Core Analysis A Guide to Maximising Added Value
Colin McPhee
Senergy (GB) Limited
Society of Petroleum Engineers Distinguished
Lecturer Program www.spe.org/dl
3
Why core matters
Bob Harrison, JPT Technology Focus, August 2009

• Core.
• confirms lithology and mineralogy
• calibrates estimates of fundamental rock
  properties
• shows how fluids occupy and flow in pore space
• supplies mechanical properties for faster safer
  drilling and better completions
• Logs cannot characterize a reservoir if
  knowledge of the rock is absent
• a struggle to convince management that the
  project benefits from the knowledge gained

4
Why core analysis matters - volumetrics
Oil initially in place OIP Gross rock
volume GRV Net to Gross
N/G Porosity ? Water saturation
Sw Formation volume factor Bo
Logs, welltests, CORE Logs, CORE Logs, CORE
PVT
5
Why core analysis matters reserves

• Recovery factor depends on technical and economic
  factors
• Recovery factor is partly defined by formations
  relative permeability
• from CORE

6
Core data do we get value?

• The ground truth for formation evaluation
• But.
• Lab
• variable lab data quality and method sensitivity
• poor lab reporting standards
• End user
• inadequate planning and inappropriate design
• Have undermined value from core analysis

7
Core data do we get value?

• Review of gt 20,000 SCAL measurements
• 70 of legacy data is unfit for purpose
• 10,000,000 data redundancy cost
• Examples of unreported lab artifacts
• porosity, Sw, and capillary pressure
• Impact on hydrocarbons in place

8
Example - Archie water saturation, Sw
9
Porosity error excess brine

• Correct for excess brine in annulus between core
  and coreholder test sleeve
• Otherwise porosity too low

10
Porosity errors - impact
Lab B -7 error in log ?
11
Excess brine resistivity tests

• Ambient m and n
• core must be fully saturated
• excess brine on plug surface
• Formation factor (F)
• resistivity (R0) too low
• m too low
• Resistivity index (I)
• Rt unaffected
• n too high

12
Correcting for excess brine

• Formation factor (F) tests at stress on tight sand

mean - 30 error in ambient m
13
Correcting for excess brine

• Resistivity index (I) tests at ambient

15 error in ambient n
14
Grain loss material balance
-

15
Grain loss correction
-20 saturation unit error in Sw
16
Impact of errors on OIP

• Uncertainty analysis
• North Sea reservoir
• 20 ? and 20 Sw
• 100 MMbbl OIP
• 20 error in input data
• Largest impact
• ?, m and n (core)

17
Pc curve distortion

• Mercury injection capillary pressure (MICP)
• Pre-1994 tests on 50 80 ml plugs
• Now most tests on lt 10 ml chips/end trims
• Pc curve (Sw versus Pc) problems
• Use Hg-filled pore volume (gt 20,000 psi)
• clay destruction in small pores
• distorted Pc curves
