Graphical Models for Segmenting and Labeling Sequence Data

1
Graphical Models for Segmenting and Labeling
Sequence Data
NLP-AI Seminar

• Manoj Kumar Chinnakotla

2
Outline

• Introduction
• Directed Graphical Models
• Hidden Markov Models (HMMs)
• Maximum Entropy Markov Models (MEMMs)
• Label Bias Problem
• Undirected Graphical Models
• Conditional Random Fields (CRFs)
• Summary

3
The Task

• Labeling
• Given sequence data, mark appropriate tags for
  each data item
• Segmentation
• Given sequence data, segment into non-overlapping
  groups such that related entities are in same
  group

4
Applications

• Computational Linguistics
• POS Tagging
• Information Extraction
• Syntactic Disambiguation
• Computational Biology
• DNA and Protein Sequence Alignment
• Sequence homologue searching
• Protein Secondary Structure Prediction

5
Example POS Tagging
6
Directed Graphical Models

• Hidden Markov models (HMMs)
• Assign a joint probability to paired observation
  and label sequences
• The parameters trained to maximize the joint
  likelihood of train examples

7
Hidden Markov Models (HMMs)

• Generative Model - Models the joint distribution

• Generation Process
• Probabilistic Finite State Machine
• Set of states Correspond to tags
• Alphabet - Set of words
• Transition Probability
• State Probability

8
HMMs (Contd..)

• For a given word/tag sequence pair
• Why Hidden?
• Sequence of tags which generated word sequence
  not visible
• Why Markov?
• Based on Markovian Assumption current tag
  depends only on previous n tags
• Solves the sparsity problem
• Training Learning the transition and emission
  probabilities from data

9
HMMs Tagging Process

• Given a string of words w, choose tag sequence t
  such that
• Computationally expensive - Need to evaluate all
  possible tag sequences!
• For n possible tags, m positions
• Viterbi Algorithm
• Used to find the optimal tag sequence t
• Efficient dynamic programming based algorithm

10
Disadvantages of HMMs

• Need to enumerate all possible observation
  sequences
• Not possible to represent multiple interacting
  features
• Difficult to model long-range dependencies of the
  observations
• Very strict independence assumptions on the
  observations

11
Maximum Entropy Markov Models (MEMMs)

• Conditional Exponential Models
• Assumes observation sequence given (need not
  model)
• Trains the model to maximize the conditional
  likelihood P(YX)

12
MEMMs (Contd..)

• For a new data sequence x, the label sequence y
  which maximizes P(yx,T) is assigned (T -
  parameter set)
• Arbitrary non-independent features on observation
  sequence possible
• Conditional Models known to perform well than
  Generative
• Performs Per-State Normalization
• Total mass which arrives at a state must be
  distributed among all possible successor states

13
Label Bias Problem

• Bias towards states with fewer outgoing
  transitions
• Due to per-state normalization
• An Example MEMM

14
Undirected Graphical ModelsRandom Fields
15
Conditional Random Fields (CRFs)

• Conditional Exponential Model like MEMM
• Has all the advantages of MEMMs without label
  bias problem
• MEMM uses per-state exponential model for the
  conditional probabilities of next states given
  the current state
• CRF has a single exponential model for the joint
  probability of the entire sequence of labels
  given the observation sequence
• Allow some transitions vote more strongly than
  others depending on the corresponding observations

16
Definition of CRFs
17
CRF Distribution Function
Where V Set of Label Random Variables fk and
gk Features gk State Feature fk Edge
Feature are parameters to be
estimated ye Set of Components of y defined by
edge e yv Set of Components of y defined by
vertex v
18
CRF Training
19
CRF Training (Contd..)

• Condition for maximum likelihood
• Expected feature count computed using Model
  equals Empirical feature count from training data
• Closed form solution for parameters not possible
• Iterative algorithms employed - Improve log
  likelihood in successive iterations
• Examples
• Generalized Iterative Scaling (GIS)
• Improved Iterative Scaling (IIS)

20
Graphical Comparison HMMs, MEMMs, CRFs
21
POS Tagging Results
22
Summary

• HMMs
• Directed, Generative graphical models
• Cannot be used to model overlapping features on
  observations
• MEMMs
• Directed, Conditional Models
• Can model overlapping features on observations
• Suffer from label bias problem due to per-state
  normalization
• CRFs
• Undirected, Conditional Models
• Avoids label bias problem
• Efficient training possible

23
Thanks! Acknowledgements Some slides in this
presentation are from Rongkun Shens (Oregon
State Univ) Presentation on CRFs
