
• SCHEMA SCHEMA_EXPORT
• TABLE TABLE_EXPORT
• TRANSPORTABLE TRANSPORTABLE_EXPORT

16
Exclude Example expdp system/manager
schemahr excludestatistics
vs expdp system/manager
schemahr exclude
SCHEMA_EXPORT/TABLE/STATISTICS

• select unique seq_num, full_path
• from sys.datapump_paths
• where het_type 'SCHEMA_EXPORT' AND full_path
  like 'STATISTICS
• order by seq_num
• 77 SCHEMA_EXPORT/TABLE/INDEX/STATISTICS
• 78 SCHEMA_EXPORT/TABLE/INDEX/STATISTICS/INDEX_S
  TATISTICS
• 221 SCHEMA_EXPORT/TABLE/INDEX/STATISTICS
• 222 SCHEMA_EXPORT/TABLE/INDEX/STATISTICS/FUNCTION
  AL_AND_BITMAP
• 223 SCHEMA_EXPORT/TABLE/INDEX/STATISTICS/FUNCTION
  AL_AND_BITMAP/INDEX_STATISTICS
• 225 SCHEMA_EXPORT/TABLE/STATISTICS
• 226 SCHEMA_EXPORT/TABLE/STATISTICS/TABLE_STATISTI
  CS
• 227 SCHEMA_EXPORT/TABLE/STATISTICS/USER_PREF_STAT
  ISTICS

17
Include Examples

• impdp system/manager tableshr.employees vs
• impdp system/manager schemashr
  includetable\" \'EMPLOYEES\'\"
• Same results
• Includes all objects that have table in the path
• vs
• impdp system/manager schemashr
  includetable/table\" \'EMPLOYEES\'\
• Only includes the table
• Some of the TABLE object paths
• SCHEMA_EXPORT/TABLE/TABLE
• SCHEMA_EXPORT/TABLE/TABLE_DATA
• SCHEMA_EXPORT/TABLE/GRANT

18
Restarting Stopped/Failed Jobs
19
Restarting Data Pump Jobs

• Restart jobs intentionally or unintentionally
  stopped
• User stopped
• Dumpfile exhausted
• Resumable wait
• Optionally change value of PARALLEL parameter
• Helps to know the job name
• System generated job names
• SYS_IMPORT_FULL_01
• SYS_EXPORT_TABLE_05
• What jobs are restartable
• Select from dba_datapump_jobs
• Select from user_datapump_jobs

20
Restarting Stopped Export JobsInitial Export
Command expdp system/manager
job_namedatapump_exp

• Restart command
• expdp system/manager attachdatapump_exp
• Exportgt start_job
• Resets dumpfile pointers to last completed object
  type
• Restarts the job after the last completed object

21
Restarting Stopped Import Jobs initial import
command impdp system/manager
job_namedatapump_imp

• Restart command
• Impdp system/manager attachsystem.datapump_imp
• Importgt Start_jobskip_current
• Detects the last object created
• If creating an object and the object exists,
  checks to see if object was in progress in failed
  job
• Data that was being loaded would have either been
  committed or not. Committed data marked
  complete, uncommitted data will be retried.

22
Restarting Stopped Network Import JobsInitial
Import Command impdp scott/tiger
job_namenet_imp network_linkdbs1

• Restart command
• Impdp scott/tiger attachnet_imp
• Importgt Start_jobskip_current
• Restarts on object type
• If creating object and object exists, checks to
  see if object was in progress in failed job
• Data that was being loaded would have either been
  committed or not. Committed data marked
  complete, uncommitted data will be retried.

23
Hear about Nokia Corporation's Database
Environment and how they use Oracle Data Pump

• Viljo Hakala (Nokia)

24
Nokia

• Nokia is a world leader in mobility
• Head office in Finland RD, production, sales,
  marketing activities around the world
• Worlds 1 manufacturer of mobile devices, with
  estimated 40 share of global device market in
  2009
• Mobile device volumes 468 million units
• Net sales EUR 50.7 billion
• Operating profit EUR 5.0 billion
• 128 445 employees at year end (including Nokia
  Siemens Networks)
• Strong RD presence in 16 countries
• RD investment EUR 6.0 billion
• Sales in more than 150 countries

24
25
Oracle _at_ Nokia

• 20 DBAs, 2300 databases
• Grid Control used for almost 5 years, 1 tool
  for all DBAs
• Applications
• OLTP 50, Hybrid databases 40, DW 10
  Teradata
• About 1800 Oracle also MySQL 200, MS SQL 300
• 11g 4
• 10g 80
• 9i 15
• 8i 1
• Host platforms
• Solaris 35
• HP-UX 35
• Linux 20
• Windows 10

