Villa Presentation

1
Villa Presentation
Property Information ( Villa)
2
(No Transcript)
3
N
GROUND FLOOR PLAN
4
N
FIRST FLOOR PLAN
5

• SPECIFICATIONS AND SCHEDULE OF FINISHES
• A. EARTHWORK
• 01. Earthwork excavation as required for wall
  foundations and RC footings and other
  substructures
• 02. Backfilling of earth with available earth and
  earth brought from outside if required
• 03. Disposal of excess earth if any
• B. PLAIN CEMENT CONCRETE
• 01. Providing and laying Plain cement concrete
  (PCC ) in mix 148 below wall foundations, RCC
  footings, toe walls, flooring and below drive
  way.
• 02. Providing and laying Damp proof course (DPC)
  in mix 136 over plinth with water proof
  admixtures.
• 03. Providing and laying PCC 136 for windows
  and cills
• 04. Providing and laying PCC 136 for Coping
  slab for parapet wall topping.
• C. REINFORCED CEMENT CONCRETE
• Providing and casting in-situ Reinforced cement
  concrete (RCC) of grade M20 for FOOTINGS AND
  PEDESTALS
• 02. Providing and casting in-situ Reinforced
  cement concrete (RCC) of grade M20 for columns at
  all levels
• 03. Providing and casting in-situ Reinforced
  cement concrete (RCC) of grade M20 for lintels
  and beams
• 04. Providing and casting facias and drops
• 05. Providing and casting in-situ Reinforced
  cement concrete (RCC) of grade M20 for ground
  floor roof slab, first floor roof slab, sloped
  roof slabs.
• 06. Providing and casting lofts and shelves and
  chajjas.

SPECIFICATIONS SCHEDULE FINISHES
6
F. WINDOWS AND VENTILATORS 01. Providing and
fixing in position Fist Class TEAKWOOD French
windows and ventilators, with Frame of size
2.5x5 size and with 3x1.25 thick
styles and 1.5x1.5 central mullion and with
mosquito mesh shutters and with nominal MS
safety grill 02. Plain glass for all windows
except for the toilet with pinned glass. G.
FLOORINGS TILINGS 01. Providing And Laying
GOOD QUALITY FIRST CLASS MARBLE FOR COMMON AREAS
LIKE, LOBBY, LIVING, DINING, STAIRS, FAMILY
GOOD QUALITY POLISHED GRANITE FOR KITCHEN, AND
NON SKID CERAMIC TILES FOR ALL TOILETS
VITRIFIED TILES FOR ALL BED ROOMS EXCEPT MASTER
BED LAMINATED WOODEN FLOOR FOR MASTER BED
ROOM 02. Providing And Laying restile or
ultra/duracrete flooring for drive way, car park,
first floor balcony 03. Providing And Laying
clay tiles flooring for the first floor open flat
terrace. 04. Providing and Dadoing GLAZED TILES
for toilet walls upto 70 height or 86 height
or full height as required for all toilets with
roof chemical jointing H. IRON AND STEEL
WORKS Providing and fabricating RIBBED STEEL
BARS for reinforced cement concrete as per
structural details (basic rate of Rs 26500/-
per MT) 02. Providing and fixing in position MS
GRILLS for windows with 10mm sq brite bars (non
decorative) 03. Providing and fixing in position
MS Non decorative/ decorative Gate of 13x6 04.
Providing and fixing in position MS Non
decorative railing for Balconies Sit out 05.
Providing and fixing in position MS powder coated
staircase grill design rods, with Teakwood top
rail Non decorative/ decorative I. PLASTERING
AND POINTING 01. Providing necessary Ceiling
plastering to all soffits in CM 13 of 0.5
thick 02. Providing necessary Internal Plastering
to all Internal surfaces in CM 14 and 0.5
thick with necessary mesh jointing between RCC
and masonry junctions 03. Providing necessary
External wall plastering of 0.75 thickness to
all external surfaces in CM 14 04. Providing
Pointing to the exposed stone masonry foundation
above ground level and for stone cladding
joints.
7
J. WATER PROOFING 01. Providing required
guaranteed water proofing below and at toilet
flooring 02. Providing required guaranteed water
proofing for sloped roof and flat terrace
roof 03. Providing and laying first class water
proof concrete tiles over sloped roof with
required ridge and with approved sandtex
matt/apex fungus proof color painting. 04.
Providing necessary guaranteed water proofing
jointing at skylight area. Contractor to provide
5 year written warranty on the water proofing for
any defects encountered, he should repair at free
of cost. K. PAINTING AND POLISHING 01.
Providing painting of approved color with deluxe
luxury plastic emulsion or equivalent washable
painting to all internal surfaces . 02.
Providing painting of approved color with apex
weather shield painting for all external
surfaces of wall 03. Providing painting with
SYNTETIC ENAMEL PAINTING for all grills, gates,
and MS items and external door external
surface window external surface. 04. Providing
Melamine polishing of approved shade, to all
inside of external doors and both sides of
internal doors, stair case top rail, L.
MISCELLANEOUS ITEMS 01. Providing earth cutting
alround the building as required for formation
levels 02. Providing and laying 3 thick flagging
concrete alround the building of 2 wide 03.
Providing and fixing front rough machine
polished granite over drain 04. Providing
Guaranteed ANTITERMITE treatment for plinth,
floor, and external perimeter 05. Providing dummy
pillars for as per elevations 06. Providing
cornices and mouldings as per elevations 07.
Providing Plastering grooves as per
elevations 08. Providing capital and pedestals
for pillars as per elevations 09. Providing gate
pillars with required design 10. Providing and
finishing the plastering grooves as required as
per the design elevation. 11. Providing cinder
filling for all sunken areas 12. Providing and
fixing in position required Granite counters and
ledges as per toilet layouts ( Basic rate of
granite Rs 35/sft) 13. Providing and
constructing RCC sump tank of 7500 litre capacity
with required water proofing 14. Providing RCC
over head water tank of 3500 lit capacity and
with required water proofing 15. Providing AC
split unit provision for all bedrooms and with
required ducting, electrical points, civil works
included 16. Providing and fixing SOLAR WATER
HEATER of 200 litre capacity of approved brand
with required insulated piping as per
toilet details and with back up heating facility

