Title: Smart Appliance / May 03-21 Home Automation via the Web


1
Smart Appliance / May 03-21Home Automation via
the Web
  • Client
  • Senior Design
  • Faculty Advisor
  • Doug Jacobson
  • Team Members
  • Mark Melville (EE)
  • Brendan Hickey (CprE)
  • Scott Reeder (CprE)
  • Brian Thorp (CprE)
  • Mike Fernholz (EE)

2
Presentation Outline
  • Introduction to Project
  • Project Activities
  • Resources and Schedules
  • Closing Materials

3
List of Definitions
API Application Program Interface. Interfaces between the operating system and application programs.
Host Controller Device that attaches between a wall plug and a computer that sends and receives X-10 signals.
Smart device Any piece of electronic equipment that is highly automated, or imitates human intelligence.
X-10 A communications protocol that allows compatible products to talk to each other via the existing 110V electrical wiring in the home.
X-10 Module Hardware that facilitates communication between appliances and an X-10 controller. A module would plug into an outlet, and a lamp, for example, would plug into the module.
4
Project Introduction
5
General Problem Statement
  • GOAL Develop a home automation system that is
    accessible via the WWW
  • Users include vacationing or security-conscience
    homeowners
  • System is designed to enable a homeowner to
    operate lights, appliances and other devices and
    check if their garage door is open or closed via
    the web.

6
General Solution Statement
  • Software
  • Programmed in Java
  • Three parts to the software
  • GUI application that can be run on the home
    computer that controls the X-10 devices from that
    computer
  • Java applet that can be run from any web-enabled
    device that connects to the home computer to
    control the home network
  • Java server that controls the devices when the
    applet has connected to the host computer
  • Hardware
  • Garage door monitor

7
Operating Environment
  • Software
  • Platform independent
  • Client applet must run on a browser that supports
    Java applets
  • Hardware
  • Host computer must have a serial port to talk to
    the X-10 controller
  • Garage door sensor must be able to withstand
    moderate vibration and seasonal temperature and
    humidity changes

8
Intended Users
  • Person who currently owns or will purchase a
    CM11A host controller
  • Small businesses that desire the same
    security/monitoring requirements that our system
    provides

9
Intended Uses
  • Control appliances and lamps locally
  • Control appliances and lamps remotely
  • Automate control via timed events
  • Allows user to check if their garage door is open
    or closed

10
Assumptions
  • Device shall be easy to install, configure, and
    use
  • User is familiar with operating a computer
  • User will have a computer with a serial port and
    continuous internet access.
    (dial-up not recommended)
  • Home environment will comply with the specified
    operating environment
  • X-10 system will not experience outside
    interference from other X-10 systems

11
Limitations
  • Limited to 16 different X-10 controlled devices
  • Server must be running on the home computer when
    the client desires to connect and control
    remotely
  • Device response time is limited by the speed of
    the users Internet connection

12
End Product Description
  • Installable software package
  • Installation instructions
  • User software
  • Software Documentation
  • Source Code
  • X-10 Hardware
  • Must be purchased separately (CM11A devices
    required)
  • Garage Door Sensor
  • Monitoring module
  • Mounting hardware
  • Installation instructions

13
Project Activities
14
Present Accomplishments
  • Software
  • Created local control software
  • Created remote Java applet
  • Implemented server into local software
  • Hardware
  • Created sensor circuit

15
Approaches Considered and Ones Used X-10
Hardware
  • FireCracker
  • Advantages smaller, no dedicated serial port
    required
  • Disadvantages less functionality, no 2-way
    support
  • ActiveHome CM11A
  • Advantages 2-way capable, more uses
  • Disadvantages more expensive
  • CM11A chosen because of 2-way functionality

16
Programming Language
  • Java
  • Advantages Familiar designing GUIs using Java,
    X- 10 API, cross-platform
  • Disadvantages Slower
  • C
  • Advantages Speed, flexibility
  • Disadvantages Not familiar with GUI design,
    could not find anything like the X-10 API found
    for Java.
  • Java chosen because of X-10 API and familiarity

17
Networking architecture
  • Stand-alone client/server
  • Advantages More secure and stable
  • Disadvantages Requires software on each
    machine
  • Java Applet
  • Advantages Most familiar, easy to use and
    implement
  • Disadvantages Requires Java-enabled browser
  • Java Applet chosen because it was the best fit
    for the project

18
Garage Door Sensor
  • Buying base sensor and building off of it
  • Advantages Quicker and more reliable.
  • Disadvantages Cost and less known about the
    circuit.
  • Making entire circuit
  • Advantages More knowledge of entire circuit.
  • Disadvantages Time and troubleshooting
  • Entire circuit was created from scratch, but
    commercial kit used for testing purposes.