25
26
Oracle _at_ Nokia

• Production databases single, HA Oracle, RAC, HA
  MySQL
• 5 MB 7 TB range
• Leverage virtually all Oracle database features
• DBAs share responsibilities
• Many federated databases Streams, Advanced
  Replication, Materialized views, DB links
• Common Oracle platform, Common MySQL platform and
  Common MS SQL platform
• 99 of databases backed up with RMAN
• 8 RMAN catalog databases
• 10 PB backed up / month

26
27
What is Data Masking?
27
28
Hints for Effective Data Masking

• Be sure to mask all data that is not sensitive,
  but can be used to create sensitive data.
• You should not be able to reverse the masking for
  it to be secure. Never should you be able to
  retrieve original values from masked values.
• The masked or obfuscated data should follow the
  source data format. Masking should protect data,
  but still allow realistic looking data to be used
  for testing.
• Integrity of relations in data should be
  followed. When masking a primary key, the
  foreign keys should also be masked using the same
  masking method.
• You should be able to repeat the masking process
  for it to be an effective day to day process.

29
Data Masking with Oracle Data Pump

• One of the best uses of Oracle Data Pump is to
  load test and development systems with data from
  production systems for realistic testing
  purposes.
• Due to company rules or legal regulations,
  sensitive data in the non-production systems has
  to be replaced with realistic looking data to
  enable effective testing.
• Effective data masking routines should support
  automation and Oracle Data Pump provides several
  ways to automate data imports and exports with
  masking.

29
30
Data Masking with Oracle Data Pump

• In addition to Data Masking Pack in Grid Control,
  Oracle Data Pump provides a method to mask data
  REMAP_DATA parameter introduced in Oracle
  Database 11g.
• Oracle Data Pumps REMAP_DATA feature uses a
  remapping function to rewrite data.
• For example, a column with phone numbers could be
  replaced by a numbers generated by a REMAP_DATA
  function.

30
31
Data Masking with Oracle Data Pump

• REMAP_DATA allows transformation of columns data
  while exporting (expdp) or importing (impdp) by
  using a remapping function in the database.
• REMAP_DATA with Data Pump is usually faster than
  a custom UPDATE statement for masking data.
• To mask multiple columns in the same process and
  command, the REMAP_DATA parameter can be used
  multiple times.

31
32
Data Masking with Oracle Data Pump Quick example

• REMAP_DATAschema.tablename.column_nameschema.
  pkg.function
• impdp dumpfiledata.dmp REMAP_DATAscott.orders.cu
  stomer_namescott.maskpkg.mask
• expdp dumpfiledata.dmp REMAP_DATAscott.orders.cu
  stomer_namescott.maskpkg.mask

32
33
Data Masking with Oracle Data PumpSyntax

• REMAP_DATA
• schema1.tablename.column_name
• schema2.pkg.function
• schema1 -- the schema with the table to be
  remapped. By default, this is the schema of the
  user doing the export.
• tablename -- the table which column will be
  remapped.

• column_name -- which is to be remapped.
• schema2 -- with the PL/SQL package for remapping
  function. As a default, this is the schema of the
  user doing the export.
• pkg -- the name of the PL/SQL package with the
  remapping function.
• function -- the name of the remap function in the
  PL/SQL package

33
34
Data Masking with Oracle Data Pump Restrictions

• Data types must be same in the table column,
  masking function parameter, and function return
  value.
• No commits or rollbacks should be done in the
  masking function.
• No direct path loads can be used in import
  process with REMAP_DATA.
• Note Operation of long export/import data pump
  processes can be monitored from the
  vsession_longops view, but the estimated values
  do not take into account REMAP_DATA operations.