8
17. Providing and fixing in position exhaust fan
(supplied by owner) with required cutouts and
frame works at all toilets and kitchen
and with required electrical points. 18.
Providing False ceilings at toilets if
required. 19. Rain water harvesting M.
ELECTRIAL All electrical points up to meter
board, using ISI standard approved make and
materials excluding any fittings and in line with
the electrical drawings furnished by the
architects All electrical switches shall be of
Modular LK(silver color plateBlack color switch)
make as approved or equivalent. All electrical
conduits shall be of FINOLEX multistrand
wires All are of concealed wiring and with a
separate UPS INDEPENDENT EMERGENCY LIGHTING
circuiting for selected points in each room Auto
level controller between sump and over head water
tank with controller placed at Kitchen utility
area N. WATER SUPPLY AND SANITARY All water
supply and sanitary points as per the TOILET
LAYOUTS FURNISHED using ISI standard approved
materials and GI/ PVC materials for piping with
necessary fittings Sanitary fixtures shall be of
Hindustan make and with Off-white/ Grey/Mint
color or equivalent color (50 color) for EWC,
wash basins Sanitary fittings shall be Jaguar
make chrome plated Counter wash basins for all
toilets Wall mounted EWC as per toilet
layouts Overhead showers, Health faucets, bidets
for all toilets
9
SCHEDULE 02 01. Electrical fittings and
fixtures like fans geysers, exhaust fans, tube
lights, light fittings 02. Air conditioners 03.
Kitchen granite platform, sink and drain boards
and wall tilling (part of kitchen decoration) 04.
Built in cupboards (wardrobes) (part of
interiors) 05. Sanctioning of the villa through
the local authority 06. Deposits and overhead
charges related to municipality/electricity board
works 07. Landscaping works 08. Providing and
cladding any Stone/ decorative tile cladding as
per the elevation treatment 09. Electricity and
water supply charges required during the
construction 10. Miscellaneous items or change in
specification as mentioned in schedule 01 THE
ABOVE INFORMATION REGARDING SPECIFICATION
(SCHEDULE OF FINISHES) IS PROVIDED HEREWITH TO
ENABLE THE CLIENT TO SELECT AND OPT FOR THE
ITEMS, FOR WHICH BILL OF QUANTITIES IS WORKED
OUT AND THE RESPECTIVE COSTING OF THE VILLA IS
DONE. ANY CHANGE IN SPECIFICATIONS SHALL AFFECT
THE COSTING ACCORDINGLY -------------------------
--------------------------------------------------
--------------------------------------------------
----------- FOR PROJECT ESTIMATE FOLLOWING
CONSIDERATIONS CAN BE CONSIDERED FOR BUDGETORY
CRITERIA (APPROXIMATE COSTING) 01. BUILDING
COST APPX Rs 1800/- per sft of the super
built up area ALTOGETHER ON A THUMB RULE, AN
AVERAGE OF Rs 1800/- per sft can be considered on
the super built up area for budgeting part,
excluding the interiors and landscape which can
be budgeted separately.
10
CLUB HOUSE FACILITIES The BLUE VALLEY PROPERTIES
boasts of very exclusive facilities that would
make you a contented villa owner. It has
in-house, state-of-the-art swimming pool, card
room, and tennis and volleyball courts, not to
mention the jogging track. Combines the modern
engineering techniques with time-tested Indian
principles of Vaastu. Theres more Our
Layouts Consists of - Easy registrations ready
to build plots with rich greenery Avenue
plantationsWi-fi and video on demand Wide
concrete roads24 hour water through tube wells
with hydro-pneumatic system Water treatment
plantRainwater harvestingUnderground sewage
lineSewage treatment plantClub house
membership Power supply networkTelephone and
cable network Multi-layered security
