Energy Savings in Water and Wastewater Segment

1
Energy Savings in Water and Wastewater Segment

• Danfoss Industries Pvt. Ltd.

2
Presentation Overview

• Introduction to Danfoss
• Danfoss Core Business
• Energy savings other benefits with VFD control
• VFD applications in water and wastewater segment

3
Danfoss in brief

• 78 years of experience within energy-efficient
  technologies
• Solutions ready to combat climate challenge
• Global competence center for energy efficiency
  rooted in Southern Denmark
• The Bitten and Mads Clausen Foundation holds the
  majority of shares in Danfoss

4
Danfoss core businesses focus on Climate Energy
5
Danfoss First company to mass produce a.c.
variable frequency drives (VFD)
VFD evolution
6
Water energy --- precious resources

• Climate change is increasing pressure on global
  fresh water resources
• At the same time demand for energy is rising
• Both are contributing to increased concern for
  the environment
• VFD can provide significant energy savings,
  reduce water loss, and provide other benefits in
  water, wastewater irrigation systems

7
Pump life cycle costs

• 20 of the worlds energy is consumed by pumps

• Initial capital and whole of life maintenance
  costs 5 of the total life cycle cost
• Energy costs 95
• 95 of pumps installed are over sized (Selected
  for worst case condition safety margin)
• Methods of flow control to meet average (lower)
  flow or varying demand include e.g.
• - Impeller trimming
• Throttling valve
• Bypass valve (3-way)
• Variable Frequency Drive (VFD)
• British Pump Manufacturers Association

5
95
8
VFD (Variable Frequency Drive)
Electronic unit that varies the fixed mains
voltage frequency to control the speed of
standard a.c. electric motors

• Infinite speed control from 0-50Hz over-speed
  operation with some limitations

9
Typical energy savings with VFD on centrifugal
pumps

• Flow is proportional to speed
• Power varies to the cube of the speed
• change
• 20 reduction in speed
• 50 reduction in energy
• 50 reduction in speed
• 80 reduction in energy

10
Throttling Valve compared to VFD
11
Throttling valve compared to VFD

• VFD gives 35 energy savings compared to
  throttling valve (On typical
  variable flow applications)

12
Energy consumption of single multiple pump
systems

Single VFD controlled pump
100
Standard cascade control with 1 x VFD pump
multiple fixed speed pumps
53
48
43
Master follower with 1 x VFD per pump
Note kWh figures are approximate relative ,
based on sample test

• Master follower best energy efficiency

13
Other benefit reduced water loss

• Smooth starting stopping with VFD
• reduces mechanical stress
• Less damage to piping valves
• Lower possible system operating
• pressure also reduces water loss
• (Non revenue water, which in
• developing countries is 30 of water
• supply)

14
Application examples

• Ground water abstraction
• Reverse Osmosis
• Water distribution
• Wastewater treatment
• Irrigation

15
Groundwater abstraction

• VFD allow control of draw down
• on deep well submersible pumps
• Constant level, flow or pressure
• Benefits (e.g.)
• Energy savings
• Reduced mechanical stress leakage
• Chemical dosing to match flow

16
Application examples

• Ground water abstraction
• Reverse Osmosis
• Water distribution
• Wastewater treatment
• Irrigation

17
Reverse Osmosis

• Membranes are used to filter salt
• other impurities from water
• Variables are Flow, Temperature
• and Salinity
• Brackish water requires less
• pressure than sea water
• Benefits (E.g.)
• VFD can maintain constant output flow
• as filters block
• Elimination of pressure surges
• extends the membrane life.
• Longer time between backwash cycles.
• Less energy consumption -
• lower speed with clean filters.

18
Application examples

• Ground water abstraction
• Reverse Osmosis
• Water distribution
• Wastewater treatment
• Irrigation

19
Constant pressure with water tower/ elevated
storage tank

• Water Towers maintain constant pressure in the
  water distribution system
• and provide a certain capacity
• Pumps are used to fill the water tower, normally
  based on level control

20
Alternative system - pressure control with VFD
Water reservoir

• The VFD adjusts the pump speed based on a
  feedback signal from the pressure transmitter to
  maintain a constant pressure with changes in flow

• Note Booster pumps may also be utilised to
  overcome pressure loss in networks with e.g.
  significant elevation in the field.