34
35
Data Masking with Oracle Data Pump Example

• Create a table in the CUSTOMERS schema called
  phones
• SQLgt
• CREATE TABLE CUSTOMERS.PHONES
• (
• MODELNAME VARCHAR(20) NOT NULL,
• PHONENUMBER VARCHAR2(50)
• )
• insert into CUSTOMERS.PHONES values(N900,35812
  34567)
• insert into CUSTOMERS.PHONES values(N8,3589817
  654)
• insert into CUSTOMERS.PHONES values(N7,3584834
  819)
• Commit

35
36
Data Masking with Oracle Data PumpExample

• We then need to create a function for remapping
• create or replace package customers.maskpkg
• as
• function masknumber(phonenumber varchar2)
  return varchar2
• end
• /
• create or replace package body customers.maskpkg
  as
• function masknumber (phonenumber varchar2)
  return varchar2 is
• begin return substr(phonenumber,1,4)
  round(dbms_random.value (100,999))
  lpad(round(dbms_random.value (1,9999)),4,'0')
• end
• end
• /

• The function masknumber will accept a varchar2
  type and returns a random phone number in
  varchar2 type

36
37
Data Masking with Oracle Data PumpExample

• This example will mask one column phonenumber to
  the export output file
• expdp customers/manager \
• tablescustomers.phones \
• dumpfilephones_masked.dmp \
• directorydumpdir \
• remap_data\
• customers.phones.phonenumber\
• customers.maskpkg.masknumber

• Export the data from the customers.phones table
  with expdp utility and use the REMAP_DATA option
  for masking the data in the dump file with the
  function customers.maskpkg.masknumber created
  earlier
• By default the owner of the remap function is the
  user running expdp/impdp
• Now the dumpfile phones_masked.dmp can be used
  for testing environments

37
38
Data Masking with Oracle Data PumpExample,
before masking

• SQLgt select from customers.phones
• MODELNAME PHONENUMBER
• ---------- --------------------
• N900 3591234567
• N8 3589817654
• N7 3584834819

38
39
Data Masking with Oracle Data Pump
import/replace table

• This example will import the masked dump file
• and replace the existing table with masked column
  data
• impdp customers/manager \
• tablescustomers.phones \
• dumpfilephones_masked.dmp \
• directorydumpdir \
• table_exists_actionREPLACE

39
40
Data Masking with Oracle Data PumpExample,
after import

• SQLgt select from customers.phones
• MODELNAME PHONENUMBER
• ---------- --------------------
• N900 35815499474
• N8 3584800578
• N7 3581247839

40
41
Data Masking with Oracle Data PumpImport

• REMAP_DATA parameter can also be used in the
  import process
• Use impdp if you have an existing dump file and
  you want to mask the data when loading into the
  database
• impdp customers/manager TABLE_EXISTS_ACTIONrepl
  ace dumpfilephones.dmp directorydumpdir
  remap_datacustomers.phones.phonenumbercustomers.
  maskpkg.masknumber

41
42
Primary Key Regeneration with REMAP_DATA

• To change primary keys after development phase of
  an application, use REMAP_DATA parameter.
• It is possible to use Data Pumps REMAP_DATA to
  change the primary keys within a database by
  writing a remapping function which follows the
  new primary key format.
• Primary key conflicts can happen when loading
  data to an existing table in a database.
• With REMAP_DATA, conflicts can be avoided by
  changing the column values during import.

42
43
When not to use Masking

• It can be very difficult and expensive to mask
  data especially in large BI/DWH systems due to
  the amount of data and refining operations.
• It is often easier to use a data model in which
  sensitive data can be
• limited to one location, referenced via surrogate
  keys, and
• kept safe with strict access policies and
  auditing.
• But when giving out data for simplified testing
  needs, masking is a good tool!

44
Other Methods to Secure Data in Oracle Database
11g Release 2

• Oracle Virtual Private Database (VPD aka Fine
  Grained Access Control) feature allows filtering
  of data at row-level for runtime SQL statements
  according to a defined policy.
• Data Masking Pack for Enterprise Manager.
  Centralized masking solution within Grid Control.

• Oracle Advanced Security Option for encrypting
  data at tablespace or column level.
• Oracle Label Security for restricting access to
  data based on policies.
• Oracle Database Vault for separating roles and
  restricting access to data per roles.

45
Oracle Data Pump at Nokia Summary

• Oracle Data Pump is used extensively at Nokia to
  move data and metadata between systems.
• REMAP_DATA option is a great way to mask
  sensitive data for security purposes.
• REMAP_DATA option can also be used to change
  primary keys.
• Oracle has many features for securing data at
  different levels.
• Security for data is not just Obscurity. It is a
  process and requires time.

45
46
Oracle Data Pump Summary

• Transportable Tablespaces
• Tablespace mode
• Table mode
• Filtering metadata using the INCLUDE and EXCLUDE
  parameters
• Restarting stopped/failed jobs
• REMAP_DATA parameter to scramble data
• How to generate primary keys without having to
  use additional software or scripts

47
Questions?

• Oracle Data Pump
• Demogrounds Booth Moscone West W-025

48
(No Transcript)
49
(No Transcript)
