Operating System Issues in Multi-Processor Systems

1
Operating System Issues in Multi-Processor
Systems

• John Sung
• Hardware Engineer
• Compaq Computer Corporation

2
Outline

• Multi-Processor Hardware Issues
• Snoopy Bus System Architecture
• AMD Athlons Snoopy Protocol
• ccNUMA System Architecture
• AMD Athlons LDT System Bus
• SGI Origions ccNUMA System Architecture
• Alpha 21364 System Architecture
• ccNUMA and CPU Scheduling
• Conclusion

3
Multi-Processor Hardware Issues

• Bandwidth/Latency
• Processor to Processor
• Processor to Memory
• Processor to I/O
• Scalability
• Increase performance as you increase CPU/Memory
• Coherency/Synchronization
• Give software coherent view of memory
• Provide synchronization primitives

4
Snoopy Bus System Architecture
5
Snoopy Bus System Architecture

• A bus Connects Processors,Memory,and I/O
• Scales upto 16 processors
• Limited by bus bandwidth
• Cache Coherency Protocol
• Snoops the bus for memory traffic
• Each set has to listen for addresses in its
  cache
• Does the right thing to give software coherent
  view of memory

6
Snoopy Bus System Architecture
CPU Core
CPU Core
CPU Core
Cache
Cache
Cache
Bus
Memory I/O
Memory I/O
Memory I/O
7
ccNUMA System Architecture
8
ccNUMA System Architecture

• Cache-Coherent Non-Uniform Memory Access
• Memory is distributed and attached to processors
• Some network connects each processor/memory sets
• Each processor owns part of the memory space
• Cache coherency protocol
• Gives software coherent view of memory
• Protocol primitives for synchronization
• Directory to keep track of who has a copy of
  memory

9
ccNUMA System Architecture
CPU Core
CPU Core
Cache
Cache
Memory Directory I/O
Network Router
Network Router
Memory Directory I/O
Network Fabric
10
SGI Origin System Architecture
11
SGI CrayLinkTM

• Node 2 CPU and their cache
• Module Memory Directory HUB
• 2 Modules per Router
• System Modules Routers CrayLinkTM Network

12
SGI CrayLinkTM
13
Processor System Network
14
Bisectional Bandwidth
15
ccNUMA and CPU Scheduling Issues
16
OSs Questions

• Single CPU System
• What to schedule next?
• ccNUMA System
• What to schedule next?
• Which cpu to schedule it to?
• Where should the process information be located
  at?
• 1 or many instances of OS?

17
OSs Choices for a Process

• Single CPU System
• Process has1 choice
• Process information has 1 choice
• ccNUMA System with N CPUs and M Memory
• Process has N choices
• Process information M choices per virtual page
• Distance between process and its information

18
Context Switch Penalty

• Single CPU System
• Saving/Restoring process state (PCB)
• Scheduling routine
• ccNUMA System
• Saving/Restoring process state (PCB)
• Scheduling routine
• Moving processs information

19
Some Common Sense

• Replicate parts of the OS across processors
• System calls will happen often
• Minimize process movement
• Cost of moving a process to another CPU is high
• Less than swaping to disk, most of the time
• Higher than simple context switching
• But if you have to move a process
• Minimize the amount of information to move
• Opportunity for a cache????

20
Conclusion

• Hardware
• Bandwidth and Latency for performance
• Cache Coherency for correctness
• Operating System
• ccNUMA adds complexity in CPU scheduling
• HW performance Lower Context Switch Penalty gt
  flexibility in scheduling choices for a process

21
References

• Alpha
• http//www.digital.com/alphaoem/present/ev7forum98
  .ppt
• http//www.compaq.com/InnovateForum99/presentation
  /session31/
• http//www.digital.com/alphaoem/
• AMD
• http//www.amd.com/products/cpg/mpf/speech/slides9
  9.ppt
• SGI
• http//www-europe.sgi.com/origin/numa_tech.html
• BenchMarks
• http//www.spec.org/
• http//www.tpc.org/

22
Abbreviation Index

• AMD - Advanced Micro Devices
• SGI - Silicon Graphics Inc.
• ECC - Error Correction Code
• SECDED - Single Error Correct Double Error Detect
• API - Alpha Processor Inc
• AGP - Accelerated Graphics Port
• DDR DRAM - Double Data Rate Dynamic RAM
• LTD - Lightning Data Transport
• PCI - Peripheral Component Interconnect
• CMOS - Complementary Metal Oxide Semiconductor
• CAS - Column Address Strobe
• TPC-C -Transaction Processing Performance Council
  Benchmark
• ccNUMA - Cache-Coherent Non-Uniform Memory Access
• SMP - Symmetric Multi-Processing
