New Solution-New Energy

1
New Solution-New Energy
During the era of the 1980s a Russian scientist,
Oleg V. Gritskevich, invented a device dubbed as
a hydro magnetic dynamo (HMD). There were three
dynamo proto-types built. The first two small
experimental prototypes were built in
Vladivostok, Russia in the late 1980s. The third
and last prototype built in Armenia (destroyed in
the civil war) continuously generated
electricity, except when turned off to
incorporate improvements, from 1992 to January
1997.The Armenian prototype generated a direct
current of 6,800 amperes at 220 volts,
approximately 1.5 megawatts. The scientist, now
deceased, was unable to secure funding to further
the technology, prior to his untimely death.
Oleg V. Gritskevich presents his HMD at the New
energetic conference at the Alternative Energy
Institute in Salt Lake City, 1999
2
Hydro-Magnetic Dynamo (HMD)
The hydro-magnetic dynamo (HMD) is a large-scaled
emission-free electrical generator, which does
not require external fueling. The source of the
HMDs huge electrical output is a nuclear
reaction. The HMD produces alpha particles, which
are helium nuclei made from fused deuterium, an
isotope of hydrogen with one proton and one
neutron. The electrons missing from the helium
nuclei provide a copious sink of electricity,
which provides the dynamos ability to generate
an exceptionally large amount of electricity. It
is also known that high-density charge clusters
are created in the dynamo these clusters are
thought by theorists to be the basis of
plasma-injected transmutation of elements and
also the neutralization of radioactive materials.
Unlike hot fusion and fission reactors, the HMD
does not accumulate any radioactive components.
Polishing of internal surface of the HMD toroid
at machining tool in Armenia, 1991
3
Patent Description of the Technology
The following is a condensed description of the
Hydro Magnetic Dynamo taken from the original
Russian patent. The dynamo is a sealed toroid
filled with distilled water with heavy water
(deuterium oxide) added. The movement of water
inside the toroid (closed-loop) takes advantage
of the unique properties of water as a polar
liquid, which cause a release of electrical
energy due to the rupture of hydrogen connections
(bonds). Additional electrical energy is drawn
from nuclear reactions and micro-cavitational
processes. The liquid, due to the movement in the
toroid, is ionized with a magnetic field due to
the stimulation of electromagnetic windings. A
thin layer of electrical material covers the
internal surfaces of the toroid. Thirty-two
electrodes made from a hard-alloy material are
inserted into the toroid at equal distances and
are connected to a power supply. Additional
stimulation windings are also connected to the
power supply.
HMD in protective plastic jacket.
4
More Description of the Technology
The creation of a magnetic field, due to the
stimulation windings moves the water in one
direction inside the toroid. An electromotive
force is created by the electromagnetic induction
in a separate set of windings. During the motion
of the water with super low conductivity,
electric potentials of high magnitude are
generated due to friction and excitation of the
coated layer on the inside surface of the toroid.
These potentials create special form and
magnitude of dynamical electrical gradients
making possible transmutation of substances
inside the toroid via low energy nuclear
reactions (LENR) providing with more
electromotive forces for the process. As result,
copious amounts of excess electrical energy are
generated than is required for electrical energy
input.
5
2 Megawatt System Layout
Toroid and Windings
Cooling System
Starting Device
Capacitors
Buffer Battery System
6
System Economics

• The technology is self sustaining and produces no
  emissions, including air or nuclear.
• The process utilizes no fossil fuels and produces
  electricity, effectively and efficiently at
  substantially reduced costs to anything on the
  market.
• A well-run nuclear power plant can generate power
  at 1.5 cents/kilowatt-hour, coal 3.0 cents,
  natural gas 5.5 cents, and oil 6.0 cents, current
  cost average.
• Hydro Magnetic Dynamos operating cost will be
  approximately 0.1 cent/kilowatt-hour with no
  external fuel needed and no pollution!
• Life cycle gt10 years after each major
  maintenance cycle.

7

• Patents are supported in
• Russia
• Australia
• Singapore
• Israel
• Japan
• and valid patent application in Brazil.

8

• We are interested in long-term business
  relationship with a strategic partner/investor
  for development of this energy technology. It
  concerns not only the questions of financing but
  also of technical support, RD staff, security,
  marketing etc.
• We are planning to spend 24 month on the RD
  stage. The aim is to create 1-2 generators with
  the output of 1-5 MW during the time.
•  The necessary investment for 2 years is about
  USD10 million.

9

• We will be able to get profit and return the
  investment in the 3rd year of the project in case
  of selling the licenses   if it is reasonable in
  the situation at the moment.
• Additional investments will be needed to
  organize production. If we produce and sell
  generators with the output till 5 MW in the
  amount of only 100 pieces a year, we will be able
  to return all the costs and get profit in the 5th
  year of the project.

10
Contacts

• Sintos Systems OÜ (Estonia, reg. nr.10820589)
• Mr. Boris Gritskevich
• Phone [phone]
• E-mail hmdnewenergy_at_gmail.com,
• bobogri_at_yahoo.com
• Skype bobogri