19
Garage Door Circuit
  • Have the circuit be an X-10 module
  • Advantages More compact, easier to use
  • Disadvantages Much more time to design and
    implement
  • Have the circuit attach to an X-10 module
  • Advantages Easier to design, more flexibility
  • Disadvantages Requires an external module to
    function
  • The circuit will attach to an X-10 module because
    it allows the team to focus on the garage door
    circuit itself instead of the X-10 circuitry.

20
Research Activities
  • X-10 protocol
  • X-10 hardware CM11A
  • X-10 APIs and programming
  • X-10 2-Way functionality
  • Secure web sites
  • Trusted Applets
  • Sensor modules

21
Design Activities
  • General System Design
  • Local Software
  • Remote Software
  • Server
  • Custom Hardware

22
General System Design
Remote PC
Java-enabled PDA or Phone
Java Applet
Web server
Control Server
Key Team-created Hardware or Software Commercial
X-10 Modules
Local PC
Local Software
Computer Interface
Lamp Module
Appliance Module
Custom X-10 Hardware
Living room Lamp
Television
Sensor
23
Local Control Screenshot
24
Local Software Add a Device
25
Trusted Applet
26
Receiver Circuit Schematic
27
Transmitter Circuit Schematic
28
Integration with X-10
  • Original Approach
  • Send signal to 2-Way X-10 module
  • Modified Approach
  • Create a new power signal from X-10 module based
    on sensor circuit signal

29
Implementation Activities
  • Software
  • 1) Create local software
  • - Create GUI
  • - Send X-10 commands
  • - Add/Modify/Remove devices
  • 2) Create remote applet
  • - Create GUI
  • - Add code to send commands
  • - Store on web site with login screen
  • 3) Implement server into local software
  • - Add remote operation functionality into
    local software

30
Implementation Activities
  • Hardware
  • 1) Create Infrared Transmission Circuit
  • - Design oscillator
  • - Combine with Infrared LED
  • 2) Create Infrared Receiver Circuit
  • - Design amplifier
  • - Design filter
  • - Combine with Infrared Phototransistor
  • 3) Combine Transmitter and Receiver Circuits
  • - Create Infrared switch
  • 4) Combine infrared circuit with X-10 module
  • - Create proper integration hardware or
    circuitry

31
Testing and Modification Activities
  • Software testing
  • Test GUI
  • Test local control functionality
  • Test remote control functionality
  • Hardware Testing
  • Test infrared circuit
  • Test circuit with X-10 module
  • System testing
  • Test local control
  • Test remote operation
  • Test garage door sensor with software

32
Other Project Activities
  • Software
  • Local control software.... (90)
  • Remote Java applet...........(100)
  • Web Site with log in....... (100)
  • Server implementation into local
    software..(100)
  • Add macros to software. (75)
  • Show status of 2-way devices...... (75)
  • Hardware
  • Sensor circuit(100)
  • Implement circuit with X-10 module. (75)

33
Resources and Schedules
34
Total Financial Resources
35
Final Personal Budget
36
First Semester Schedule
Project Planning and Technology Selection
Develop Project Plan
Implement Project Design (Hardware)
37
Second Semester Schedule
Software Coding and Testing
Product Revision
Documentation
Product Demo
38
Conclusion
39
Project Evaluation
  • Identify possible designs to implement,
  • and choose one fully met
  • Hardware and software specifications
  • fully met
  • Code software by specification
  • nearly met
  • Design hardware
  • fully met
  • Test hardware and software
  • nearly met
  • Documentation
  • fully met

40
Commercialization
  • Production Costs (sensor) 20
  • Selling price (sensor) 40
  • Selling price (Software) 20
  • Market vacationers, security conscience
    homeowners
  • plus a monthly fee for using web service

41
Recommendations for Additional Work
  • Commercialization
  • Add support for additional X-10 devices
  • Secure website with a database
  • Write a java X-10 Api

42
Lessons Learned
  • What went well
  • Communication
  • Teamwork
  • What didnt go well
  • Unspecific project
  • Procrastination
  • Technical knowledge gained
  • X-10 protocol
  • Non-Technical knowledge gained
  • Time management
  • What to change
  • Start Earlier

43
Risk and Risk Management
  • Anticipated risks
  • Team scheduling
  • Loss team member
  • Finding parts
  • Finding a java API
  • Anticipated risks encountered
  • None
  • Unanticipated risks
  • X-10 API incomplete
  • Integrating sensor with X-10 module

44
Closing Summary
  • Need for project
  • No software available for remote operation
  • Didnt have a garage door sensor
  • Original software was horrible
  • Software for Windows only
  • Chosen Solution
  • Java application and applet
  • Garage door sensor
  •  Effectiveness of solution
  • Allows for remote operation of devices
  • Easy to use

45