21
Water Distribution

• VFD controlled pumps replace water tower to
  maintain constant pressure, irrespective of
  demand

Flow

PRESSURE

• Benefits
• Constant pressure with changing flow
• Elimination of water hammer
• Reduced water leakage
• Less energy consumption
• Less maintenance / lower whole of life cycle cost

22
Application examples

• Ground water abstraction
• Reverse Osmosis
• Water distribution
• Wastewater treatment
• Irrigation

23
Typical modern Wastewater treatment plant
24
Typical Wastewater treatment plant (WWTP) process
25
Typical energy distribution at WWTP
Typical cost distribution at WWTP
26
Fans

• Applications (E.g.)
• Odour control
• Ventilation
• Cooling towers

• Benefits
• Exact air flow to match demand
• Energy savings (20 reduction in
• speed gives 50 saving in energy)
• Constant pressure or temperature etc.
• Less wear (EG Extends belt life)
• Reduced audible noise
• Parallel fan operation possible

27
Application examples

• Ground water abstraction
• Reverse Osmosis
• Water distribution
• Wastewater treatment
• Irrigation

28
Irrigation

• Applications
• Lift station pumps (Level control)
• Deep well submersible pumps
• Transfer pumps

• Benefits
• Constant level with changing flow
• Less water hammer / mechanical stress
• Lower risk of pipe breakage
• Potential energy savings

29
Summary of benefits of VFD control

• Energy savings (E.g. 35 when compared to
  throttling valve)
• Low in rush current / low torque surges less
  mechanical stress (E.g. prevent water hammer,
  gearbox damage, belt breakage)
• Less water leakage due to lower possible
  operating pressure (I.e. extend life of
  aging infrastructure)
• Increased flexibility /improved system
  performance (E.g. control to match actual demand
  not design demand)
• Advanced control diagnostic interface
  possibilities (E.g. SCADA)
• Less maintenance / lower whole of life cycle
  costs
• Environmentally friendly solution!

30
VLT AQUA Drive

• Dedicated VFD for all applications in Water,
  wastewater irrigation
• 0.35kW 1.4MW power range
• Suit both constant variable torque loads
• Automatic Energy optimiser
• Built-in pump control protection
• functions
• Optimum ingress protection
• High efficiency ( 98)
• Lowest cost of ownership

31
Global focus

• Water
• Wastewater
• Irrigation
• Power generation
• Steam, hot water gas supply
• Waste processing recovery

• Our vision is to be recognized as the most
  dedicated supplier of Drives solutions in the
  Water Wastewater Irrigation sector world wide
• Sales service in 100 countries, including
  India
• 40 year track record
• Dedicated product organisation

32
Over 25 year track record globally in Asia
Pacific

• 1000s of Drives Soft Starters in service
• Water supply treatment
• RO / Desalination recycling
• Wastewater treatment
• Pumping Stations
• Irrigation
• Power generation
• District heating
• Waste processing recycling

33
Global References

• Bisalpur Water  Supply Project Project aims to
  reduce dependence of
• Jaipur city on ground water resources. Under this
  project 400 MLD of raw water is
• pumped from Bisalpur Dam to Clear Water treatment
  plant at Surajpura.
• Yamuna Interceptor project Delhi Jal board.
• Yen So Park is one of Vietnams most important
  development projects,
• Yen So Park entrails the development of a sewage
  treatment plant capable
• of treating 200,000m3 or half of Hanois waste
  water per day.
• Energy saving using back channel cooling and
  installation space saving.
• Pressurized system for Booster pumping stations
  in Bulgaria.

Danfoss can accept no
responsibility for possible errors in printed
material. Please consult
equipment design guides / manuals for specific
details / verify data. All images contained in
this presentation are the property of Danfoss A/S
or other parties where relevant must not be
copied. VLT is a registered trademark of Danfoss
Drives)
34

• Please consider the environment use VFD for
  your next application
• Thank you!
